Specifications
Brand Name :
YUHONG
Model Number :
ASME SA269 TP321
Certification :
ISO, SGS, BV, ISO & SGS, ISO/CE/SGS
Place of Origin :
CHINA
MOQ :
100 KGS
Price :
NEGOTIABLE
Payment Terms :
T/T, L/C, Western Union
Supply Ability :
1500 Tons Per Month
Delivery Time :
5-80 days
Packaging Details :
Ply-wooden Case /Iron Case/ Bundle with plastic Cap
Steel grade :
321
Type :
Welded steel tube
Standard :
ASTM, AISI, GB, DIN, JIS
Length :
3000mm-6000mm, 6 Meters or customized, 18000max., 11.8m or as required., 8m
Thickness :
0.4-30mm, 1.0mm, 0.6mm-2500mm, 1mm-60mm, 0.6-25 mm
Technique :
Cold Rolled Hot Rolled, Cold Drawn, Extrusion, Cold Drawn/Cold Rolling or Both of them
Product name :
Stainless Steel Pipe, 304 304L 316 316L 321 310S Stainless Steel Welded/Seamless Tube, Factory Direct Sales Stainless Steel Pipe For Electric Heating Element, Seamless stainless Steel Pipe/Tube
Outer diameter :
6-630mm, Customized, 6-762mm, 6-860mm;, 6mm-630mm
Surface :
Annealing, 8K, Polishing or Unpolishing, Morror/Satin
Finish :
Brush Polish, Cold drawn, Pickled, Bright Annealed or Un Annealed, Bright
Description

ASTM A269 / ASME SA269 TP321Stainless Steel Welded Tube For Electro Thermal

Overview

ASTM A269/ASME SA269 TP321 welded stainless steel pipe is a corrosion-resistant piping solution based on titanium-stabilized austenitic stainless steel. It offers significant cost advantages in low- to medium-pressure, moderately corrosive environments. Strict weld quality and surface treatment level are crucial during selection, ensuring compatibility with high-temperature chloride environments. It is a cost-effective choice for industries such as chemical, food, and pharmaceuticals.

TP321 welded stainless steel pipe's core value in the electric heating industry lies in its ability to replace seamless pipe at a 30%-50% cost advantage while meeting the oxidation and corrosion resistance requirements of medium- and high-temperature applications. Its reliability has been proven in applications such as resistance sheaths, hot air ducts, and electrode boilers.

In the electric heating industry, small-diameter stainless steel welded pipe (such as ASTM A269 TP321) is advantageous due to its adaptability (compactly encapsulating the heating element, with diameters ranging from 6 to 25 mm), lower mass production costs compared to seamless pipe, and comparable performance. Its thin-wall design improves thermal response, and its austenitic stainless steel resistance to oxidation and corrosion at temperatures up to 800°C is also excellent.

SA 269 TP 321 Welded Tubes Mechanical Properties

Grade Yield Strength 0.2% Proof (MPa) minimum Tensile Strength (MPa) minimum Elongation (% in 50 milimeter) minimum Hardness
Rockwell B (HR B) maximum Brinell (HB) maximum
321 205 515 40 95 217
321H 205 515 40 95 217

ASTM A269 Grade TP321 ERW Tubes Equivalent

Grade UNS No Old British Euronorm Swedish SS Japanese JIS
BS En No Name
321 S32100 321S31 58B, 58C 1.4541 X6CrNiTi18-10 2337 SUS 321
321H S32109 321S51 – 1.4878 X10CrNiTi18-10 – SUS 321H

SA 269 Grade TP321 Coil Tubing Physical Properties

Grade Elastic Modulus (GPa) Density (kg/m3) Thermal Conductivity (W/m.K) Mean Coefficient of Thermal Expansion (m/m/0C)
at 5000C at 1000C 0-3150C 0-1000C 0-5380C
321 193 8027 22.2 16.1 17.2 16.6 18.6

Application:

1. Heating element sheaths. Encapsulated resistance wire/PTC heaters

2. High-temperature fluid pipelines. Thermal oil/electrode boiler pipelines

3. Precision heat exchange systems. Semiconductor equipment gas pipelines, micro thermal probes

4. Hot air circulation ducts. Electric hot air furnaces, drying line ducts
