ASME SA268 TP430 S43000 Ferritic Stainless Steel Seamless Tube for Oil and Gas Industry
ASME SA268 TP430 S43000 Ferritic Stainless Steel Seamless Tube for Oil and Gas Industry
ASME SA268 TP430 S43000 Ferritic Stainless Steel Seamless Tube for Oil and Gas Industry
ASME SA268 TP430 S43000 Ferritic Stainless Steel Seamless Tube for Oil and Gas Industry
ASME SA268 TP430 S43000 Ferritic Stainless Steel Seamless Tube for Oil and Gas Industry
ASME SA268 TP430 S43000 Ferritic Stainless Steel Seamless Tube for Oil and Gas Industry
ASME SA268 TP430 S43000 Ferritic Stainless Steel Seamless Tube for Oil and Gas Industry
ASME SA268 TP430 S43000 Ferritic Stainless Steel Seamless Tube for Oil and Gas Industry
Specifications
Brand Name :
YUHONG SPECIAL STEEL
Model Number :
ASTM A268 TP430
Certification :
ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2008
Place of Origin :
CHINA
MOQ :
1000KGS
Price :
Negotiable
Payment Terms :
L/C, T/T
Supply Ability :
800Tons/ month
Delivery Time :
20-80 Days
Packaging Details :
Ply-wooden Case /Iron Case/ Bundle with plastic Cap
Standard :
ASME SA268
Grade :
TP430
Heat Treatment :
Pickled Surface
Application :
Oil and Gas Industry
Test :
Tension Test, Flaring Test, Hardness Test, Reverse Flattening Test, Hydrostatic Test, Nondestructive Electric Test, Intergranular Corrosion Test
Description

ASME SA268 TP430 S43000 Ferritic Stainless Steel Seamless Tube for Oil and Gas Industry

We are one of the largest manufacturers of stainless steel, duplex and alloy steel pipes in China. After more than 20 years of development, we have accumulated a large number of customers all over the world, and Yuhong products have won the praise of our customers.
ASME SA268 is a standard specification for seamless and welded tubes and pipes of ferritic and martensitic stainless steels for general purposes, in grades TP410, TP405, TP420, TP430, TP430Ti, TP403, TP409, TP444, TP439, and TP446 etc..

ASME SA268 TP430 Stainless Steel Seamless Tube Chemical Composition

Grade: TP410 TP430 TP439
UNS S41000 S43000 S43035
C, Max 0.15 0.12 0.07
Mn,Max 1 1 1
P, Max 0.04 0.04 0.04
S, Max 0.03 0.03 0.03
Si, Max 1 1 1
Ni … … 0.50max
Cr 11.5-13.5 16.0-18.0 17.00-19.00
Mo … … …
Al … … 0.15
Cu … … …
N … … 0.04
Ti … … 0.20+4(C+N)Min, 1.10max

ASME SA268 TP430 Stainless Steel Seamless Tube Mechanical Properties

Grade Tensile Strength, Min, Ksi [MPa] Yield Strength, Min, Ksi [MPa] ELONGATION. MIN, %
TP410 55 [380] 30 [205] 20
TP430 60 [415] 35 [240] 20
TP439 60 [415] 30 [205] 20

ASME SA268 TP430 Stainless Steel Seamless Tube Physical Properties

Density, g/cm3 (lb/in.3) 7.8 (0.28)
Melting point, °C (°F) 1425-1510 (2600-2750)
Specific heat capacity, J/kg · K (Btu/lb · °F) 460 (0.11) at 0-100 °C (32 to 212 °F)
Electrical resistivity, μΩ·m 0.60 at 20 ℃
430 stainless steel magnetic permeability 600-1100 (Approximate)
Elastic modulus (Modulus of elasticity), GPa (106 psi) 200 (29.0)
Thermal diffusivity, mm2/s 7.3
Thermal conductivity, W/m · K (Btu/ft · h · °F) 26.1 (15.1), at 100 ℃ (212 °F)
26.3 (15.2), at 500 ℃ (932 °F)
Coefficient of thermal expansion, μm/m · °C (μin./in. · °F) 10.4 (5.8), at 0-100 ℃ (32-212 °F)
11.0 (6.1), at 0-315 ℃ (32-600 °F)
11.4 (6.3), at 0-538 ℃ (32-1000 °F)

ASME SA268 TP430 Stainless Steel Seamless Tube Heat Treatment

  • Annealing: Recommended annealing treatment for 430 steel is 650 °C (1200°F).
  • Forging: Typical forging temperature for SS430 is 815-1120 °C (1500-2050 °F).

ASME SA268 TP430 Stainless Steel Seamless Tube Heat Resistance

Maximum service temperatures, °C (°F)
AISI Intermittent service Continuous service
430 870 (1600) 815 (1500)

ASME SA268 TP430 (S43000) Tubing in Oil & Gas Applications​, ​​​​Common Application Areas & Equipment:​​

  1. ​​Utility & Service Water Systems

  2. ​​Low-Pressure Instrumentation & Sensing Lines

  3. ​​Hydraulic Control Lines (Limited)

  4. ​​Vent & Drain Lines

  5. ​​Heat Exchanger Tubes (Limited & Specific)

  6. ​​Fuel Gas Piping (Conditional)

ASME SA268 TP430 S43000 Ferritic Stainless Steel Seamless Tube for Oil and Gas Industry
