C12200/TP2 Phosphorus Deoxidized Copper Seamless Tube, 99.9% Cu for Heat Exchangers
C12200/TP2 Phosphorus Deoxidized Copper Seamless Tube, 99.9% Cu for Heat Exchangers
C12200/TP2 Phosphorus Deoxidized Copper Seamless Tube, 99.9% Cu for Heat Exchangers
C12200/TP2 Phosphorus Deoxidized Copper Seamless Tube, 99.9% Cu for Heat Exchangers
C12200/TP2 Phosphorus Deoxidized Copper Seamless Tube, 99.9% Cu for Heat Exchangers
C12200/TP2 Phosphorus Deoxidized Copper Seamless Tube, 99.9% Cu for Heat Exchangers
C12200/TP2 Phosphorus Deoxidized Copper Seamless Tube, 99.9% Cu for Heat Exchangers
C12200/TP2 Phosphorus Deoxidized Copper Seamless Tube, 99.9% Cu for Heat Exchangers
Specifications
Brand Name :
Yuhong Group
Model Number :
C12200
Certification :
Ply-wooden Case /Iron Case/ Bundle with plastic Cap
Place of Origin :
China
MOQ :
1000kgs
Price :
Negotiable
Payment Terms :
L/C, T/T,
Delivery Time :
7 days
Packaging Details :
Ply-wooden Case /Iron Case/ Bundle with plastic Cap
Supply Ability :
800 Tons/ month
Material :
C12200/C106/Cu-DH/C1220/TP2
Size :
3/8inch to 3inch
Temper designation :
O60, O50, H58
Shape :
Round
NDT :
Hydraulic test, Eddy current test
Application :
HVAC (heating, ventilation and air conditioning), refrigeration, plumbing, wiring and heat exchangers
Description

C12200/TP2 Phosphorus Deoxidized Copper Seamless Tube, 99.9% Cu for Heat Exchangers

Yuhong is a leading manufacturer and supplier of high-quality copper products. We focus on producing durable and efficient copper products that meet various global standards, including ASTM, JIS, DIN, and EN. Our C12200/TP2 copper seamless tubes are widely used in heat exchangers, condensers, and other thermal transfer systems across marine, power generation, and chemical industries.

C12200 Chemical Composition

Element Composition (%)
Copper (Cu)** 99.9 (min)
Phosphorus (P) 0.015 - 0.040
Other Impurities ≤ 0.03

Note: The high copper content ensures optimal thermal and electrical conductivity, while phosphorus eliminates oxygen, improving corrosion resistance and preventing hydrogen embrittlement.

Mechanical Properties

Property Annealed (O) Half-Hard (H55) Hard (H80)
Tensile Strength (MPa) 205 - 275 275 - 345 345 - 415
Yield Strength (MPa) 50 - 100 100 - 200 200+
Elongation (%) ≥ 40 15 - 30 ≤ 10
Hardness (HV) 40 - 60 80 - 110 110 - 150

Equivalent Standards Across Regions

The table below shows equivalent grades for C12200 under different international standards:

Standard Grade
ASTM (USA) C12200
JIS (Japan) TP2
EN (Europe) CW024A
DIN (Germany) SF-Cu
BS (UK) C106

Heat Treatment States and Explanations

C12200 tubes are available in multiple heat treatment states, each suited to specific applications:

  1. Annealed (O):

    • Fully soft for maximum ductility.
    • Suitable for bending, forming, and welding.
    • Commonly used in heat exchangers and condensers.

  2. Half-Hard (H55):

    • A balance between strength and ductility.
    • Ideal for applications requiring moderate mechanical strength and some flexibility.

  3. Hard (H80):

    • Maximum strength with minimal elongation.
    • Used in high-pressure systems and environments where wear resistance is critical.

Applications

1. Heat Exchangers and Condensers

2. Air Conditioning and Refrigeration Systems

3. Plumbing and Gas Distribution

4. Chemical Processing

5. Marine Applications
