Shipbuilding Marine Carbon Steel Plate AH36 DH36 Hot Rolled 10mm 12mm Mill Inspection
Shipbuilding Marine Carbon Steel Plate AH36 DH36 Hot Rolled 10mm 12mm Mill Inspection
Shipbuilding Marine Carbon Steel Plate AH36 DH36 Hot Rolled 10mm 12mm Mill Inspection
Shipbuilding Marine Carbon Steel Plate AH36 DH36 Hot Rolled 10mm 12mm Mill Inspection
Specifications
Brand Name :
ANSTEEL
Model Number :
DD36 AH36 Q235B A36 SS400 1020 1045 1050
Certification :
ASTM,GB,JIS,ASTM A1008
Place of Origin :
Jiangsu China
MOQ :
2 Tons
Price :
Negotiable
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
50000 Tons/Year
Delivery Time :
7-10 days
Packaging Details :
Seaworthy Packing For Exporting
Key Word :
Carbon steel plate
Grade :
SAE1008 SAE1010 SAE1050 SAE1070 DH36
Thickness :
0.6-200mm or as required
Standard :
GB/T709-2006, ASTM A36, JIS G4051
Width :
600-2300mm or as required
Sample :
We can provide it if it is in stock.
Cutting Type :
Laser Cutting;Water-Jet Cutting;Flame Cutting
Packing :
Standard seaworthy packing
Description

Shipbuilding Marine Carbon Steel Plate AH36 DH36 Hot Rolled 10mm 12mm Mill Inspection

Product Introduction

DH36 ship plate is a high-strength ship plate. Ship steel generally refers to steel for hull structure. It is a steel used to manufacture hull structure produced according to the construction specifications of classification societies. DH36 has good comprehensive mechanical properties, welding properties, and process properties. It is suitable for manufacturing hull structures of ocean-going, coastal and inland waterways, docks, oil platforms, pipelines in the sea, coastal power plants, dock facilities and other structural parts.

Standard CCS,ABS
Grade A/B/D/E,A32/D32/E32/F32,A36/D36/E36/F36,A40/D40/E40/F40,A131A/B/D/E/
AH32/DH32/EH32/AH36/DH36/EH36/AH40/DH40/EH40,NVA420/D420/E420,
NVA460/D460/E460,NVA500/D500/E500,NVA550/D550/E550….
Thickness 0.3-200mm (2-100mm usually used)
Width 600-2300mm (1000-2200mm usually used)
Length 1000-12000mm or as your request
Surface Clean, finishing,blasting and painting according to customer requirement
Process Hot-rolled, Controlled rolling, Normalizing, Annealing, Tempering, Quenching, N+T, Q+T,
and other delivery states are available as required
Certificate API,ISO,SGS,BV,CE etc
Quality MTC will be provided with goods, third part inspection is acceptable, for example BV,
SGS.
Package Standard export seaworthy package,suit for all kinds of transport,or as required.
Container Size 20ft GP:5898mm(Length)x2352mm(Width)x2393mm(High)
40ft GP:12032mm(Length)x2352mm(Width)x2393mm(High)
Trade term Ex-Work,FOB,CFR,CIF,etc
Application Widely used in a variety of architectural and engineering structures,such as
1.) metal constructions such as buildings,bridges,ships;
2.) transmission tower, reaction tower;
3.) lifting transportation machinery;
4.) industrial furnace;boilers
5.) container frame, warehouse goods shelves, etc
Product Detail

Shipbuilding Marine Carbon Steel Plate AH36 DH36 Hot Rolled 10mm 12mm Mill Inspection图像属性

Chemical Composition

Grade C Si Mn P S Als
A ≤0.21 ≤0.50 ≥2.5C ≤0.035 ≤0.035
B ≤0.21 ≤0.35 0.8~1.2 ≤0.035 ≤0.035
D ≤0.21 ≤0.35 0.6~1.2 ≤0.035 ≤0.035 ≥0.015
E ≤0.18 ≤0.35 0.7~1.2 ≤0.035 ≤0.035 ≥0.015
AH32 ≤0.18 ≤0.50 0.9~1.6 ≤0.035 ≤0.035 ≥0.015
DH32 ≤0.18 ≤0.50 0.9~1.6 ≤0.035 ≤0.035 ≥0.015
EH32 ≤0.18 ≤0.50 0.9~1.6 ≤0.035 ≤0.035 ≥0.015
AH36 ≤0.18 ≤0.50 0.9~1.6 ≤0.035 ≤0.035 ≥0.015
DH36 ≤0.18 ≤0.50 0.9~1.6 ≤0.035 ≤0.035 ≥0.015
EH36 ≤0.18 ≤0.50 0.9~1.6 ≤0.035 ≤0.035 ≥0.015
AH40 ≤0.18 ≤0.50 0.9~1.6 ≤0.035 ≤0.035 ≥0.015
DH40 ≤0.18 ≤0.50 0.9~1.6 ≤0.035 ≤0.035 ≥0.015
EH40 ≤0.18 ≤0.50 0.9~1.6 ≤0.035 ≤0.035 ≥0.015

Test

We will control the quality from part of material steel plate, each plate produced will be have it is own identify label, quality will check the chemical component and physical property and then provide material test certificate. Size dimension will be checked and show pictures to customer to guarantee all goods will be meet requirement.

Shipbuilding Marine Carbon Steel Plate AH36 DH36 Hot Rolled 10mm 12mm Mill Inspection

Cutting Service

Shipbuilding Marine Carbon Steel Plate AH36 DH36 Hot Rolled 10mm 12mm Mill Inspection

Recommend Products

Shipbuilding Marine Carbon Steel Plate AH36 DH36 Hot Rolled 10mm 12mm Mill Inspection

Application

Hot-rolled steel products are widely used in cold-rolled substrates, ships, cars, bridges, construction, machinery, oil pipelines, pressure vessels, etc. due to their excellent strength, good durability, easy processing and outstanding weldability.

Shipbuilding Marine Carbon Steel Plate AH36 DH36 Hot Rolled 10mm 12mm Mill Inspection

Package & Delivery

Shipbuilding Marine Carbon Steel Plate AH36 DH36 Hot Rolled 10mm 12mm Mill Inspection
Shipbuilding Marine Carbon Steel Plate AH36 DH36 Hot Rolled 10mm 12mm Mill Inspection

Certification

Shipbuilding Marine Carbon Steel Plate AH36 DH36 Hot Rolled 10mm 12mm Mill Inspection

FAQ

What are the shipping ports?
You can choose other ports shipping to your needs.

About the product price?
Due to the cyclical changes in raw material prices, prices vary from period to period.

What certifications do your products have?
We have ISO 9001, SGS, EWC and other certifications.
