Copper Alloy Tube JIS H 3330 C1220T Copper Nickel Seamless Condenser Tubes
Copper Alloy Tube JIS H 3330 C1220T Copper Nickel Seamless Condenser Tubes
Copper Alloy Tube JIS H 3330 C1220T Copper Nickel Seamless Condenser Tubes
Copper Alloy Tube JIS H 3330 C1220T Copper Nickel Seamless Condenser Tubes
Copper Alloy Tube JIS H 3330 C1220T Copper Nickel Seamless Condenser Tubes
Copper Alloy Tube JIS H 3330 C1220T Copper Nickel Seamless Condenser Tubes
Copper Alloy Tube JIS H 3330 C1220T Copper Nickel Seamless Condenser Tubes
Copper Alloy Tube JIS H 3330 C1220T Copper Nickel Seamless Condenser Tubes
Specifications
Brand Name :
YUHONG
Model Number :
C1220T,C1220TS
Certification :
ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2008
Place of Origin :
CHINA
MOQ :
100KGS
Payment Terms :
L/C, T/T
Delivery Time :
7DAYS
Packaging Details :
PLYWOOD CASE,BUNDLE,PALLET
MATERIAL :
C1220T,C1220TS
STANDARD :
JIS H 3330
OD :
12.7MM,19.05MM,25.4MM....
WT :
0.89MM,1.2MM,1.5MM...
STATUS :
O,OL,1/2H,H
TEST :
ET, HT, Flattening Test,Expansion Test, Mercurous Nitrate Test; Ammonia Vapor Test; Chemical Analysis; Microscopical Examination,Tension Testing.
Description
Copper Alloy Tube JIS H 3330 C1220T Copper Nickel Seamless Condenser Tubes

What is JIS H 3330 C1220T tube?

JIS H 3330 C1220T refers to a phosphorus-deoxidized copper tube standard specified by the Japanese Industrial Standards (JIS).
Key Features of JIS H 3330 C1220T Tube:
1. Material:
- C1220 (Phosphorus-Deoxidized Copper, DHP Copper)
- Contains a small amount of phosphorus (0.015–0.040%) for deoxidation, improving weldability and resistance to embrittlement.
- High thermal and electrical conductivity (though slightly lower than pure copper due to phosphorus content).
- Excellent corrosion resistance, especially in water and steam applications.
Grade Chemical Composition% Tensile Strength
Cu P N/mm2
C1220T 99.9 0.015 315
0.040
2. Standard:
- JIS H 3330 covers seamless copper and copper alloy tubes for general piping.
3. Applications:
- Plumbing & HVAC systems (water supply, heating, refrigeration).
- Gas distribution, medical gas systems, and industrial piping.
- Often used where brazing or welding** is required.
4. Comparable Standards:
- ASTM B68 (C12200) – U.S. equivalent.
- EN 1057 (CW024A) – European equivalent.

What is the advantage of JIS H 3330 C1220T tube?

  1. High Conductivity: C1220 copper tubes offer excellent electrical conductivity, making them ideal for electrical and electronic applications.
  2. Thermal Conductivity: These tubes have superior thermal conductivity, facilitating efficient heat transfer in heating, cooling, and refrigeration systems.
  3. Corrosion Resistance: C1220 copper exhibits excellent corrosion resistance, ensuring durability and longevity in various environments.
  4. Ease of Fabrication: C1220 copper is easily formable and weldable, allowing for seamless tube production and customization to meet specific requirements.

Dimensional Range


Outer Diameter - 4.00 to 22.00 mm
Wall Thickness - Between 0.15mm and 1.50 mm
Length upto 6 mtrs
End Applications

Heat Exchangers, Oil Coolers, Radiators, High Capacity Power Plants, Ship Building & Ship Repairs, Condensers, Offshore Oil rigs, Distiller Tubes, Evaporators, Ferrules etc.
