Specifications
Brand Name :
YUHONG
Model Number :
A182 F11 CL.2
Certification :
ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2015
Place of Origin :
China
MOQ :
500KGS
Price :
NEGOTIABLE
Payment Terms :
L/C, T/T
Supply Ability :
According To Client's Request
Delivery Time :
10-90 Days
Packaging Details :
Ply-wooden Case /Iron Case/ Bundle with plastic Cap
Standard :
ASTM A182
Material :
Carbon Steel
Material Grades :
F11 CL.2
Size :
Customizable
Type :
Nozzle
Drawing :
Customizable
Description

ASME SA105N carbon Steel Self Reinforced Nozzle For High Pressure Vessels And Piping Systems


The ASTM A182 F11 Class 2 self-reinforced nozzle is a forged inlet/outlet connection fitting made from chromium-molybdenum alloy steel. This material is normalized and tempered (Grade 2) to achieve a specific strength level suitable for high-temperature and high-pressure applications. Crucially, it is designed and forged to have an integrally thickened wall at the base, eliminating the need for a separate reinforcement pad when welding to the pipe or vessel.

F11 is a chromium-molybdenum (Cr-Mo) alloy steel. Grade 2 is the most commonly used grade for F11 nozzles and fittings, offering an excellent balance of strength, ductility, and toughness for typical high-temperature and high-pressure applications.

A nozzle is a pipe fitting or vessel accessory used to provide an inlet/outlet connection for fluid flow. Common types include weld-on nozzles, socket-type nozzles, threaded nozzles, and Nippleite nozzles. Nozzles are typically welded to the pipe or pressure vessel shell/head.

Self-reinforced nozzles are forged with additional wall thickness in the area where they connect to the operating pipe or vessel wall. This integral thickening provides the necessary reinforcement to the nozzle body itself.

Chemical Composition

Grade Symbol UNS Number Alloy Elements Composition %
F11 Class 2 K11572 1.25% chromium,
0.5% molybdenum		 Carbon 0.10 - 0.20
Manganese 0.30 - 0.80
Phosphorus 0.040 max
Sulfur 0.040 max
Silicon 0.50 - 1.00
Chromium 1.00 - 1.50
Molybdenum 0.44 - 0.65

Mechanical Properties

Property Value
Tensile Strength, min, ksi [MPa] 70 [485]
Yield Strength, min, ksi [MPa] 40 [275]
Elongation in 2 in. [50mm] or 4D, min, % 20
Reduction or Area, min, % 30
Brinell Hardness Number, HBW 143-207

Application

High-temperature, high-pressure piping systems in power generation (fossil fuel, nuclear).

Refineries and petrochemical plants.

Process piping handling steam, hydrocarbons, or other demanding fluids.

Pressure vessels requiring reliable, high-integrity connections.
