Specifications
Brand Name :
YUHONG
Model Number :
ASTM A179, ASME SA179,ASTM A210 GR.A
Certification :
ISO9001-2008, API 5L, API 5CT
Place of Origin :
CHINA
MOQ :
100KGS
Payment Terms :
L/C, T/T
Delivery Time :
7DAYS
Packaging Details :
PLYWOOD CASE,BUNDLE,WOVEN BAG
Standard :
ASTM A179,ASME SA179
Material :
A179
Length :
6000MM,6096MM,SRL,DRL
OD :
3/4" (19.05), 1"(25.4) , 1-1/4"(31.75), 1-1/2"(38.1), 2" (50.8), 2-1/2"(63.5) , 3" (76.2)
Description

ASTM A179 Carbon Steel Seamless Boiler Tube for Heat Exchangers and Condensers,A210 A1

ASTM A179 covers minimum-wall thickness, seamless cold-drawn low-carbon steel tubes for tubular, heat exchanger, condensers, and other heat transfer services. seamless ASTM A 179 steel tube is supplied and produced by cold drawning method. Chemical composition contains carbon, manganese, phosphorus, and sulfur.

Application: For high, middle, low pressure boiler and pressure purpose

Production Standard, Grade, Steel No:

ASTM A179

ASTM A192

ASTM A210 GradeA-1, C

Chemical Composition,

Material Chemical Composition(%)
C Si Mn P S
ASTM A179 0.06-0.18 ≤ 0.25 0.27-0.63 ≤0.035 ≤0.035

Delivery Condition:Annealed, Normalized, Normalized and Tempered

Mechanical Propertie,

Grade ASTM A179
Tensile Strength(MPa) ≥325
Yield Strength(MPa) ≥180
Elongation,% ≥35
Hardness, HRB ≤72

Inspection and Test:

Chemical Composition Inspection, Mechanical Properties Test(Tensile Strength,Yield Strength,

Elongation, Flaring, Flattening, Bending, Hardness, Impact Test), Surface and Dimension Test,No-destructive Test, Hydrostatic Test.

Tube Sizes for Heat Exchangers & Condensers & Boiler
Outside Diameter BWG
25 22 20 18 16 14 12 10
Wall Thickness mm
0.508 0.71 0.89 1.24 1.65 2.11 2.77 3.40
mm inch Weight kg/m
6.35 1/4 0.081 0.109 0.133 0.174 0.212
9.53 3/8 0.126 0.157 0.193 0.257 0.356 0.429
12.7 1/2 0.214 0.263 0.356 0.457 0.612 0.754
15.88 5/8 0.271 0.334 0.455 0.588 0.796 0.995
19.05 3/4 0.327 0.405 0.553 0.729 0.895 1.236
25.4 1 0.44 0.546 0.75 0.981 1.234 1.574 2.05
31.75 1 1/4 0.554 0.688 0.947 1.244 1.574 2.014 2.641
38.1 1 1/2 0.667 0.832 1.144 1.514 1.904 2.454 3.233
44.5 1 3/4 1.342 1.774 2.244 2.894 3.5
50.8 2 1.549 2.034 2.574 3.334 4.03
63.5 2 1/2 1.949 2.554 3.244 4.214 5.13
76.2 3 2.345 3.084 3.914 5.094 6.19
88.9 3 1/2 2.729 3.609 4.584 5.974 7.27
101.6 4 4.134 5.254 6.854 8.35
114.3 4 1/2 4.654 5.924 7.734 9.43
Form of Tube: Straight & U-bend & Finned & Coiled
Stainless Steel Tube: A/SA213, A/SA249, A/SA268, A/SA269, A/SA789, EN10216-5, A/SA688, B/SB163, JIS-G3463, GOST9941-81.

Carbon &Alloy Steel Tube: A/SA178, A/SA179, A/SA192,A/SA209, A/SA210, A/SA213, A.SA214
