6×19S+PP (SFC) Elevator Governor Rope 6-9.5mm Wire Rope GB 8903-2024

Specifications

Material :

steel wire rod

Product Type :

Wire Rope

Tensile Strength :

1370/1770N/mm²、1570N/mm²、1770N/mm²、1960N/mm²

Nominal Diameter :

6-9.5 mm

Number Of Wires Per Strand :

Number Of Outer Wires :

6 strands

Brand Name :

Huayi

Model Number :

6×19S+PP (SFC)

Place of Origin :

China

MOQ :

4000m

Payment Terms :

T/T

Supply Ability :

10000+M+

Packaging Details :

roll, polly-wooden reel

Construction :

6×19S+PP (SFC)

Application Fields :

Elevator Industry、Lifting and Hoisting Operations、Mechanical Transmission

Surface Treatment :

ungalvanized

Implementation standard :

GB 8903-2024

Description

6×19S+PP SFC Elevators Governor Ropes 6-9.5mm 6 Strands GB 8903-2024

6×19S+PP (SFC) Elevators Governor Ropes

Structural Composition

6×19S: Indicates the wire rope is composed of 6 strands, with 19 wires in each strand in a Seale type (S) structure. This configuration features thicker outer wires, providing superior wear resistance, fatigue resistance, and higher tensile strength compared to other structures of the same diameter.
PP (SFC): Represents a polypropylene synthetic fiber core. The PP core offers high density, excellent toughness, and strong supporting force, maintaining wire rope shape and structural stability while providing buffering and shock absorption to extend service life.

Performance Characteristics

High Strength: The 6×19S structure provides high breaking tensile force, suitable for demanding lifting, hoisting, and traction applications.
Excellent Wear Resistance: Thicker outer wires and optimized structure effectively resist wear during contact with other surfaces, reducing breakage risk and extending service life.
Corrosion Resistance: Typically features galvanized surface treatment combined with PP core's inherent corrosion resistance, protecting against moisture, acid, alkali, and other corrosive media in harsh environments.
Superior Flexibility: Combines PP core flexibility with 6×19S structure for easy bending and winding while maintaining high strength characteristics.

Application Areas

Elevator Industry: Used as governor ropes for elevators, ensuring safety and stability during operation.

Lifting and Hoisting: Employed in cranes, tower cranes, and similar equipment for heavy load bearing and safe hoisting operations.

Mining Industry: Suitable for mine hoisting and inclined shaft traction applications in demanding underground environments.

Fishery and Forestry: Used for trawling, fishing net hoisting, timber lifting, and other specialized applications.
