DIN17660 CuZn20Al2 F39, UNS C68700 Seamless Aluminums Brass Tube For Heat Exchanger
DIN17660 CuZn20Al2 F39, UNS C68700 Seamless Aluminums Brass Tube For Heat Exchanger
DIN17660 CuZn20Al2 F39, UNS C68700 Seamless Aluminums Brass Tube For Heat Exchanger
DIN17660 CuZn20Al2 F39, UNS C68700 Seamless Aluminums Brass Tube For Heat Exchanger
DIN17660 CuZn20Al2 F39, UNS C68700 Seamless Aluminums Brass Tube For Heat Exchanger
DIN17660 CuZn20Al2 F39, UNS C68700 Seamless Aluminums Brass Tube For Heat Exchanger
DIN17660 CuZn20Al2 F39, UNS C68700 Seamless Aluminums Brass Tube For Heat Exchanger
DIN17660 CuZn20Al2 F39, UNS C68700 Seamless Aluminums Brass Tube For Heat Exchanger
Specifications
Brand Name :
YUHONG
Model Number :
DIN17660 CuZn20Al2 F39
Certification :
ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2015
Place of Origin :
China
MOQ :
500 KGS
Price :
Negotiable
Payment Terms :
T/T, L/C
Supply Ability :
According to Clients' Requirement
Delivery Time :
5 - 90 Work Days
Packaging Details :
Ply-Wooden Case / Iron Case / Bundle with Plastic Cap
Standard :
DIN17660, ASME SB111
Material Grade :
CuZn20Al2 F39, UNS C68700
Type :
Seamless
Outside diameter :
2mm~914mm
Wall thickness :
0.2mm~120mm
Length :
1-12m, or as required
Shape :
Round
Applications :
Heat Exchanger, Boiler, Petroleum, Condenser, Etc.
Description

DIN17660 CuZn20Al2 F39, UNS C68700 Seamless Aluminums Brass Tube For Heat Exchanger

DIN17660 CuZn20Al2 F39 seamless copper alloy aluminums brass tube is a specific type of alloy tube that is made from a specific alloy of steel. This alloy, known as CuZn20Al2, is a type of brass that is primarily composed of copper and zinc, with a small amount of aluminum added for additional strength and durability.

Brass is a mixture of copper and zinc with a homogeneous material structure. It is characterised by higher strength than copper, a high torsional and bending stability as well as a high corrosion resistance. Brass is widely used in various industrial applications such as machine equipment, power plant, construction, chemical industry.

Characteristics:

Good Thermal conductivity

Good Conductivity

Excellent Wear Resistance

Good Plasticity

Good Cold Bending Property

Easy To Welding And Machining

Strong Seawafer Corrosion Resistance

Equivalent Material:

GB/T8890 ASTM B111 BS2871 JIS H3300 DIN1785
HAL77-2 C68700 CZ110 C6870 CuZn20Al2

DIN17660 CuZn20Al2 F39, UNS C68700 Seamless Aluminums Brass Tube For Heat Exchanger

Chemical Composition:

Elements Composition, %
Cu, incl. Ag 76.0-79.0
Al 1.8-2.5
Pb 0.07 max
Fe 0.06 max
Zn Balance
Mn 0.02-0.06

Mechanical Properties:

Standard Grade DIN17660
CuZn20Al2
Condition F39
F34
Yield Strength [N/mm2] 150 - 230(F39)
120 - 180(F34)
Tensile Strength [N/mm2] 390 min.(F39)
340 min.(F34)
Elongation [%] 45 min.(F39)
55 min.(F34)

Applications:

Marine System

Automotive Industry

Construction Industry

Chemical Industry

Power Plants

Petrochemical Industry

Oil and Gas Industry

Heat Exchanger

Aerospace Industry

Refineries

Food Processing Industry

DIN17660 CuZn20Al2 F39, UNS C68700 Seamless Aluminums Brass Tube For Heat Exchanger
