TWINFLEX Oil Hydraulic Disc Brake for Crane Customized 20mm Disc Thickness Brake Disc
TWINFLEX Oil Hydraulic Disc Brake for Crane Customized 20mm Disc Thickness Brake Disc
Specifications
Place of Origin :
Taiwan, China
Brand Name :
STEKI
Model Number :
DBM-07 20
type :
oil hydraulic disc brake
disc thickness :
20mm
Packaging Details :
corrugated carton packing. wooden packing if necessary
1pcs/ carton
Port :
Shanghai or Fuzhou
Supply Ability :
500 Piece/Pieces per Month
Price :
$250.00/pieces >=1 pieces
Description

TWINFLEX like hydraulic brake for crane with customized brake disc

DBM20

TYEPDBM20
CYLINDER MODEL 2 1/8
CYLINDER AREADF 22.88CM2
OIL QUANTITY2.5C.C
DISC THICKNESS20MM
USABLE DISC DIA200MM
MAX AIR PRESSURE5MPA
PADS CLEARANCE7MM
WEIGHT 5.5KGS

is mainly powered by braking oil, and can also be powered by air-actuated matched with hydraulic booster. It has 2 types, right (model R)and left (model L). Please indicate right or left before landing your order. The ordinary braking fluid is required (DOT3, DOT4 or above), if you are going to use mineral oil, please informe us in advance.

Note:

"R" model, namely does move the source to enter by right, the graphical representation is "R".

"L" model, namely does move the source to enter by the left side.
