ASTM B564 N10276 Hastelloy C276 Weld Neck Flange RF FF ASME B16.5
ASTM B564 N10276 Hastelloy C276 Weld Neck Flange RF FF ASME B16.5
ASTM B564 N10276 Hastelloy C276 Weld Neck Flange RF FF ASME B16.5
ASTM B564 N10276 Hastelloy C276 Weld Neck Flange RF FF ASME B16.5
ASTM B564 N10276 Hastelloy C276 Weld Neck Flange RF FF ASME B16.5
ASTM B564 N10276 Hastelloy C276 Weld Neck Flange RF FF ASME B16.5
ASTM B564 N10276 Hastelloy C276 Weld Neck Flange RF FF ASME B16.5
ASTM B564 N10276 Hastelloy C276 Weld Neck Flange RF FF ASME B16.5
Specifications
Brand Name :
YUHONG
Model Number :
ASTM B564 N10276
Certification :
ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2008
Place of Origin :
CHINA
MOQ :
500KGS
Price :
Negotiable
Payment Terms :
L/C, T/T
Supply Ability :
1500 tons per month
Delivery Time :
15-30days
Packaging Details :
Plywooden Case /Iron Case
Standard :
ASTM B564
Grade :
N10276
Type :
Weld Neck
Pressure Class :
Class 150/300/600/900/1500/2500
Face Type :
Raised Face (RF) / Flat Face (FF)
Dimensions :
ASME B16.5
Description

ASTM B564 N10276 (Hastelloy C276) Nickel Alloy Weld Neck Flange RF/FF Corrosion Resistant for Power Plants

​​YUHONG GROUP​​ specializes in manufacturing high-performance nickel alloy flanges for critical industrial applications. Our ASTM B564 N10276 (Hastelloy C276) Weld Neck Flanges are engineered for power plants and harsh chemical environments, combining 30+ years of metallurgical expertise with full ASME/EN certification.

Chemical Requirements for Low Carbon Nickel-Molybdenum-Chromium Alloy UNS N010276

​​Element​​ ​​Nickel ​ ​​Iron ​ ​​Manganese​ ​​Carbon​ ​​Silicon​ ​​Sulfur​ ​​Chromium​ ​​Molybdenum​ ​​Phosphorus​ ​​Tungsten​ ​​Cobalt​ ​​Vanadium​
​​UNS N10276 Balance 4.0–7.0 ≤1.0 ≤0.010 ≤0.08 ≤0.03 14.5–16.5 15.0–17.0 ≤0.04 3.0–4.5 ≤2.5 ≤0.35

Test Types and Standards Summary​

​​Test Type​​ ​​Standard Method​​
​​Chemical Analysis​​ ASTM E76, E350, E1473
​​Tensile Testing​​ ASTM E8
​​Grain Size Measurement​​ ASTM E112
​​Rounding of Test Results​​ ASTM E29

​​Mechanical Properties of UNS N10276 (Solution Annealed)​

Property Value
​​Material & Condition​​ Low-carbon nickel-chromium-molybdenum alloy, solution annealed
​​Maximum Section Thickness​​ Not specified (typical for standard forms)
​​Tensile Strength, min​​ 100 ksi (690 MPa)
​​Yield Strength (0.2% offset), min​​ 41 ksi (283 MPa)
​​Elongation (2" or 50mm or 4D), min​​ 40%

Typical Service:​​

  • Flue gas desulfurization systems
  • Seawater cooling pipelines
  • High-temperature steam lines
