Specifications
Brand Name :
YDX
Model Number :
YDX-5S14
Certification :
CE ISO SGS
Place of Origin :
CHINA,QINGDAO
MOQ :
50-10000 square meters
Price :
$35.00-$63.00
Payment Terms :
T/T
Supply Ability :
10000 tons/month
Delivery Time :
20-30 works days
Packaging Details :
Exported standard packing
Building :
Pre Engineered Steel Building Warehouse
Product Resistance :
Corrosion Resistant
Product Usage :
Building Construction
Resistance :
corrosion-resistant
Product Type :
Construction Material
Building Type :
Frame
Description
Pre-engineered Steel Structure Warehouse with Q355B/Q235B Frame

Steel Structure Features:

High Strength & Durability – Made from high-quality steel, the warehouse structure offers superior load-bearing capacity, resistance to harsh weather, and long-term stability.
Large Clear Span Design – Eliminates the need for internal columns, maximizing usable space for storage, machinery, or operations.
Quick & Easy Installation – Pre-engineered steel components allow for fast assembly, reducing construction time and labor costs.
Customizable Design – Flexible layouts to accommodate different sizes, heights, door placements (overhead, roll-up), and ventilation needs.
Low Maintenance – Corrosion-resistant coatings (e.g., galvanized or painted steel) minimize upkeep costs over time.
Cost-Effective Solution – Lower construction expenses compared to traditional materials, with long-term savings due to minimal repairs.
Fire & Pest Resistance – Steel is non-combustible and immune to termites or rodents, enhancing safety and longevity.
Eco-Friendly & Recyclable – Steel is 100% reusable, reducing environmental impact and supporting sustainable construction.
Excellent Seismic & Wind Resistance – Engineered to withstand earthquakes, heavy snow loads, and strong winds for reliable performance.
Energy Efficiency Options – Can be insulated with panels or cool roofing systems to regulate temperature and reduce energy costs.
Product Specifications
Attribute Value
Building Prefabricated Steel Structure
Product Resistance Corrosion Resistant
Product Usage Building Construction
Resistance Corrosion-resistant
Product Type Construction Material
Building Type Frame
Applications
Housing Construction
Tower Masts
Containers
Steel Pipes
Ocean Engineering
Bridges
Municipal Facilities
Mechanical Equipment
Household Items
Plantation Facilities
Technical Specifications
Main Steel Frame
Material: Q345B (S355JR) or Q235B(S235JR)/ Welded/Hot Rolled H section steel
Surface: Hot Dip Galvanized or Painted
Connection: All Bolts Connection
Supporting System
Roof Purlin: C or Z Section Steel, Q235B
Wall Purlin: C or Z Section Steel, Q235B
Bracing: Steel Rod, Q235B
Cross Support: Steel Rod, Q235B
Column Support: Angle Steel; Steel Rod; Q235B
Angle Brace: Angle steel, Q235B
Tie Bar: Steel Pipe, Q235B
Roof & Wall System
Single Colorful Corrugated Steel Sheet (0.3-0.8mm thickness)
Sandwich Panel with EPS, Rock Wool, Fiberglass, PU (50-150mm thickness)
Accessories
Doors: Sliding; Rolled Up Door (Manual/Auto)
Windows: Aluminum Alloy; PVC
Downspout: PVC pipe
Gutter: Galvanized Steel Sheet; Stainless Steel
Ventilator: Stainless Steel Turbine Ventilator
Skylight Belt: FRP or PC semi-transparent Skylight Belt
Flash: Color Steel Sheet
Fittings: Anchor Bolt; High Strength Bolt; Standard Bolt, Self-tapping nail etc
