Specifications
Brand Name :
YDX
Model Number :
YDX-SD5
Certification :
CE ISO SGS
Place of Origin :
CHINA,QINGDAO
MOQ :
50-10000 square meters
Price :
$35.00-$63.00
Payment Terms :
T/T
Supply Ability :
10000 tons/month
Delivery Time :
20-30 works days
Packaging Details :
Exported standard packing
Structure Type :
High Strength Steel Structure Frame
Color :
Client's Request
Frame :
Steel Structure
Visit :
Workshop Visit And Quality Check Acceptable
Design :
Custom With Free Architectural Design
Surface :
Hot-dip Galvanized / Painted
Description

Custom Prefab Warehouse High Strength Bolts Connected Prefabricatd Steel Structure Warehouse

Steel Structure Features:

High Strength-to-Weight Ratio – Steel offers exceptional strength while being relatively lightweight, allowing for large spans and reduced foundation loads.
Durability & Longevity – Resistant to corrosion (when properly treated) and environmental factors, steel structures have a long service life with minimal maintenance.
Design Flexibility – Steel can be molded into various shapes, enabling innovative and complex architectural designs while maintaining structural integrity.
Speed of Construction – Prefabricated steel components allow for fast assembly, reducing project timelines compared to traditional materials.
Sustainability – Steel is 100% recyclable, making it an eco-friendly choice that supports green building practices.
Seismic & Wind Resistance – Its ductility and ability to withstand dynamic forces make steel ideal for earthquake-prone and high-wind regions.
Cost-Effectiveness – Lower labor costs, reduced construction time, and minimal maintenance contribute to long-term economic benefits.
Fire Resistance – While steel weakens at high temperatures, fireproofing coatings enhance its performance in fire-prone scenarios.
Adaptability – Steel structures can be easily modified, expanded, or repurposed to meet changing needs.
Quality Control – Factory-manufactured steel components ensure precision and consistency, minimizing on-site errors.

Product Application
Light Frame Steel Construction Hangar Design Prefabricated Steel Structure Factory Building Workshop warehouse
A pre-engineered steel building is a modern technology where the complete designing is done at the factory and the building components are brought to the site and then fixed/jointed at the site, all is bolt connection, no need any welding!
An efficiently designed pre-engineered building can be lighter than the conventional steel buildings by up to 30%. Lighter weight equates to less steel and potential price savings in structural framework.
SPECIFICATION FOR STEEL STRUCTURE BUILDING
Main Steel Frame Steel Column & Beam 1. Material: Q345B (S355JR) or Q235B(S235JR)/ Welded/Hot Rolled H section steel
2. Surface: Hot Dip Galvanized or Painted;
3. Connection: All Bolts Connection;
Supporting System Roof Purlin C or Z Section Steel, Q235B
Wall PDoorurlin C or Z Section Steel, Q235B
Bracing Steel Rod, Q235B
Cross Support Steel Rod, Q235B
Column Support Angle Steel; Steel Rod; Q235B
Angle Brace Angle steel,Q235B
Tie Bar Steel Pipe,Q235B
Roof & Wall System 1. Single Colorful Corrugated Steel Sheet;
Thickness: 0.3-0.8mm
2. Sandwich Panel with EPS, Rock Wool, Fiberglass,PU;
Thickness: 50-150mm;
Accessories Sliding; Rolled Up Door (Manual/Auto)
Window Aluminum Alloy; PVC;
Downspout PVC pipe;
Gutter Galvanized Steel Sheet; Stainless Steel
Ventilator Stainless Steel Turbine Ventilator
Skylight Belt FRP or PC semi-transparent Skylight Belt
Flash Color Steel Sheet
Fittings Anchor Bolt; High Strength Bolt; Standard Bolt, Self-tapping nail etc
