Prefabricated Steel Structure Hangar Painted Galvanized Metal Aircraft Hangars
Prefabricated Steel Structure Hangar Painted Galvanized Metal Aircraft Hangars
Prefabricated Steel Structure Hangar Painted Galvanized Metal Aircraft Hangars
Prefabricated Steel Structure Hangar Painted Galvanized Metal Aircraft Hangars
Specifications
Brand Name :
XGZ
Model Number :
XGZ-SSH006
Certification :
CE EN1090,ISO9001,GOST,AISC
Place of Origin :
Qingdao,China
MOQ :
100 square meters
Price :
USD 30-80 per square meter/Negotiable
Payment Terms :
T/T,L/C,Western Union,MoneyGram
Supply Ability :
30000 tons per month
Delivery Time :
30-55 days
Packaging Details :
Steel pallet
Name :
Prefabricated Steel Structure Hangar
Design Style :
Industrial
Main Structure :
Steel Structure
Material :
Q235/Q355 Carbon Steel
Drawing Design :
AutoCAD /PKPM /3D3S, etc.
Surface Treatment :
Painted or Galvanized
Description
Prefabricated Metal Aircraft Hangars Painted Galvanized Surface
Maximum Efficiency And Cost-Effectiveness For Prefabricated Steel Structure Hangar
Prefabricated steel structure hangar is one of the innovative technologies in building construction solutions. Its economical price, convenient transportation and quick installation make it increasingly popular in construction projects.
The hangar consists of H steel columns, H steel beams, purlins, roof sheets, wall sheets, rolling doors and windows. All main structural parts (H column & beam) are fixed by high strength bolts, while purlins are fixed on columns and beams by 4.8S bolts, enabling faster workshop frame erection than traditional concrete construction systems. The roof and walls use steel sheet or sandwich panel, which are lighter and quicker to erect.
Product Specification
Components of Steel Structure Hangar
  • Primary Framing Elements: Columns and beams made of H section steels (hot rolled/welded), easily bolted together on site with factory primer and painted/galvanized surface treatment for anti-rust protection.
  • Secondary Framing Elements: Purlin and tie bar formed as secondary framing, fixed on columns and beams by common bolts.
  • Bracing: Round steel supplied with knee bracing and supporting parts for portal framing, improving stability and durability.
  • Cladding: Roof and wall covered by color-coated corrugated steel sheet or sandwich panel, hot-dipped with zinc and aluminum compound for weather protection and aesthetic appeal.
  • Windows and Doors: Plastic Steel Window/Aluminum-alloy Window; Sliding Door/Folding Door.
  • Other Options: Gutter, downpipe, transparent sheet, ventilator and bridge crane available per client requirements.

Prefabricated Steel Structure Hangar Painted Galvanized Metal Aircraft Hangars

Name Steel Structure Hangar
Size Customized according to customer needs
Main Steel Q355, Q235B etc.
Column & Beam Welded or Hot rolled H-section
Wall/Roof Sandwich panel (EPS/PU/glass wool)/steel tile
Door Rolled up door or sliding door
Window Plastic steel or aluminum alloy window
Connection Welding connection or bolt connection
Surface Hot dip galvanized or painted (customizable)
Crane 5MT, 10MT, 15MT and more
Features Of Steel Structure Hangar
  • Large span design: Allows open internal space for storage and operation, suitable for large equipment and goods.
  • Fast construction speed: Prefabricated steel components assembled on site shorten construction cycle.
  • Lightweight: Reduced self-weight compared to concrete lowers foundation loads and construction costs.
  • Excellent seismic performance: Steel's toughness and ductility ensure superior performance in earthquakes.
  • Durability: Corrosion-protected steel withstands environmental erosion with long service life.
  • High flexibility: Can be flexibly designed and modified for different production needs.
  • Environmental friendliness: Recyclable steel aligns with sustainable development requirements.
  • Low maintenance costs: Simple maintenance requirements result in long-term cost savings.
Design and Quotation
We can help realize your design concept. If no drawings exist, we can prepare them after clarifying these project details:
  • Location: Project site location, country and city.
  • Dimensions: Overall dimensions (length, width, eave height).
  • Mezzanine: Required or not, with load per square meter if applicable.
  • Wall Type: Single-layer steel sheet or sandwich panel wall.
  • Snow Load: Requirements if applicable.
  • Wind: Wind speed/load requirements.
  • Interior Column: Whether interior columns are allowed.
  • Overhead Crane: Needed or not, with capacity specification.
  • Additional Requirements: Any specific project requirements.

Prefabricated Steel Structure Hangar Painted Galvanized Metal Aircraft Hangars

Product Processing
Factory processing of steel components involves these key steps:
  • Material Preparation: Steel materials received, inspected for quality, and organized.
  • Cutting and Shaping: Components cut to size via sawing, shearing or plasma cutting, then shaped by bending, rolling or pressing.
  • Welding and Joining: Components joined using arc or gas welding for strong connections.
  • Surface Treatment: Shot blasting or painting to remove impurities and provide corrosion resistance.
  • Quality Control: Inspections at all stages to meet standards and specifications.

Prefabricated Steel Structure Hangar Painted Galvanized Metal Aircraft Hangars

Prefabricated Steel Structure Hangar Painted Galvanized Metal Aircraft Hangars

Packaging and Shipping
Packaging Detail: Main steel frame securely packed on steel pallets for protection and efficient handling. This method optimizes container space, reducing shipping costs. Other components like purlins and steel sheets are carefully packaged in parcels for safe container loading.

Prefabricated Steel Structure Hangar Painted Galvanized Metal Aircraft HangarsPrefabricated Steel Structure Hangar Painted Galvanized Metal Aircraft Hangars

Our Service
Xinguangzheng Group offers comprehensive steel structure hangar services:
  • Custom design plans and construction drawings using Tekla, PKPM, 3D3S software
  • Steel structure hangar consultation services
  • Budget offers for contractors
  • Customized transportation & delivery
  • Fabrication, shot blasting & painting to specifications
  • Erection & installation with on-site technical guidance

Prefabricated Steel Structure Hangar Painted Galvanized Metal Aircraft Hangars

Prefabricated Steel Structure Hangar Painted Galvanized Metal Aircraft Hangars

Customers Visit
We welcome visitors to our factory to observe our operations firsthand. Touring our state-of-the-art facilities and seeing our skilled workforce in action will demonstrate our commitment to quality and excellence. We look forward to establishing mutually beneficial partnerships.

Prefabricated Steel Structure Hangar Painted Galvanized Metal Aircraft Hangars

FAQ
1. Who you are?
We are a global one-stop manufacturer of steel structure buildings, offering complete services from design to installation with guaranteed quality.
2. How can I get the quotation of the project?
With existing drawings, we provide quotations directly. Without designs, we first create drawings for your confirmation before quoting.
3. Do you offer design service?
Yes, we provide complete design solutions using AutoCAD, PKPM, MTS, 3D3S, Tarch, and Tekla Structures for various industrial buildings.
4. How do you ensure your quality?
We maintain strict quality control conforming to ISO9000 standards and support pre-shipment inspections by SGS, BV CCIC and other certifications.
5. What is your terms of payment?
Standard terms are 30% deposit paid in advance with balance before shipment, negotiable for specific projects.
