Specifications
Brand Name :
YUHONG
Model Number :
28G-32G
Certification :
EN ISO13485:2016
Place of Origin :
China
MOQ :
30 KGS
Price :
Negotiable
Payment Terms :
T/T, L/C
Supply Ability :
13 Billion pieces Per Year
Delivery Time :
15-30 Days
Packaging Details :
Carton Box, Plastic Box, Plywood Case
Product Name :
Insulin Pen Needle
Needle Tip :
Double-end bevel tip, Triple bevelled Tip, Quintuple bevelled Tip
Standard :
ISO9626
Material :
SUS304
Diameter :
28G - 32G
Wall Thickness :
TW, ETW
Length :
4-12mm or Customize
Features :
Disposable
Description

32G 0.23MM Insulin Needle , Tri-Bevelled Injection Needle Tube For Diabetes Management

Insulin Needles are mainly used for administering insulin in the diabetes management. These needle tubes are designed to be used with insulin pens, and they have various sizes ranging from 29 Gauge to 32 Gauge. The size of the insulin needles depends on many factors such as the patient's age, physical condition, and injection site. Using insulin needles has numerous benefits for patients with diabetes. For example, insulin needles can reduce the risk of needlestick injuries, which may result in infections and other complications. These insulin needles can also minimize patients' discomfort while making injections. And insulin needles are available in different kinds of sizes to meet different patients' requirements, ensuring accurate dosages and effective delivery of insulin.

Insulin can be injected with a pen needle. Insulin needles are designed to be thinner and shorter to make insulin administration easier, less painful and discomfortable. YUHONG GROUP has manufactured stainless steel medical needle tubes for more than 30 years. We have own factory with more than 10 production lines and mainly produce semi-finished needle tubes and capillary tubes for medical use. The insulin needles are one of most popular needle tubes from our company. Except the insulin needle, we can also provide other common needle tubes, like injection needle, mesotherapy needle, dental needle. blood lancet needle, hypodermic needle, etc..We produce what our clients require and can manufacture custom-made stainless steel needle tubes with various kinds of needle points according to the drawings.

How do Insulin Needles work?
Insulin needles work by injecting insulin from the pen device into the subcutaneous tissue below the skin through a small-bore stainless steel needle tube.

Usage:

Shorter needles (4-6mm) are recommended for subcutaneous injections, especially in children and lean adults, to avoid intramuscular injection.

Longer needles (8-12.7mm) may be used for individuals with more subcutaneous fat.

Selection Criteria:

Body Type: Longer needles for higher body fat; shorter for leaner individuals.

Age/Comfort: Children may prefer higher gauges.

Injection Site: Rotation is crucial to prevent lipodystrophy (fatty lumps).

Injection Technique:

-Angle: 90-degree angle for 4-6mm needles without pinching; 45-degree or pinch technique for longer needles.

-Best Practices: Avoid reusing needles to prevent infection, dullness, and dosing inaccuracies.

Main Sizes:

OD OD Range ID Min.(MM)
Gauge Norminal(MM) Min. Max. RW TW ETW
32G 0.23 0.229 0.241 0.089 0.105 0.125
31G 0.25 0.254 0.267 0.114 0.125 0.146
30G 0.30 0.298 0.320 0.133 0.165 0.190
29G 0.33 0.324 0.351 0.133 0.190 0.240
28G 0.36 0.349 0.370 0.133 0.190 -

32G 0.23MM Insulin Needle , Tri Bevelled Injection Needle Tube For Diabetes Management
