Lightweight Prefabricated Steel Buildings Metal Frame Structure Construction
Lightweight Prefabricated Steel Buildings Metal Frame Structure Construction
Lightweight Prefabricated Steel Buildings Metal Frame Structure Construction
Lightweight Prefabricated Steel Buildings Metal Frame Structure Construction
Lightweight Prefabricated Steel Buildings Metal Frame Structure Construction
Lightweight Prefabricated Steel Buildings Metal Frame Structure Construction
Lightweight Prefabricated Steel Buildings Metal Frame Structure Construction
Lightweight Prefabricated Steel Buildings Metal Frame Structure Construction
Specifications
Brand Name :
XGZ
Model Number :
XGZ-SPB011
Certification :
CE,ISO9001,GOST,AISC
Place of Origin :
Pingdu,Qingdao
MOQ :
100 square meters
Price :
USD 30-80 Square Meter/Negotiable
Payment Terms :
T/T,L/C,Western Union,MoneyGram
Supply Ability :
30000 tons per month
Delivery Time :
30-55 days
Packaging Details :
Steel pallet, In bulk
Name :
Prefabricated Building
Material :
Steel
Use :
Prefabricated Steel Warehouse, Workshop, Office Building
Large Span :
Customized
Structure Type :
Portal Frame With Steel H Section
Typical Model :
Single Span ,Multi Span
Surface :
Galvanized or Prepainted
Connection :
Bolt Connection and Welded Connection
Description
Lightweight Steel Structure Prefabricated Buildings For Easy Transport And Assembly
Product Description
Prefabricated steel structure buildings offer a quick-installation alternative to traditional concrete construction. The structure consists of steel columns, beams, trusses, bracing, purlins, U channel, angle steel and steel plates, connected through welding, bolts and rivets to form a complete frame.
The steel frame comprises vertical columns and horizontal beams bolted or welded together. Columns transfer compressive loads to form the building skeleton, while beams resist lateral loads. All components are precision-manufactured in our factory with tolerances under 2mm, ensuring structural safety and compliance with industry standards.
Product Specifications
Component Specification
Main steel frame H section steel beam and columns, hot dip galvanized or painted
Secondary frame Tie rod: circular steel tube; Brace: round bar; Knee brace: angle steel
Roof & Wall panel Steel angle, steel pipe, steel round
Window PVC steel or aluminum alloy window
Door Sliding door or rolling up door
Other accessories Roof gutter, rainspout, roof ventilator

Lightweight Prefabricated Steel Buildings Metal Frame Structure Construction

Key Features
  • Cost Saving: 25% lower cost per square meter than conventional buildings with reduced installation expenses
  • Quality Control: Factory-designed and fabricated with strict quality assurance throughout the process
  • Quick Erection: Bolt-connected components enable fast, step-by-step assembly
  • Flexibility: Adaptable designs with easy future expansion and economical transportation
  • Energy Efficiency: Environmentally friendly solution with CO2 reduction and recyclability
Applications
  • Industrial buildings and warehouses
  • Aircraft hangars and exhibitions
  • Supermarkets and shopping malls
  • Office buildings and workshops
  • Poultry houses and steel sheds

Lightweight Prefabricated Steel Buildings Metal Frame Structure Construction

Design & Quotation Process
Our engineering team can bring your ideas to reality. Please provide:
  • Project location and environmental conditions (wind/snow/earthquake requirements)
  • Building dimensions (length × width × height)
  • Wall and roofing material preferences
  • Crane requirements (if applicable)
  • Multi-level needs and door/window specifications

Lightweight Prefabricated Steel Buildings Metal Frame Structure Construction

Manufacturing Process
  • Cutting: Precision cutting using automatic laser technology
  • Assembly: Component fitting per engineering specifications
  • Welding: Secure joining with various welding techniques
  • Surface Preparation: Rust removal via sandblasting or chemical cleaning
  • Finishing: Custom spray painting or hot-dip galvanizing

Lightweight Prefabricated Steel Buildings Metal Frame Structure Construction

Lightweight Prefabricated Steel Buildings Metal Frame Structure Construction

Certifications
Our company holds numerous qualifications including Grade I Professional Contracting Qualification for Steel Structure Engineering, ISO 9001/14001/45001 certifications, and compliance with American, European, Russian, Japanese and British standards. We offer full-chain capabilities from design R&D to intelligent manufacturing and engineering management.
Frequently Asked Questions
Are you a manufacturer?
Yes, we operate our own factory and offer competitive pricing.
Do you offer design service?
Yes, we provide complete solution drawings using AutoCAD, PKPM, MTS, 3D3S, Tarch, and Tekla Structures.
How do you ensure quality?
We maintain strict quality control per ISO 9000 standards and support third-party inspections (SGS, BV, CCIC).
What are your payment terms?
30% deposit with balance before shipment (negotiable for specific projects).
What's your packing method?
Components are packed on steel pallets or in bulk.
