PLC Control PP Strapping Roll Making Machine With Non-Stop Screen Changer
PLC Control PP Strapping Roll Making Machine With Non-Stop Screen Changer
PLC Control PP Strapping Roll Making Machine With Non-Stop Screen Changer
PLC Control PP Strapping Roll Making Machine With Non-Stop Screen Changer
PLC Control PP Strapping Roll Making Machine With Non-Stop Screen Changer
PLC Control PP Strapping Roll Making Machine With Non-Stop Screen Changer
PLC Control PP Strapping Roll Making Machine With Non-Stop Screen Changer
PLC Control PP Strapping Roll Making Machine With Non-Stop Screen Changer
Specifications
Brand Name :
JIATUO
Model Number :
JTPP-110
Certification :
CE, ISO
Place of Origin :
Shenzhen, China
MOQ :
1 Set
Price :
Negotiable
Payment Terms :
L/C, D/A, T/T, Western Union, MoneyGram
Supply Ability :
50set/month
Delivery Time :
50~55 working days
Packaging Details :
plastic film or other standard package for sea shipping
Product type :
PP Packing Belt Machine
Raw material :
Polypropylene PP raw material pellets, recycled pellets
Screw design :
single screw/ double screw
Processing type :
Extruding Machine
Power :
100KW
Capacity :
250kg/h
Automation :
Automatic
Driven Type :
Electric
Application :
Packaging Strap
Warranty :
1 Year
Description

PLC Control PP Strapping Roll Making Machine With Non-Stop Screen Changer

PRODUCT DESCRIPTION

PP strap production line is used to produce mechanical or manual bands with 100% PP recycled granules as materials, if raw materials, it will be better. This kind of band is widely used in the packing of kinds of fields such as mines, general merchandise, weaving, electrical equipment, apparatus, architecture, medicine, etc.

Type JTPP-90 JTPP-100 JTPP-110 JTPP-125 JTPP-135 JTPP-90/65 JTPP110/75
Strap of number 2 3 4 6 8 2 4
Sandwich belt Sandwich belt
width 5-19mm 5-19mm 5-19mm 9-19mm 9-19mm 9-19mm 9-19mm
Thickness 0.4-1.2mm
Reducer mode 200 200 225 250 280 200/173 225/173
Screen changer Automatic/ Manual
Production capacity 80-120kg/H 180-200kg/H 220-250kg/H 350-370kg/H 460-500kg/H 80-120kg/H 180-200kg/H
Screw type Single screw Double screw
Features of PP strapping production line

1 . This line is specially designed for the production of PP Straps. It can produce 2 or 4 PP Straps at the same time that saves energy by 20%-30%;

2 . Unique stretching process, with good rigidity and stable width.

3 . PLC Controller by touching keys with alternative languages, which is safe and easy to operate that keeps good status of all part and ensures the stable performance of whole line and continuous production of PP Straps.

Model Strap Width Strap Thickness Break Load Net Weight Strap Length Core Size
PP05005 5mm 0.5mm >40kg 10kg >6700M 200mm
PP06006 6mm 0.6mm >50kg 10kg >5800M 200mm
PP08005 8mm 0.5mm >60kg 10kg >3600M 200mm
PP09005 9mm 0.5mm >80kg 10kg >3300M 200mm
PP09006 9mm 0.6mm >90kg 10kg >3000M 200mm
PP09007 9mm 0.7mm >100kg 10kg >2500M 200mm
PP09008 9mm 0.8mm >120kg 10kg >2300M 200mm
PP12006 12mm 0.6mm >120kg 10kg >2300M 200mm
PP12007 12mm 0.7mm >130kg 10kg >2000M 200mm
PP12008 12mm 0.8mm >150kg 10kg >1660M 200mm
PP13506 13.5mm 0.6mm >130kg 10kg >2000M 200mm
PP13507 13.5mm 0.7mm >150kg 10kg >1700M 200mm
PP13508 13.5mm 0.8mm >160kg 10kg >1440M 200mm
PP13510 13.5mm 1.0mm >170kg 10kg >1250M 200mm
PP15005 15mm 0.5mm >130kg 10kg >2100M 200mm
PP15006 15mm 0.6mm >140kg 10kg >1830M 200mm
PP15008 15mm 0.8mm >160kg 10kg >1250M 200mm
PP15010 15mm 1.0mm >180kg 10kg >1100M 200mm
PP18008 18mm 0.8mm >220kg 10kg >1100M 200mm

PLC Control PP Strapping Roll Making Machine With Non-Stop Screen Changer
SERVICE

1. Machine to be installed and commissioned by our technicians. We can send our technician to install the machine accordingly if the buyer need.
2. The buyer have to pay the salary , and the air ticket, accommodation,
3. Meals and some related fees should be your responsibility.
4. It is in same condition if the buyer need the seller to send the interpreter.

GUARANTEE

1. Except the wearing parts, 12 months guarantee for machine and 6 months guarantee for electric appliance after shipment. During guarantee time, if the parts are broken caused by the product problem, seller will offer the parts by free.
2. If the parts were broken caused by the mishandling by buyer, buyer needs to buy the parts from seller.
3. The price does not include the charge of installation, the buyer will need to pay for the charge of visa, the air ticket, the accommodation and traffic charge in buyer's country.

FAQ

(1).Q: Can we send sample for customizing the machine?
A: No problem, you can send us samples, and our engineer will recommend and customize the machine according to your product and other demand.


(2).Q: If we have problem on machine or production, can you help us?
A: Yes, no problem.
We offer the Preventative Maintenance and After Sales Service. We test the machine before delivery. We offer comprehensive maintenance options to prevent equipment issues before they become problems. Also we offer one year guarantee period. If there is problem in using, you can tell us. Our engineer team will do best to help you solve the problem. Our engineers can go to your factory and help you solve the problem. We provide longlife service for the machine.


(3).Q: How can I get the price, photos and video about the machine?
A:You can contact me online or send an inquiry. Please provide your request details as clearly as possible. So we can send the price to you as soon as possible. For design or further discussion, we can all receive QQ, wechat,Skype or other instant methods to avoid any delay. We can provide you with all the details of our machines. We can manipulate the video for you if you need it.Of course, you can also visit our factory.


(4).Q: Why choose us?
1.We are an exporter of professional wire drawing machine and rope machine factory
2. We have rich experience for chemical and plastic machinery more than 20 years.
3. Our quality is praised by our customers and we provide very competitive price for you.
4. We will provide service for the machine all the time.

PLC Control PP Strapping Roll Making Machine With Non-Stop Screen Changer
