8×19S Construction Elevator Steel Rope, Diameter 8mm, Fiber Core, 1620/1770N/mm² Tensile Strength
8×19S Construction Elevator Steel Rope, Diameter 8mm, Fiber Core, 1620/1770N/mm² Tensile Strength
8×19S Construction Elevator Steel Rope, Diameter 8mm, Fiber Core, 1620/1770N/mm² Tensile Strength
8×19S Construction Elevator Steel Rope, Diameter 8mm, Fiber Core, 1620/1770N/mm² Tensile Strength
8×19S Construction Elevator Steel Rope, Diameter 8mm, Fiber Core, 1620/1770N/mm² Tensile Strength
8×19S Construction Elevator Steel Rope, Diameter 8mm, Fiber Core, 1620/1770N/mm² Tensile Strength
8×19S Construction Elevator Steel Rope, Diameter 8mm, Fiber Core, 1620/1770N/mm² Tensile Strength
8×19S Construction Elevator Steel Rope, Diameter 8mm, Fiber Core, 1620/1770N/mm² Tensile Strength
Specifications
Material :
steel wire rod
Number Of Strands :
8
Nominal Diameter :
8 mm
Application Fields :
Elevator Industry、Lifting and Hoisting Operations、Mechanical Transmission
Surface Treatment :
ungalvanized
Implementation standard :
GB 8903-2024
Product Type :
Wire Rope
Tensile Strength :
1620/1770N/mm²
Construction :
8×19S+NFC
Number Of Wires :
19
Brand Name :
Huayi
Model Number :
8×19S+NFC
Place of Origin :
China
MOQ :
2000m
Payment Terms :
T/T
Supply Ability :
10000+M+
Description
8*19S + FC - 8 Elevator Steel Rope
8×19S Construction Elevator Steel Rope, Diameter 8mm, Fiber Core, 1620/1770N/mm² Tensile Strength
Product Overview

The 8*19S+FC wire rope with fiber core is specifically engineered for elevator applications, offering superior flexibility, durability, and safety performance.

Structural Features
  • Strand Configuration: "8*19S" indicates 8 strands with 19 wires per strand, utilizing the Seale (S) construction
  • Core Material: "FC" denotes fiber core, typically composed of natural or synthetic fibers that store lubricating oil for enhanced performance
  • Construction Benefits: Seale structure features thicker outer wires for improved wear resistance and durability
Performance Advantages
Superior Flexibility

Excellent bending and winding capabilities, ideal for elevator systems and precision equipment requiring high flexibility.

Enhanced Wear Resistance

Thick outer wires in Seale construction provide superior resistance to abrasion when contacting pulleys and sheaves.

Shock Absorption

Fiber core acts as internal buffer, reducing vibration and impact loads during operation.

Long-term Protection

Fiber core stores lubricating oil for continuous lubrication and rust prevention, extending service life.

Application Fields
  • Elevator Systems: Primary hoisting wire rope ensuring smooth operation and passenger safety
  • Lifting Equipment: Suitable for small-sized lifting devices and light-duty hoisting operations
  • Mechanical Transmission: Used in winches, elevators, and equipment requiring power transmission or traction
Operational Guidelines
  • Load Management: Operate strictly within rated load capacity to prevent premature damage or failure
  • Regular Inspection: Monitor surface wear, wire breakage, and fiber core condition regularly
  • Proper Lubrication: Maintain lubrication schedule based on operating environment and frequency
  • Damage Prevention: Avoid contact with sharp objects or rough surfaces to prevent abrasion
