T22 Alloy Steel Seamless Fin Tube 11Cr High Frequency Welding Type for Preheater
T22 Alloy Steel Seamless Fin Tube 11Cr High Frequency Welding Type for Preheater
T22 Alloy Steel Seamless Fin Tube 11Cr High Frequency Welding Type for Preheater
T22 Alloy Steel Seamless Fin Tube 11Cr High Frequency Welding Type for Preheater
T22 Alloy Steel Seamless Fin Tube 11Cr High Frequency Welding Type for Preheater
T22 Alloy Steel Seamless Fin Tube 11Cr High Frequency Welding Type for Preheater
T22 Alloy Steel Seamless Fin Tube 11Cr High Frequency Welding Type for Preheater
T22 Alloy Steel Seamless Fin Tube 11Cr High Frequency Welding Type for Preheater
Specifications
Brand Name :
YUHONG
Model Number :
ASTM A213, ASME SA213 , ASTM A179 , ASTM A192, ASTM A209 , ASTM A210
Certification :
ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2008
Place of Origin :
CHINA
MOQ :
50pcs
Price :
Negotiable
Payment Terms :
T/T, L/C
Supply Ability :
1500 tons per month
Delivery Time :
10days->
Packaging Details :
Ply-wooden Case /Iron Case/ Bundle with plastic Cap
Standard :
ASTM A213, ASME SA213 , ASTM A199, ASME SA199
Grade :
T1, T11, T12, T22, T23, T5, T9, T91, T92
Fin Type :
HFW Fin Tube, Solid Fin Tube
Packing :
Iron Case
Fin Height :
5-30MM
FPI :
3-25
Description

T22 Alloy Steel Seamless Fin Tube 11Cr High Frequency Welding Type for Preheater

  • ASTM A192 / A192M : Seamless Carbon Steel Boiler Tubes for High-Pressure Service
  • ASTM A210 / A210M : Seamless Medium-Carbon Steel Boiler and Superheater Tubes
  • ASTM A179 / A179M : Seamless Cold-Drawn Low-Carbon Steel Heat-Exchanger and Condenser Tubes
  • Tube Type:Seamless (Cold Drawn)
  • Ends:Plain ends or bevel ends.
  • Surface protection:black painting,anti-rust oil or varnish.

​​T22 Alloy Steel Seamless Fin Tube 11Cr High Frequency Welding Type Detail

General extrusion production capacity General specifications of Extruded Fin Tubes

Extrusion Facility: 10 finning machines.
Daily capacity up to 3000 meters.
Extruded fins type: solid plain and serrated.

Tube OD: 12mm min.~50.8mm(2'') max.
Tube Length: 18 meters max.
Fin Height: 16.5 mm max.
Fin Thickness: appr. 0.4mm/0.5mm/0.6mm
Fin Pitch: 1.5mm min.

T22 Alloy Steel Seamless Fin Tube 11Cr High Frequency Welding Type Applications

Power Industry

  • Boiler Air Preheaters
  • Recovers heat from 540℃~580℃ flue gas to preheat combustion air (150℃~300℃), boosting boiler efficiency.
  • T22 alloy resists sulfide corrosion; high-frequency welding ensures strong fin-tube bonding for low thermal resistance.

Petrochemical Industry

  • Process Gas Preheaters
  • Preheats reaction gases (up to 600℃) in catalytic processes, withstanding H₂S/CO₂ corrosion and 10~20MPa pressure.
  • Fins stay secure under high-flow conditions, maintaining efficient heat transfer.

Metallurgy Industry

  • Furnace Flue Gas Preheaters
  • Recovers 600℃~700℃ waste heat to preheat combustion air (300℃~450℃) for steelmaking furnaces.
  • Resists dust fouling; compact design fits industrial spaces, reducing energy consumption.

Key Advantages in Preheaters

FeatureBenefit
540℃~700℃ heat resistanceSustains high-temperature operation
High-frequency welded fins2~3x higher heat transfer vs. bare tubes
Corrosion/wear resistanceReduces maintenance in harsh flue gas

T22 Alloy Steel Seamless Fin Tube 11Cr High Frequency Welding Type Specifications

ItemsGeneral MaterialsPopular ASTM Materials
Core Tube Material

Any metallic materials, as carbon steel, low-alloy steel,
stainless steel, brass, copper,
cooper-nickel alloys, aluminum bronze, nickel alloys etc.

1. Carbon Steel: A179, A192,SA210 Gr A1/C,A106 Gr B
2. Stainless Steel: TP304/304L,TP316/TP316L/316Ti,
A789 S31803/S2205 etc...
3. Copper:UNS12200/UNS14200/UNS70600,
CuNi70/30,CuNi 90/10
4. Titanium: B338 Gr 2

Fins Material

1. Aluminum Alloy
2. Copper.

1. Aluminum(Alu.1100,Alu.1060,Alu.6063)
2. Copper.

All dimensions are in Inches and specification upon your requests.

Tube OD

Fin Height

Fin Thickness

Fins per Pitch(Density)

5/8

3/8,1/2

.015/.016/ .020

4, 5, 6, 7, 8, 9, 10, 11, 12

3/4

3/8,1/2,5/8

.015/.016/ .020

4, 5, 6, 7, 8, 9, 10, 11, 12

1

3/8,1/2,5/8

.015/.016/ .020

4, 5, 6, 7, 8, 9, 10, 11

1 1/4

3/8,1/2,5/8

.015/.016/ .020

4, 5, 6, 7, 8, 9, 10,

1 1/2

3/8,1/2,5/8

.015/.016/ .020

4, 5, 6, 7, 8, 9, 10, 11

1 3/4

3/8,1/2,5/8

.015/.016/ .020

4, 5, 6, 7, 8, 9, 10

2

3/8,1/2,5/8

.015/.016/ .020

4, 5, 6, 7, 8, 9, 10

Please email us for more information.

T22 Alloy Steel Seamless Fin Tube 11Cr High Frequency Welding Type Competitive Advantage

  • We have more than 10,000 square meters workshop, including 10 extrusion finning machines, daily extrusion capacity up to 3,000 Meters.
  • The extrusion finning machines are designed and assembled by ourselves and we can offer you finning machines, extrusion muff sleeves and all accessories (extrusion finning disks) etc...
  • DR-extruded bimetallic fin tubes maximum operating temperature: 300 degree. The transfer coefficient remains steady.
  • DR-extruded bimetallic fin tubes have stronger fins than other mechanical fins, like L, LL, KL, and G, so it is much easier to clean.
  • In application of high stress and corrosive condiction, DR-extruded bimetallic fin tubes provides an excellent technical and economical savings in comparsion to a costlier single alloy tube, as the use of costlier material is reduced to the min.

T22 Alloy Steel Seamless Fin Tube 11Cr High Frequency Welding Type for Preheater
