Specifications
Brand Name :
YUHONG
Model Number :
ASTM B111 C12200
Certification :
ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2008
Place of Origin :
CHINA
MOQ :
1 PC
Price :
Negotiable
Payment Terms :
T/T,L/C
Supply Ability :
1000 Tons/Month
Delivery Time :
7 Days
Packaging Details :
Wooden Cases
Standard :
ASTM B111, GB/T 1527-2006, JIS H3300
Material Grade :
C12200 Copper Alloy (Red Copper), Customizable according to requirements
Product Type :
Seamless Tube (Smls), Straight Type; U-bend, Coiled Type optional
Pressure Class :
Class 150, 300; ≤16MPa (Working Pressure), Customizable
Size Range :
OD: 6-168mm, Wall Thickness: 0.8-10mm; Length: 1-12m, Customizable
Surface Treatment :
Polishing, Pickling & Passivated, Anti-tarnish Coating, Natural Oxide Film
Description

ASTM B111 C12200 Seamless (Smls) Tube, High-Quality Copper Alloy Seamless Tube

Brief Introduction

C12200 B111 Seamless (Smls) Tube is a high-performance copper alloy seamless tube, strictly manufactured in accordance with ASTM B111 standard (Standard Specification for Seamless Copper and Copper Alloy Tubes for Condensers and Heat Exchangers). It is mainly made of C12200 copper alloy (commonly known as red copper), which has excellent thermal conductivity, electrical conductivity, ductility and corrosion resistance. As a seamless-structured product, it eliminates the hidden dangers of leakage and structural instability caused by welding seams, ensuring high pressure resistance and long-term stable operation. The product integrates the superior performance of C12200 copper alloy and the structural advantages of seamless tubes, and is widely used in scenarios requiring efficient heat transfer, corrosion resistance and good electrical conductivity, such as condensers, heat exchangers, hydraulic systems and marine equipment.

Chemical Composition Analysis (wt%)

Material Grade Cu (Copper) Pb (Lead) ≤ Fe (Iron) ≤ Zn (Zinc) Others ≤
C12200 Copper Alloy (ASTM B111) 89.0-91.0 0.05 0.05 Remainder 0.10

Typical Mechanical Properties

Mechanical Property C12200 (Annealed) C12200 (Cold Drawn) ASTM B111 Requirement
Yield Strength (Rp0.2), MPa ≥70 ≥200 ≥65
Tensile Strength (Rm), MPa 220-280 350-420 ≥210
Elongation (A), % ≥35 ≥10 ≥30
Hardness (HB), Brinell ≤65 80-100 ≤70
Reduction of Area, % ≥60 ≥45 ≥55
Thermal Conductivity, W/(m·K) 370-380 360-370 ≥360

Available Tests

Test Type Standard
Chemical Composition Analysis (PMI) Spectrometer (XRF/OES), ASTM E1019, ASTM B111
Tensile & Impact Test ASTM E8/E8M, ASTM B111, Charpy V-Notch
Hardness Test ASTM E10 (Brinell), ASTM E18 (Rockwell), Vickers
Corrosion Resistance Test ASTM B117 (Salt Spray), Neutral Salt Spray Test, Corrosion Test in Acid/Alkali Medium
Non-Destructive Testing (NDT) Eddy Current Test, UT (Ultrasonic), MT (Magnetic Particle), PT (Liquid Penetrant)
Hydrostatic/Pneumatic Pressure Test ASTM B111, Pressure Test for Seamless Copper Tubes
Dimensional & Visual Inspection ASTM B111, CMM, Gauge Inspection, Surface Finish Test
Material Test Certificate (MTC) EN 10204 3.1/3.2, ASTM B111
Flattening & Flaring Test ASTM B111 (Standard for Seamless Copper and Copper Alloy Tubes)
Thermal Conductivity Test ASTM D5470, Thermal Conductivity Measurement Standard

Product Application Scope

Industry Field Typical Applications
Thermal Power & Heat Exchange Industry Power plant condensers, heat exchangers, boiler economizers, air preheaters, cooling water pipelines
Petrochemical & Chemical Industry Petroleum refining heat exchangers, chemical reaction kettle heat transfer tubes, corrosive medium transmission pipelines
Marine Industry Marine condensers, heat exchangers, ship hydraulic system pipelines, marine electrical conduction tubes
Refrigeration & Air Conditioning Industry Air conditioner evaporators, condensers, refrigeration unit heat exchange tubes, central air conditioning systems
Electrical & Electronic Industry Electrical conduction tubes, transformer cooling tubes, electronic equipment heat dissipation tubes, electrical cabinet bushing tubes
Other Fields Hydraulic transmission pipelines, medical equipment (non-toxic requirements), food processing equipment, architectural decoration tubes
