Quick Assembly Prefabricated Steel Structure Building Bolt Connection Easy Installation Industrial Commercial
Quick Assembly Prefabricated Steel Structure Building Bolt Connection Easy Installation Industrial Commercial
Quick Assembly Prefabricated Steel Structure Building Bolt Connection Easy Installation Industrial Commercial
Quick Assembly Prefabricated Steel Structure Building Bolt Connection Easy Installation Industrial Commercial
Quick Assembly Prefabricated Steel Structure Building Bolt Connection Easy Installation Industrial Commercial
Quick Assembly Prefabricated Steel Structure Building Bolt Connection Easy Installation Industrial Commercial
Quick Assembly Prefabricated Steel Structure Building Bolt Connection Easy Installation Industrial Commercial
Quick Assembly Prefabricated Steel Structure Building Bolt Connection Easy Installation Industrial Commercial
Specifications
Brand Name :
KXD STEEL
Payment Terms :
T/T,L/C
Connection Type :
High-Strength Bolt Connection
Packaging Details :
Steel components packed in bundles on steel pallets, wrapped with waterproof tarpaulin for ocean transport
Model Number :
KXD-SB2406
Main Structure :
Q355B H-section Steel Columns and Beams
Certification :
ISO 9001:2015, CE, SGS
Design Standard :
GB 50017-2017 / AISC / Eurocode 3
Place of Origin :
Shandong
Seismic Grade :
Grade 8
Price :
USD 35-65 / Square Meter
Service Life :
50 years
Supply Ability :
20000 Square Meters per Month
Roof & Wall Material :
Color Steel Sandwich Panel with EPS/Rock Wool Insulation
Delivery Time :
15-30 days after deposit
Wind Resistance :
Up to 180 km/h
MOQ :
100 Square Meters
Description

Quick Assembly Bolted Steel Structure Building

The KXD STEEL bolt-connection prefabricated steel structure building is engineered for maximum site efficiency. All primary and secondary members arrive at the job site pre-cut, pre-drilled, and labeled — eliminating on-site welding, cutting, and grinding. Your crew simply bolts everything together following the numbered assembly drawing.

This easy installation system reduces on-site labor by up to 40% compared to traditional welded steel construction, making it the preferred choice for projects with tight timelines or remote locations where skilled welders are scarce.


Quick Assembly Prefabricated Steel Structure Building Bolt Connection Easy Installation Industrial Commercial


Key Advantages of Bolt Connection

  • 100% Pre-Drilled Components: Every bolt hole is CNC-drilled at the factory with ±0.5mm precision — zero on-site drilling required.
  • Numbered Part Identification: Each steel member carries a unique ID tag matching the assembly drawing for foolproof erection.
  • High-Strength Grade 10.9 Bolts: All connections use torque-controlled HSFG bolts, ensuring consistent joint performance.
  • Welding-Free Assembly: Entire structure assembled with bolts and screws — no welding permits, generators, or NDT testing needed on site.
  • Rapid Erection Timeline: Typical 1000m² warehouse frame erected in 7-10 days with a 6-person crew.
  • Dismantle & Relocate Ready: Bolted connections allow full disassembly and relocation — protecting your investment.


Quick Assembly Prefabricated Steel Structure Building Bolt Connection Easy Installation Industrial Commercial

Technical Specifications

Main Frame Q355B H-section welded members, factory painted
Connection System Grade 10.9 high-strength friction-grip bolts, M16-M30
Secondary Members Q235B galvanized C/Z purlins, pre-punched holes
Bracing System

Cross bracing with

tension rods, portal frame knee braces
Roof Cladding 0.5mm color steel with EPS/rock wool sandwich panels
Wall Cladding 0.5mm corrugated color steel sheet, insulated optional
Wind Resistance Up to 180 km/h (engineered per site conditions)
Seismic Grade Grade 8
Clear Span Up to 48m single-span, unlimited multi-span configuration
Service Life 50 years with standard maintenance

Applications

  • Industrial manufacturing workshops and assembly lines
  • Commercial showrooms, retail outlets, and auto dealerships
  • Office buildings and administrative complexes
  • Aircraft hangars and maintenance facilities
  • Sports halls, exhibition centers, and event venues

Easy Installation Process

  1. Foundation Preparation: Cast anchor bolts per our supplied layout drawing — completed by your local contractor.
  2. Column Erection: Position and bolt H-section columns to embedded anchor bolts with leveling nuts.
  3. Rafter Assembly: Assemble roof trusses on the ground, then lift into position with a mobile crane.
  4. Purlin & Girt Installation: Bolt pre-punched C/Z purlins to the frame — no cutting or drilling needed.
  5. Bracing & Tie Rods: Install cross bracing and knee braces following the numbered assembly diagram.
  6. Cladding Fixing: Attach roof and wall panels with self-drilling screws and integrated washers.
  7. Trim & Flashings: Install ridge caps, corner flashings, and gutter systems to complete the weathertight envelope.

Quick Assembly Prefabricated Steel Structure Building Bolt Connection Easy Installation Industrial Commercial

FAQ

Q: Can your crew assemble this without specialized tools?
A: The only specialized tool needed is a torque wrench for critical bolted connections. Standard hand tools and a mobile crane handle the rest.

Q: Do you provide a bill of materials with bolt schedule?
A: Yes, every order includes a complete BOM with bolt grades, quantities, and torque specifications.

Q: What if we need to expand the building later?
A: Bolted steel frames are inherently expandable — we design end frames to accept future bay additions.

Q: Can the structure withstand hurricane-force winds?
A: We engineer all connections and bracing per your local wind code. 180 km/h is standard; higher ratings are available on request.
