Anti - Corrosion Strain Gauge Load Cell For Electronic Scale 50kg / 100kg / 200kg
Anti - Corrosion Strain Gauge Load Cell For Electronic Scale 50kg / 100kg / 200kg
Anti - Corrosion Strain Gauge Load Cell For Electronic Scale 50kg / 100kg / 200kg
Anti - Corrosion Strain Gauge Load Cell For Electronic Scale 50kg / 100kg / 200kg
Specifications
Brand Name :
ruijia
Model Number :
RJ-6540
Place of Origin :
china
MOQ :
1pc
Price :
USD5-10
Payment Terms :
L/C, T/T, Western Union,
Supply Ability :
10000 Piece/Pieces per Month
Delivery Time :
Within 2-4 Weeks
Packaging Details :
Standard export packaging
Theory :
Resistance Sensor
Capacity :
50-200kg
Comprehensive error :
±0.03
Safe overload (%F.S) :
120
Ultimate overload (%F.S) :
150
Excitation voltage (V) :
9-12(DC)
Application :
electronic scale and other weighing equipment
Material :
Aluminum Alloy
Description

100kg High Accuracy Single Point Load Cell C3 Electronic Platform Scale sensors

Features:

1. Material: Aluminum Alloy

2. Silicone rubber seal, surface oxidation treatment, good anti - corrosion performance.

3. Applicable to electronic platform scales, electronic counting scales and weighing systems, with a resolution of 15,000 degrees.

Specification:

Rated capacity 30,50,60,80,100,150,200,300(kg)
Accuracy class C3
Comprehensive error 0.02%FS
Sensitivity 2.0±0.1mV/V
Zero balance 2%FS
Input resistance 410±10Ω
Output resistance 350±2Ω
Insulation resistance ≥3GΩ
Use temp.range -20 - +60℃
Excitation voltage 15V(AC/DC)
Safe overload 120%FS
Ultimate overload 150%FS
Ingress protection IP65

Dimension

Anti - Corrosion Strain Gauge Load Cell For Electronic Scale 50kg / 100kg / 200kg

Process flowchart

Anti - Corrosion Strain Gauge Load Cell For Electronic Scale 50kg / 100kg / 200kg

FAQ

1. What terms of payment are available?

We accept T/T, L/C, Western Union, , etc.

2. When will you arrange the production?

We will arrange the production immediately after receiving your payment.

3. How do you ensure good product quality?

We have a complete quality control system, all of our products are fully checked by IQC, OQC departments before shipping to our clients.
