20kg Accuracy 5g Half Bridge Load Cell Sensor For Full Customization Medical Baby Scale Kid Scale
20kg Accuracy 5g Half Bridge Load Cell Sensor For Full Customization Medical Baby Scale Kid Scale
20kg Accuracy 5g Half Bridge Load Cell Sensor For Full Customization Medical Baby Scale Kid Scale
20kg Accuracy 5g Half Bridge Load Cell Sensor For Full Customization Medical Baby Scale Kid Scale
20kg Accuracy 5g Half Bridge Load Cell Sensor For Full Customization Medical Baby Scale Kid Scale
20kg Accuracy 5g Half Bridge Load Cell Sensor For Full Customization Medical Baby Scale Kid Scale
20kg Accuracy 5g Half Bridge Load Cell Sensor For Full Customization Medical Baby Scale Kid Scale
20kg Accuracy 5g Half Bridge Load Cell Sensor For Full Customization Medical Baby Scale Kid Scale
20kg Accuracy 5g Half Bridge Load Cell Sensor For Full Customization Medical Baby Scale Kid Scale
20kg Accuracy 5g Half Bridge Load Cell Sensor For Full Customization Medical Baby Scale Kid Scale
20kg Accuracy 5g Half Bridge Load Cell Sensor For Full Customization Medical Baby Scale Kid Scale
20kg Accuracy 5g Half Bridge Load Cell Sensor For Full Customization Medical Baby Scale Kid Scale
Specifications
Brand Name :
ruijia
Certification :
CE
Place of Origin :
china
MOQ :
1pc
Price :
USD 8.5~25 /piece
Payment Terms :
L/C, T/T, Western Union, D/A, D/P,
Supply Ability :
2000 Piece/Pieces per Month
Delivery Time :
Within 2Weeks
Packaging Details :
Standard export packaging
Output :
Strain gauge deformation
Type :
Load Cell
Cable :
Three Color PVC Wires
Capacity :
20kg
Theory :
Strain gauge deformation
Comprehensive error :
±0.05%F.S
Input resistance(Ω) :
500±5Ω
Output resistance(Ω) :
500±5Ω
Operating Temp.Range :
-10~+40℃
Description

Hot Sale ! Full Customization medical baby scale kid scale 20kg accuracy 5g half bridge load cell sensor

Parameters:

Rated capacity
20kg
Accuracy class
C1
Compensated Temp.Range
-10～+40℃
Comprehensive error
±0.05%F.S
Four-angle Error
1.0%F.S
Rated output
0.7±0.1mV/V
Excitation,Recommended
3～10VDC
Zero Balance
±0.5mV/V
Excitation,Maximum
5VDC
Linearity Error
±0.05%F.S
Safe Overload
120%F.S
Repeatability Error
±0.05%F.S
Ultimate Overload
150%F.S
Hysteresis Error
±0.05%F.S
Insulation Resistance
≥2000MΩ(100VDC)
Creep
0.05%F.S/15min
Cable
Three Color PVC Wires
Input Resistance
500±5Ω
Cable Length
φ0.8×420mm
Output Resistance
500±5Ω
Ingress Protection
IP65
Temp.Effect on Output
±0.1%F.S/10℃
Wiring Code
Signal + : Black ;Signal - : White
Temp.Effect on Zero
±0.1%F.S/10℃
Common : Red

20kg Accuracy 5g Half Bridge Load Cell Sensor For Full Customization Medical Baby Scale Kid Scale

Xi'an Ruijia Measuring Instruments Co., Ltd. is a manufacturer of force sensors and related products, dedicated to providing high-quality solutions for various industries. With a commitment to innovation, reliability, and precision, we have established ourselves as a trusted partner for businesses worldwide.
Founded in 2005, we have accumulated years of experience in the field of weighing technology, enabling us to deliver products tailored to our customers' needs. Our product range includes a comprehensive selection of load cells, weighing modules, controllers, systems, and software solutions. We offer a diverse array of weighing products suitable for industrial automation, logistics, transportation, healthcare, retail, and more.
At Xi'an Ruijia Measuring Instruments Co., Ltd., we pride ourselves on our technological expertise and dedication to continuous improvement. Our team of skilled engineers is committed to developing innovative solutions that push the boundaries of weighing technology, ensuring our products meet the highest standards of performance and accuracy. We serve a global clientele, catering to diverse market sectors across the globe. Our products are utilized by businesses of all sizes, from small enterprises to multinational corporations, in both domestic and international markets.
Quality is at the core of everything we do. We adhere to stringent quality control measures throughout the manufacturing process to ensure that our products meet or exceed industry standards. Our commitment to quality has earned us a reputation for reliability and excellence among our customers. Besides, customer satisfaction is our top priority. We offer comprehensive customer service and support, including technical consultation, pre-sales assistance, and after-sales service, to ensure a seamless experience for our clients.
With a focus on innovation, quality, and customer satisfaction, Xi'an Ruijia Measuring Instruments Co., Ltd. is your trusted partner for all your weighing sensor needs. Contact us today!
FAQ

1.How to place an order ?
Please provide us more details of what you want, such as: application, measurement range, output, accuracy, thread type, electric connector and other related parameters.

2.Does SNCoffer any discount ?
Yes, if you buy large QTY, please contact us, we will give you a big discount.

3.What terms of payment are available ?
We accept T/T, L/C, Trade assurance, Western Union, Paypal, etc.

4.When will you arrange the production ?
We will arrange the production immediately after receiving your payment.

5.How do you ensure good product quality ?
We have a complete quality control system, all of our products are fully checked by IQC, OQC departments

before shipping to our clients.

6.Do you have warranty ?
Yes, we provide 1 year warranty for most of our products. Some products we offer 15month to 24 months warranty.
