H Beam Steel Structure Building Q235B Q345B Industrial Warehouse
H Beam Steel Structure Building Q235B Q345B Industrial Warehouse
H Beam Steel Structure Building Q235B Q345B Industrial Warehouse
H Beam Steel Structure Building Q235B Q345B Industrial Warehouse
H Beam Steel Structure Building Q235B Q345B Industrial Warehouse
H Beam Steel Structure Building Q235B Q345B Industrial Warehouse
H Beam Steel Structure Building Q235B Q345B Industrial Warehouse
H Beam Steel Structure Building Q235B Q345B Industrial Warehouse
H Beam Steel Structure Building Q235B Q345B Industrial Warehouse
H Beam Steel Structure Building Q235B Q345B Industrial Warehouse
H Beam Steel Structure Building Q235B Q345B Industrial Warehouse
H Beam Steel Structure Building Q235B Q345B Industrial Warehouse
H Beam Steel Structure Building Q235B Q345B Industrial Warehouse
H Beam Steel Structure Building Q235B Q345B Industrial Warehouse
Specifications
Brand Name :
YDX
Model Number :
YDX123
Certification :
ISO,BV.SGS,CE
Place of Origin :
CHINA
MOQ :
1TON
Price :
USD760/TON
Payment Terms :
L/C,T/T,Western Union,MoneyGram
Supply Ability :
10000TON/MONTH
Delivery Time :
35 DAYS
Packaging Details :
Steel pallet
Steel Grade :
Q235B Q345b Low Carbon Steel
Main Structure :
Hot Rolled or Welded H Section, I Section
Connect :
All Bolt Connection(High-Strength and Normal Bolt)
Roof/wall material :
Single Sheet or Sandwich Panel
Usage :
Steel Structure Platform, Steel Workshop, Structural Roofing, Steel Walkway and Floor, Steel Fabricated House, Frame Part, Steel Structure Bridge
Door :
Walk Door, Sliding Door, Roller Door
Description
H Beam Pre Engineering Steel Building Steel Structure Industrial Warehouse Construction
Product Specifications
Attribute Value
Steel Grade Q235B Q345b Low Carbon Steel
Main Structure Hot Rolled or Welded H Section, I Section
Connect All Bolt Connection (High-Strength and Normal Bolt)
Roof/wall material Single Sheet or Sandwich Panel
Usage Steel Structure Platform, Steel Workshop, Structural Roofing, Steel Walkway and Floor, Steel Fabricated House, Frame Part, Steel Structure Bridge
Door Walk Door, Sliding Door, Roller Door
Product Features
  • Custom Design: Free architectural drawings provided
  • Fast Assembly: Flexible, safe installation with thermal and noise insulation
  • Cost-Effective: Quick installation reduces construction time and costs
  • Durability: Low-maintenance structure with 50+ year lifespan
  • Weatherproof Design: Leak-proof construction with national fire prevention standards
  • Structural Strength: Resists strong winds, seismic activity, and heavy snow loads
Construction Details
Base Cement and steel foundation bolt
Main frame H beam
Material Q235B, Q345B or custom specifications
Purlin C or Z purlin: Size from C120~C320, Z100~Z20
Bracing X-type or other type bracing made from angle, round pipe
Bolt Plain bolt and High-strength bolt
Roof & wall Sandwich panel or color plate
Door Sliding or rolling door
Window Aluminium alloy window
Surface Two times of Anti-rust Painting or Hot Dip Galvanized
Sheet 0.5mm or 0.6mm galvanized sheet
Accessories Semi-transparent skylight belts, Ventilators, down pipe, galvanized gutter, etc
Installation Process
After foundation preparation, anchor bolts must be precisely positioned according to provided axis and elevation specifications. All anchor bolts must be perfectly aligned to ensure steel columns are placed in straight lines.
H Beam Steel Structure Building Q235B Q345B Industrial Warehouse H Beam Steel Structure Building Q235B Q345B Industrial Warehouse
Steel Column Installation: Foundation nuts must be leveled before hoisting. No personnel should stand within crane lifting range during operation. After positioning, anchor nuts should be properly tightened.
Steel Beam Assembly: After completing steel column tie rods/column supports, steel beams are lifted into position. All connections must achieve proper bolt tightening with consistent direction.
Welding Specifications: Roof steel beams use high-strength bolts (no welding required). Platform beams include main beams (generally welded with wing plates) and secondary beams (typically not welded).
