Specifications
Product Name :
Alloy Steel Tee
High Light :
ASTM A234 WP11 Class 2 Pipe Fittings, Alloy Steel Equal Tee
Brand Name :
YUHONG
Delivery Time :
7 DAYS
Packaging Details :
Plwood case or Pallet
W.T. :
Schedule 10s - Schedule XXS
Place of Origin :
CHINA
Model Number :
ASTM A234 WP11 CL2 Alloy Steel Equal Tee
Specification :
ASTM A234, ASME SA234
O.D. :
1/8”NB to 48”NB
Application :
Power Generation, Oil & Gas, Chemical Processing, Pipeline
Payment Terms :
L/C, T/T
Type :
Equal Tee, Reducing Tee
Certification :
ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2008
Class :
Class 1, 2, 3
Surface :
Black Painting
Material :
WP11
MOQ :
1 PC
Description

ASME B16.9 ASTM A234 WP11-S CL2 Alloy Steel Equal Tee Buttweld Pipe Fittings​

The ASTM A234 WP11 CL2 Equal Tee is a CrMo alloy buttweld fitting designed for severe service. The CL2 designation ensures impact toughness (Charpy tested) and a strict normalized & tempered microstructure, making it superior to CL1 for critical applications involving thermal cycling or low ambient temperatures.

Manufacturing Process

  • Forming Methods: These tees are produced by seamless (extruded from pipe) or welded (with filler metal, then heat treated) methods. Seamless is preferred for high-pressure systems.

  • Hot Forming: The blank pipe is heated and shaped via hydraulic bulging or press forming. Branch outlets are drawn or extruded from the run.

  • Post-Form Heat Treatment: Mandatory for CL2. After forming, the tee is normalized + tempered to restore microstructure and impact properties. No cold forming is allowed without subsequent heat treatment.

ASTM A234 WP11 Alloy Steel Equal Tee BW Pipe Fittings Chemical Requirements

ASTM A234 WP11 C Mn Si S P Cr Mo
CL1 0.05-0.15 0.30-0.60 0.50-1.00 ≤0.03 ≤0.03 1.00-1.50

0.44-0.65
CL2, CL3 0.05-0.20 0.30-0.80 0.50-1.00 ≤0.04 ≤0.04 1.00-1.50 0.44-0.65

ASTM A234 WP11 Alloy Steel Equal Tee BW Pipe Fittings Mechanical Properties

ASTM A234 WP11

 Tensile Strength (Mpa)
CL1 60 (415)
CL2 70 (485)
CL3 75 (520)

*Note: Fittings of Grades WP1, WP11 Class 1, WP11 Class 2, WP11 Class 3, WP12 Class 1, WP12 Class 2, WP22 Class 1, WP22 Class 3, WP5, and WP9 shall be furnished in the annealed, isothermal-annealed, or normalized and tempered

condition. If normalized and tempered, the tempering temperature for WP11 Class 1, WP11 Class 2, WP11 Class 3, WP12
Class 1, and WP12 Class 2 shall not be less than 1150 °F [620°C]; for Grades WP5, WP9, WP22 Class 1, and WP22 Class 3 the tempering temperature shall not be less than 1250 °F [675°C].

Applications

  • Power Generation: Used in boiler systems, steam lines, and other high-temperature, high-pressure applications.
  • Oil and Gas Industry: Used in pipelines for transporting oil, natural gas, and other hydrocarbons.
  • Chemical Processing: Suitable for systems handling corrosive chemicals, where high strength and durability are required.
  • Water Treatment and Distribution: Used in municipal water systems and wastewater treatment plants.
