Specifications
Brand Name :
XGZ
Model Number :
XGZ-SS001
Certification :
CE EN1090,ISO9001,GOST,AISC
Place of Origin :
Pingdu,Qingdao,China
MOQ :
100 square meters
Price :
USD 30-80 per square meter
Payment Terms :
T/T,L/C,Western Union,MoneyGram
Delivery Time :
30-55 days
Packaging Details :
Steel pallet
Supply Ability :
30000 tons per month
Name :
Metal Storage Building Construction
Material :
Steel
Use :
Steel Shed,Warehouse,Workshop
Design Style :
Modern
Design Softwares :
PKPM,Auto CAD,3D3S,Tekla,SAP2000
Surface Treatment :
Hot Dip Galvanized,Painted
Description
Galvanized Pre Engineered Steel Shed Custom Color Steel Structure Warehouse Buildings
Steel sheds are practical, versatile structures providing reliable storage solutions. Constructed primarily from steel, these buildings offer exceptional strength and durability, capable of withstanding harsh weather conditions including heavy rain, strong winds, and snow accumulation. Ideal for protecting tools, equipment, and valuable items, our steel sheds feature easy assembly and complete customization options for business or agricultural applications.
Product Specifications
Our products are fully customized with all specifications designed to meet your specific requirements. We collaborate closely with customers to deliver tailor-made solutions that precisely match your needs.
Component Specifications
Main Structure Column: Q355, Q235B Welded or Hot Rolled H-steel (Box column available)
Beam: Q355, Q235B Welded or Hot Rolled H-steel
Surface Processing 1. Epoxy Zinc-Rich Primer + Epoxy Mica Intermediate Paint (120μm thickness)
2. Hot Dip Galvanization
Sub Structure Purlin: Q355B C/Z Section Steel
Angle Brace: Q235B L-Steel
Cross Bracing: Q235B Round Bar, L-Steel
Tie Bar: Q235B Round Pipe
Batter Brace: Q235B Round Bar
Roof System Roof Panel Options:
1. Insulated Sandwich Panel (PU, Rock Wool, Glass Fiber, EPS) - 50mm/75mm/100mm thickness
2. Steel Plate - 0.4mm/0.5mm thickness
Gutter Options:
1. Galvanized Steel Gutter - 2.0mm/2.5mm/3.0mm thickness
2. Painted, Pre-finished Steel Gutter - 0.4mm/0.5mm/0.6mm thickness
Downspout: PVC Pipe
Wall System Wall Panel Options:
1. Insulated Sandwich Panel (PU, Rock Wool, Glass Fiber, EPS) - 50mm/75mm/100mm thickness
2. Steel Plate - 0.4mm/0.5mm thickness
3. Brick Wall (provided by client)
Door Options: Roller Door, Sliding Door, Access Door (Steel/Glass)
Window Options: PVC or Aluminum Frame (Fixed, Swing, Sliding)
Accessories Anchor Bolts, Chemical Bolts, High Strength Bolts, Ordinary Bolts, Self-Drilling Screws, Rivets
Key Advantages of Steel Shed Buildings
  • High Strength & Stability: Constructed from high-tensile steel capable of withstanding significant loads
  • Corrosion Resistance: Surface-treated components prevent oxidation and degradation
  • Easy Installation: Engineered for straightforward assembly with minimal specialized tools
  • Customizable Specifications: Adjustable dimensions and configurations to suit specific requirements
  • Quality Assurance: Rigorous inspection procedures ensure compliance with national standards

Metal Storage Building Construction Steel Galvanized Pre Engineered Storage BuildingsMetal Storage Building Construction Steel Galvanized Pre Engineered Storage Buildings

Applications
Our steel structures serve diverse industries with reliable performance:
  • Commercial Buildings: Office spaces, retail stores, shopping centers with flexible design options
  • Industrial Facilities: Factories, warehouses, and plants requiring heavy-duty support structures
  • Agricultural Structures: Barns, storage sheds, and livestock housing resistant to pests and fire
  • Energy Infrastructure: Solar power plants and utility buildings requiring durable frameworks

Metal Storage Building Construction Steel Galvanized Pre Engineered Storage Buildings

Installation Process
  1. Foundation Construction: Pre-embedded anchor bolts according to engineering drawings
  2. Column Installation: Crane-assisted placement of steel columns onto foundation bolts
  3. Beam Assembly: Connection of main beams between installed columns
  4. Purlin Installation: Attachment of roof and wall purlins to the main framework
  5. Panel Fixation: Securing wall and roof sheets with self-tapping screws
  6. Finishing: Installation of covers, windows, and doors to complete the structure
We provide comprehensive installation support including construction drawings, instructional videos, online guidance, and optional on-site technical assistance.

Metal Storage Building Construction Steel Galvanized Pre Engineered Storage Buildings

Shipping & Handling Guidelines
  • Specialized supervision during loading to ensure proper stacking and secure binding
  • Stable transportation with trained personnel for oversized components
  • Careful handling procedures to prevent damage during loading/unloading
  • Proper equipment selection for on-site component movement
  • Immediate organization of materials upon arrival at construction site

Metal Storage Building Construction Steel Galvanized Pre Engineered Storage Buildings

Frequently Asked Questions
1. Are you a manufacturer?
Yes, we specialize in steel structure production with extensive industry experience.
2. Do you conduct pre-shipment testing?
All products undergo rigorous quality checks before dispatch to ensure compliance.
3. How is quality guaranteed?
We implement strict quality control protocols with 100% inspection prior to delivery.
4. What documentation is provided?
Complete construction drawings including plans, elevations, sections, foundations, and installation details.
5. What are payment terms?
30% deposit with 70% balance payment required before shipment.
