ASTM A335 P9 Ferritic Alloy Steel Pipe For High Temperature
ASTM A335 P9 Ferritic Alloy Steel Pipe For High Temperature
ASTM A335 P9 Ferritic Alloy Steel Pipe For High Temperature
ASTM A335 P9 Ferritic Alloy Steel Pipe For High Temperature
ASTM A335 P9 Ferritic Alloy Steel Pipe For High Temperature
ASTM A335 P9 Ferritic Alloy Steel Pipe For High Temperature
ASTM A335 P9 Ferritic Alloy Steel Pipe For High Temperature
ASTM A335 P9 Ferritic Alloy Steel Pipe For High Temperature
Specifications
Brand Name :
YUHONG
Model Number :
ASTM A335 P9
Certification :
ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2008
Place of Origin :
CHINA
MOQ :
100 KGS
Price :
Negotiable
Payment Terms :
T/T, L/C AT SIGHT
Supply Ability :
1500 tons / Month
Delivery Time :
5-80 Days
Packaging Details :
Ply-wooden Case /Iron Case/ Bundle with plastic Cap
Standard :
ASTM A335 Alloy Steel Pipe Standard
Material :
P9
Type :
Seamless Alloy Steel Pipe
Technique :
Hot Rolled
Surface :
Black Painting
Application :
Boiler/Heat Exchanger/Oil&Gas
Description

ASTM A335 P9 Ferritic Alloy Steel Pipe For High Temperature

ASTM A335 P9 is a standard specification for seamless ferritic alloy steel pipe for high temperature applications. The alloy steel pipe is commonly used in power plants, refineries, and other industrial applications under high temperature and pressure conditions.

ASTM A335 P9 seamless alloy steel pipe is made of a combination of chromium and molybdenum, which provides excellent corrosion resistance and high temperature strength. It is available in a variety of sizes and specifications to meet different application needs.

Its high temperature resistance: It can withstand temperatures up to 600°C, making it ideal for high temperature applications.

The alloy composition of the pipe provides excellent corrosion resistance, ensuring long-lasting durability in harsh environments.

ASTM A335 Gr P9 Composition

C, % Mn, % P, % S, % Si, % Cr, % Mo, %
0.015 max 0.30-0.60 0.025 max 0.025 max 0.50 max 4.00-6.00 0.45-0.65

ASTM A335 P9 Properties

Tensile Strength, MPa Yield Strength, MPa Elongation, %
415 min 205 min 30 min

Heat Treatment Requirements

P5, P9, P11, and P22
Grade Heat Treatment Type Normalizing Temperature Range F [C] Subcritical Annealing
or Tempering
Temperature Range F
[C]
ASTM A335 P5 Pipe(b,c) Full or Isothermal Anneal
Normalize and Temper ***** 1250 [675]
Subcritical Anneal (P5c only) ***** 1325 - 1375 [715 - 745]
ASTM A335 P9 Pipe Full or Isothermal Anneal
Normalize and Temper ***** 1250 [675]
ASTM A335 P11 Pipe Full or Isothermal Anneal
Normalize and Temper ***** 1200 [650]
ASTM A335 P22 Pipe Full or Isothermal Anneal
Normalize and Temper ***** 1250 [675]
ASTM A335 P91 Pipe Normalize and Temper 1900-1975 [1040 - 1080] 1350-1470 [730 - 800]
Quench and Temper 1900-1975 [1040 - 1080] 1350-1470 [730 - 800]

Tensile Requirements

Seamless
Alloy Steel ASTM A335/SA335 P-5 Pipe Alloy Steel ASTM A335/SA335 P-9 Pipe Alloy Steel ASTM A335/SA335 P-11 Pipe Alloy Steel ASTM A335/SA335 P-22 Pipe Alloy Steel ASTM A335/SA335 P-91 Pipe
Tensile Strength, min., psi
ksi 60 60 60 60 85
MPa 415 415 415 415 585
Yield Strength, min., psi
ksi 30 30 30 30 60
MPa 205 205 205 205 415

ASTM A335 Gr P9 Equivalent Material

ASTM ASME JIS G 3458 UNS BS DIN ISO ABS NK LRS
A335 P9 SA335 P9 STPA 26 S50400 3604 P1 629-470 2604 II TS38

Yuhogn Group Chrome-Moly Alloy Steel Products
Seamless Pipe Seamless Tube Froged Flange /Fitting Butt Weld Fitting
Standard Grade Standard Grade Standard Grade Standard Grade
ASTM A335 ASME SA335 P1 ASTM A213 ASME SA213 ASTM A199 ASME SA199 T1 ASTM A182 ASME SA182 F1 ASTM A234 ASME SA234 WP1
ASTM A335 ASME SA335 P11 ASTM A213 ASME SA213 ASTM A199 ASME SA199 T11 ASTM A182 ASME SA182 F11 ASTM A234 ASME SA234 WP11
ASTM A335 ASME SA335 P12 ASTM A213 ASME SA213 ASTM A199 ASME SA199 T12 ASTM A182 ASME SA182 F12 ASTM A234 ASME SA234 WP12
ASTM A335 ASME SA335 P22 ASTM A213 ASME SA213 ASTM A199 ASME SA199 T22 ASTM A182 ASME SA182 F22 ASTM A234 ASME SA234 WP22
ASTM A335 ASME SA335 P23 ASTM A213 ASME SA213 ASTM A199 ASME SA199 T23 ASTM A182 ASME SA182 F23 ASTM A234 ASME SA234 WP23
ASTM A335 ASME SA335 P5 ASTM A213 ASME SA213 ASTM A199 ASME SA199 T5 ASTM A182 ASME SA182 F5 ASTM A234 ASME SA234 WP5
ASTM A335 ASME SA335 P5b ASTM A213 ASME SA213 ASTM A199 ASME SA199 T5b ASTM A182 ASME SA182 F5a ASTM A234 ASME SA234 WP9
ASTM A335 ASME SA335 P5c ASTM A213 ASME SA213 ASTM A199 ASME SA199 T5c ASTM A182 ASME SA182 F9 ASTM A234 ASME SA234 WP91
ASTM A335 ASME SA335 P9 ASTM A213 ASME SA213 ASTM A199 ASME SA199 T9 ASTM A182 ASME SA182 F91 ASTM A234 ASME SA234 WP92
ASTM A335 ASME SA335 P91 ASTM A213 ASME SA213 ASTM A199 ASME SA199 T91 ASTM A182 ASME SA182 F92 　 　 　
ASTM A335 ASME SA335 P92 ASTM A213 ASME SA213 ASTM A199 ASME SA199 T92 　 　 　 　 　 　

Application

  • Off-Shore Oil Drilling Companies
  • Condensers
  • Heat exchangers
  • Power Generation
  • Petrochemicals
  • Gas Processing
  • Specialty Chemicals
  • Pharmaceuticals
  • Pharmaceutical Equipment
  • Chemical Equipment
  • Sea Water Equipment
  • Pulp and Paper Industry


ASTM A335 P9 Ferritic Alloy Steel Pipe For High Temperature
