Passivation ASTM 0.48mm PPGI PPGL Prepainted Gi Steel Coil S550GD
Passivation ASTM 0.48mm PPGI PPGL Prepainted Gi Steel Coil S550GD
Passivation ASTM 0.48mm PPGI PPGL Prepainted Gi Steel Coil S550GD
Passivation ASTM 0.48mm PPGI PPGL Prepainted Gi Steel Coil S550GD
Passivation ASTM 0.48mm PPGI PPGL Prepainted Gi Steel Coil S550GD
Passivation ASTM 0.48mm PPGI PPGL Prepainted Gi Steel Coil S550GD
Passivation ASTM 0.48mm PPGI PPGL Prepainted Gi Steel Coil S550GD
Passivation ASTM 0.48mm PPGI PPGL Prepainted Gi Steel Coil S550GD
Specifications
Brand Name :
HUIJIAN
Model Number :
DX51D DX54D S550GD
Certification :
ASTM、AISI、GB、JIS、DIN、BS
Place of Origin :
China
MOQ :
1 Ton
Price :
USD 623-678 per ton
Payment Terms :
L/C, T/T
Supply Ability :
10000Tons per Month
Delivery Time :
7-15 days
Packaging Details :
Standard seaworthy packing
Product Name :
Galvanized PPGI Coil
MOQ :
1 TON
Payment Term :
T/T L/C
Surface :
Color Coated Galvalume Aluzinc Galvanized
Coil Weight :
3-10 Tons
Samples :
Sample Freely
Price Term :
CIF CFR Fob Ex-Work
After-sales Service: 12 Months Warranty: 3 Years Type: Steel Plate Standard :
ASTM, AISI, GB, JIS, DIN, BS
Description
ASTM PPGI PPGL 0.48mm Color Coated Pre Painted Galvalume Sheet Coil DX51D DX54D S550GD
Product Description

Color steel plate refers to the organic coating or plastic film on the continuous production line coating or pressing on the surface of galvanized plate, cold-rolled plate or aluminum plate, forming a new type of metallurgical products.Color steel plate refers to the organic coating or plastic film on the continuous production line coating or pressing on the surface of galvanized
plate, cold-rolled plate or aluminum plate, forming a new type of metallurgical products.

Thickness
0.12mm-2.5mm
Width
750mm-1250mm
Steel Grade
SGCC/SGCH/CS Type A and B/DX51D/DX52D/G550/S280/S350 ETC
Base Steel Coating Thickness
Gazlvanized coating thickness Z30-Z275g;
Galvalume coating thickness AZ30-275g.
Color
RAL color, Wooden color,Military color,Matt, Winkled, ECT.
Painting Coating
Top coating:5-30UM;
Back coating :5-15UM
Coating Types
Top Paint: PVDF, HDP, SMP, PE, PU;
Back Paint: Epoxy, Modified Polyester.
Surface Treatment
Passivation or Chromated, Skin Pass,Oil or Unoiled,or Antifinger print
Coil Wieght
3-5 tons

Passivation ASTM 0.48mm PPGI PPGL Prepainted Gi Steel Coil S550GD
Passivation ASTM 0.48mm PPGI PPGL Prepainted Gi Steel Coil S550GD






Package of wrinkle ppgi / Diamond embossed PPGI / chequered ppgi sheet in coil

Standard packing to export:

1) 4 eye bands and 4 circumferential bands in steel
2) Galvanized metal fluted rings on inner and outer edges
3) Galvanized metal & waterproof paper wall protection disk
4) Galvanized metal & waterproof paper around circumference

Passivation ASTM 0.48mm PPGI PPGL Prepainted Gi Steel Coil S550GD

About us:
Shandong Huijian Metal Materials Co., Ltd. is a new modern private enterprise integrating R&D, produc
-tion and export. The company is located in Liaocheng, Shandong, a national excellent city known as
(Jiangbei Water City), with a registered capital of 60 million yuan, covering an area of more than 100
acres, a construction area of 20,000 square meters, and more than 100 employees. The company has
advanced production equipment and Mature technology, but also has a high-quality professional man
-agement and technical personnel team. The company has passed the international quality manage
-ment system ISO9001: 2000 certification.
FAQ:
Q:What is PPGI used for?
PPGI Sheets are sheets of pre-painted or pre-coated Steel that display high durability, and resistance against weather and UV rays from sunlight. As such, they are widely used as roofing sheets for buildings and construction.
Q:What is PPGI material?
PPGI is pre-painted galvanised iron, also known as pre-coated steel, coil coated steel, color coated steel etc., typically with a hot dip zinc coated steel substrate. The term is an extension of GI which is a traditional abbreviation for Galvanized Iron.


Q:What is difference between PPGL and PPGI?
PPGI means pre-painted galvanized steel while PPGL describes pre-painted galvalume steel.

Q:What is PPGL material?
PPGL stands for pre-painted galvalume steel, which is a kind of color-coated steel with GL as substrate. It combines the strength of steel with excellent anti-corrosion of Zn-Al coating. The galvalume coating is made of 55% aluminum, 43.4% zinc, and 1.6% silicon.
