Q355B Structural Steel Frame for Industrial Warehouse Buildings
Q355B Structural Steel Frame for Industrial Warehouse Buildings
Q355B Structural Steel Frame for Industrial Warehouse Buildings
Q355B Structural Steel Frame for Industrial Warehouse Buildings
Q355B Structural Steel Frame for Industrial Warehouse Buildings
Q355B Structural Steel Frame for Industrial Warehouse Buildings
Q355B Structural Steel Frame for Industrial Warehouse Buildings
Q355B Structural Steel Frame for Industrial Warehouse Buildings
Q355B Structural Steel Frame for Industrial Warehouse Buildings
Q355B Structural Steel Frame for Industrial Warehouse Buildings
Q355B Structural Steel Frame for Industrial Warehouse Buildings
Q355B Structural Steel Frame for Industrial Warehouse Buildings
Specifications
Brand Name :
KXD
Model Number :
S-0088
Certification :
CE, ISO, SGS
Place of Origin :
Qingdao, China
MOQ :
500 square meters
Price :
US$ 50-80 per square meter
Payment Terms :
L/C,T/T
Supply Ability :
3000 tons per month
Delivery Time :
30-40 working days
Packaging Details :
bulk for steel panels, steel pallet for steel structure, wooden box for small installing accessories
Installation :
Free Installing drawing details & Quick on-line technical guide
Prefabrication :
Off-site in workshop & Ready for direct installation
Connection :
High Strength Bolt connection
Visit :
Workshop Visit And Quality Check Acceptable
Turnkey Project :
Acceptable
Design :
Custom with Free Architectural design
Dimensions :
Customers' Requirement
Door :
Sliding door or rolling up door
Color :
Client's Request
Surface :
Hot-dip Galvanized / Painted
Frame :
Steel structure
Lifetime :
over 50 years
Structure Type :
High Strength Steel Structure Frame
Third Party Test :
SGS, BV, ITS
Description

Steel Structure Introduction:

Steel Frame

Materials

Q355b (equivalent to S355JR, ASTM A572 Gr. 50)

Q235b (equivalent to S235JR, ASTM A36)

H section steel

steel plate thickness: 8-30mm

Welding

Automatic submerged arc welding

Rust removal

Sand blasting

Surface finish

Alkyd / Epoxy zinc paint / hot dipping galvanized

Connection

By High strength bolt, Grade 10.9, Grade 8.8

Supporting System

Angle steel brace

L steel, Q235b, painted / hot dipping galvanized

Horizontal brace

Steel bar, Q235b, painted / hot dipping galvanized

Column brace

Steel bar, Q235b, painted / hot dipping galvanized

Tie beam

CHS, Q235b, painted / hot dipping galvanized

Connection

By ordinary bolt, Grade 4.8

Roof

Purlin

C/Z purlin, Q235b, pre-galvanized 100g-275g

Roof panel

Insulated sandwich panel or Corrugated steel sheet

Edge cover

steel sheet trimming

Gutter

Stainless steel / Galvanized sheet

Down pipe

Φ110 PVC-U, Φ150 PVC-U

Fix Accessories

sealing, self-tapping screws, etc.

Walls

Purlin

C/Z purlin, Q235b, pre-galvanized 100g-275g

Wall

Insulated sandwich panel or corrugated steel sheet

Accessories

sealing, self-tapping screws, etc.

Edge cover

steel sheet trimming

Fix Accessories

sealing, self-tapping screws, etc.

Door and window

Different sizes and types are possible to custom.

Additional option

Skylight panel; Roof ventilator; Parapet; Glass curtain wall; Decorative aluminum panel

Q355B Structural Steel Frame for Industrial Warehouse Buildings

Q355B Structural Steel Frame for Industrial Warehouse Buildings

Steel Structure Widely Appication:

Steel structure is a popular and reliable choice for a wide range of construction projects due to their structural integrity, from commercial and industrial buildings to bridges and other infrastructure developments.

Steel has a high strength-to-weight ratio, which is very strong for its weight, and is much higher than other common construction materials, such as concrete and wood. This means that steel components can be made very lightweight without sacrificing strength.

