ASTM A105 Carbon Steel Series B Weldneck Flange B16.47 For Piping
ASTM A105 Carbon Steel Series B Weldneck Flange B16.47 For Piping
ASTM A105 Carbon Steel Series B Weldneck Flange B16.47 For Piping
ASTM A105 Carbon Steel Series B Weldneck Flange B16.47 For Piping
ASTM A105 Carbon Steel Series B Weldneck Flange B16.47 For Piping
ASTM A105 Carbon Steel Series B Weldneck Flange B16.47 For Piping
ASTM A105 Carbon Steel Series B Weldneck Flange B16.47 For Piping
ASTM A105 Carbon Steel Series B Weldneck Flange B16.47 For Piping
Specifications
Brand Name :
YUHONG
Model Number :
ASTM A105 A105
Certification :
ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2008
Place of Origin :
CHINA
MOQ :
500KGS
Price :
Negotiable
Payment Terms :
L/C, T/T
Supply Ability :
1500 tons per month
Delivery Time :
5-8days
Packaging Details :
Plywooden Case /Iron Case
Standard :
ASTM A105
Grade :
A105
Type :
Weldneck
Class :
#150, #300, #400, #600, #900
Application :
Piping Application
Hydrostatic Test :
ASTM A961/A961M
Description

ASTM A105 Carbon Steel Series B Weldneck Flange B16.47 for Piping Applications

With 30 years of experience in the piping components industry, Yuhong specializes in manufacturing ASTM A105 carbon steel Series B weldneck flanges conforming to B16.47, tailored for diverse piping applications. Having exported to 85 countries, the company has built a solid reputation worldwide, leveraging reliable quality and professional services to stand out in the global piping components market.

ASTM A105 Carbon Steel Series B Weldneck Flange Chemical Requirements

Element

Carbon

Manganese

Phosphorus

Sulfur

Silicon

Copper

Nickel

Chromium

Molybdenum

Vanadium

Composition, %

0.35 max

0.60 - 1.05

0.035 max

0.040 max

0.10 - 0.35

0.40 max

0.40 max

0.30 max

0.12 max

0.08 max

ASTM A105 Carbon Steel Series B Weldneck Flange Mechanical Requirements

Tensile strength, min, ksi [MPa]

70 [485]

Yield strength, min, ksi [MPa]

36 [250]

Hardness, HBW, max

197
Computed Minimum Values

Wall Thickness

Elongation in 2 in. or 50 mm, min, %

in.

mm

5/16 (0.312)

7.9

30

9/32 (0.281)

7.1

28.5

1/4 (0.250)

6.4

27

7/32 (0.219)

5.6

25.5

3/16 (0.188)

4.8

24

5/32 (0.156)

4

22.5

1/8 (0.125)

3.2

21

3/32 (0.094)

2.4

19.5

1/16 (0.062)

1.6

18

ASTM A105 Carbon Steel Series B Weldneck Flange B16.47 for Piping Applications

  1. Energy Sector

    • Used in oil & gas exploration, refining, and power generation, handling high - pressure fluids in pipelines.

  2. Petrochemical Industry

    • Ideal for petrochemical processes, connecting pipelines that transport chemicals, solvents, and petroleum products.

  3. Infrastructure and Construction

    • Applied in building HVAC, water supply, and drainage systems, as well as in bridge and tunnel pipelines.

  4. Mechanical and General Industrial Applications

    • Connects pipelines in industrial machinery, sewage treatment, and equipment like pumps and boilers.

ASTM A105 Carbon Steel Series B Weldneck Flange B16.47 For Piping
