Q235 Q355 Pemb Metal Building , Lightweight Prefab Metal Structures
Q235 Q355 Pemb Metal Building , Lightweight Prefab Metal Structures
Q235 Q355 Pemb Metal Building , Lightweight Prefab Metal Structures
Q235 Q355 Pemb Metal Building , Lightweight Prefab Metal Structures
Q235 Q355 Pemb Metal Building , Lightweight Prefab Metal Structures
Q235 Q355 Pemb Metal Building , Lightweight Prefab Metal Structures
Q235 Q355 Pemb Metal Building , Lightweight Prefab Metal Structures
Q235 Q355 Pemb Metal Building , Lightweight Prefab Metal Structures
Specifications
Brand Name :
XGZ
Model Number :
XGZ-PEB012
Certification :
CE EN1090,ISO9001,GOST,AISC
Place of Origin :
Pingdu, Qingdao
MOQ :
100 square meters
Price :
USD 40-80 per square meter/Negotiable
Payment Terms :
T/T,L/C,Western Union,MoneyGram
Supply Ability :
30000 tons per month
Delivery Time :
30-55 days
Packaging Details :
Steel pallet or in bulk
Name :
Pre-engineered Building
Standard :
GB,EN,ASTM,GOST,JIS,BS,CSA
Type :
Light
Surface Treatment :
Painted/Galvanized
Application :
Pre-engineered Steel Warehouse, Workshop, Factory, Office Building
Description
Q235 Q355 Pemb Metal Building Prefab Metal Structures Steel Structure
Steel Structure Pre-Engineered Building With Welded H Section Steel
Steel is the most important building material in the world due to its lightweight and high strength properties. With the highest strength-to-weight ratio among all building materials, steel members add structural integrity without excessive weight. Our engineering team leverages this advantage to create flexible designs with clear spans for large space requirements. Pre-engineered steel buildings offer significant cost savings and reduced waste compared to traditional materials, with greater savings on larger projects. The environmentally friendly nature of steel minimizes waste and provides long-term energy cost reductions.
Product Parameters
Components of Steel Structure Pre-Engineered Building
  • Primary Framing Elements: Columns and beams made from H section steels (hot rolled or welded), bolted together on-site with factory primer and protective coatings.
  • Secondary Framing Elements: Purlins and tie bars fixed to columns and beams with common bolts.
  • Bracing: Round steel with knee bracing and supporting parts to enhance structural stability.
  • Cladding: Roof and wall panels made from color-coated corrugated steel sheets or sandwich panels for weather protection and durability.
  • Windows and Doors: Plastic steel or aluminum-alloy windows; sliding or folding doors.
  • Optional Features: Gutters, downpipes, transparent sheets, ventilators, and bridge cranes available per client requirements.
Items Specification
Main Steel Frame - Column Q235, Q355 Welded H Section Steel
Main Steel Frame - Beam Q235, Q355 Welded H Section Steel
Secondary Frame - Purlin Q235 C and Z purlin
Secondary Frame - Knee Brace Q235 Angle Steel
Secondary Frame - Tie Rod Q235 Circular Steel Pipe
Secondary Frame - Brace Q235 Round Bar
Secondary Frame - Vertical and Horizontal Support Q235 Angle Steel, Round Bar, or Steel Pipe
Maintenance System - Roof Panel EPS Sandwich Panel / Glass Fiber Sandwich Panel / Rock Wool Sandwich Panel / Pu Sandwich Panel / Steel Sheet
Maintenance System - Wall Panel Sandwich Panel / Corrugated Steel Sheet
Accessories - Window Aluminum Alloy Window / PVC Window / Sandwich Panel Window
Accessories - Door Sliding Sandwich Panel Door / Rolling Metal Door / Personal Door
Accessories - Rainspout PVC

Q235 Q355 Pemb Metal Building , Lightweight Prefab Metal Structures

Customization
We welcome custom designs based on your drawings. Our design team will create satisfactory plans with the following information:
  1. Location: Country and City
  2. Size: Length × width × eave height
  3. Wind load (maximum wind speed)
  4. Snow load (maximum snow height)
  5. Anti-earthquake level
  6. Brick wall requirements (if needed, specify height)
  7. Thermal insulation preferences (EPS, fiberglass wool, rockwool, PU sandwich panels, or metal sheets)
  8. Door quantity and size
  9. Window quantity and size
  10. Crane requirements (if needed, specify details)

Q235 Q355 Pemb Metal Building , Lightweight Prefab Metal Structures

Applications
Our pre-engineered steel structures serve diverse applications including:
  • Warehouse/Storage
  • Factory
  • Agriculture Barn
  • Retail Store
  • Repair/Mechanic Shop
  • Office Space
  • Medical Warehouse
  • Animal Farm (specify animal type)

Q235 Q355 Pemb Metal Building , Lightweight Prefab Metal Structures

Product Processing
Our manufacturing process includes:
  1. Material Preparation: Quality inspection and organization of steel components.
  2. Cutting and Shaping: Precision cutting and forming using advanced techniques.
  3. Welding and Joining: Secure assembly with professional welding methods.
  4. Surface Treatment: Protective treatments for corrosion resistance.
  5. Packaging and Storage: Careful preparation for shipment.
Packaging And Shipping
Main steel frames are packed on steel pallets for protection and efficient handling. Other components are securely packed in containers. We accommodate special packaging requests at additional cost.

Q235 Q355 Pemb Metal Building , Lightweight Prefab Metal Structures

Our Service
  • Custom design plans and construction drawings using Tekla, PKPM, and 3D3S software
  • PEB steel structure consultation services
  • Budget offers for contractors
  • Flexible transportation solutions
  • Custom fabrication with shot blasting and painting options
  • On-site erection and installation services with technical guidance
FAQ
1. Are you a factory?
Yes, we have extensive experience in steel building manufacturing.
2. How can I get a project quotation?
We provide quotes based on your drawings or can create designs for your approval first.
3. What drawings do you provide?
Plan, elevation, sectional, foundation, and installation drawings.
4. Do you offer overseas installation guidance?
Yes, we can send technical engineers for on-site supervision (additional cost applies).
5. How are products packaged?
Standard packaging is used, with special packaging available at customer's expense.