Ductile steel structures can absorb more energy before failure than brittle structures. This makes them ideal for applications subjected to high-impact loads, such as in earthquake-prone areas or industrial settings.

Prefabrication and ease of assembly of steel structures lead to faster construction times.

The steel structure is recyclable, making it an environmentally friendly choice.

Low maintenance requirements of steel structures contribute to long-term cost efficiency.

Steel fabrication can be easily modified or expanded.

Properly designed steel structures can provide high fire resistance.


Buildings’ structure Type

Building service lifetime (years)

Non-production processing building

Production processing building

Corrosive Production processing building

Steel structure

80

70

50

Reinforced Concrete structure

60

50

35

Brick Concrete structure

50

40

30

Wood and Brick structure

40

30

20

Simple structure

5-10

Steel structure is used in a wide variety of applications, including:

Buildings: Steel structure is used to construct the frames of all types of buildings, from tiny residential homes to large commercial skyscrapers.

Bridges: Steel structure is the primary material used to build bridges of all sizes, from small footbridges to large multi-span bridges.

Other infrastructure: Steel structure is also used to build other types of infrastructure, such as roads, railways, and power lines.

Industrial structures: Steel structure is used to build various industrial structures, such as factories, warehouses, and power plants.

Ships and other vessels: Steel structure is the primary material used to build ships and other vessels, such as boats, barges, and oil rigs.

Features of steel structure building

1,Steel structure has light weight;

2,Steel structure has good seismic and impact resistance;

3,Steel structure manufacturing is highly industrialized;

4,Steel structures can be assembled accurately and quickly;

5,The building can be recycled after disassemble;

6,Steel structure building construction period is short.

Q355B Structural Steel Frame for Industrial Warehouse Buildings

Q355B Structural Steel Frame for Industrial Warehouse Buildings

We own more than 20 engineers who have abundant experience for various types buildings. Before design, all requirements will be collected from clients. The design will obey the requirements and pass the calculation check by the architectural soft, such as CAD, PKPM, 3D3S etc.

For the initial planning, we will design the construction blueprint after confirming the client’s requirements details. With the check and feedback from the clients, we will make the revise if possible.

After the confirm, we will make further steel structure detailed drawing to prepare the production. This will still be offered to the clients to confirm. Double check will guarantee the building with correct details.

If necessary, finial 3D model will be offered if needed.

Q355B Structural Steel Frame for Industrial Warehouse Buildings

Details

Architectural design to meet the required loads.

1. Size (Length* Width* Height; Roof slope) : MOQ as 500sqm

2. Different Structure Types to meet different demands:

Single slope, Double slope, Multi slope

Single span, Double span, Multi span

Mezzanine, Single floor, Multi floors

3. Base: Cement and Steel foundation bolts

4. Column & Beam: Q345(S355JR) or Q235(S235JR) steel, all bolts connection!

5. Bracing: X-type or V-type or other type bracing made from angle, round pipe, etc

6. C or Z purlin: Size from C120~C320, Z100~Z200

7. Roof and wall panel:

Single steel sheet: thickness 0.4~0.7mm

Sandwich panel: thickness 50mm~150mm

8. Accessories: Semi-transparent skylight belts, Ventilators, down pipe, galvanized gutter, etc

9. Surface treatment of steel:Alkyd / Epoxy zinc / Hot dipping galvanized

10. Loading: Normally by 40'OT/ 40'HQ


Q355B Structural Steel Frame for Industrial Warehouse Buildings

KXD Service:

Our service

Design

Large engineer team for quick response and quick quote

Capability for elaborate design, high wind resistance performance

Architecture Grade: I architect certificate

Manufacture

We can manufacture all kinds of steel structure products based on different conditions of projects.

Workshop visit & Production Check

Always warmly welcome to visit our production lines before the order, Project processing during the production and Finished steel components in the packing and loading.

Certification and Test

We accept your stage to supervise the whole fabrication, steel raw material testing, and also support third-party inspection.

Installation

We provide detailed drawings to ensure installation.

We also provide remote guidance for installation.

We can also send a team of engineers to guide or install on site.

KXD is on-line for your any questions! Feel free to contact for your project! We will offer free architecture design for you.
