CARBNO STEEL HFW U TYPE FIN TUBE A106 GR.B FOR FIRE FURNACE ,FIRED HEATER ,CONVENCTION TUBE ,RADIANT TUBE
CARBNO STEEL HFW U TYPE FIN TUBE A106 GR.B FOR FIRE FURNACE ,FIRED HEATER ,CONVENCTION TUBE ,RADIANT TUBE
CARBNO STEEL HFW U TYPE FIN TUBE A106 GR.B FOR FIRE FURNACE ,FIRED HEATER ,CONVENCTION TUBE ,RADIANT TUBE
CARBNO STEEL HFW U TYPE FIN TUBE A106 GR.B FOR FIRE FURNACE ,FIRED HEATER ,CONVENCTION TUBE ,RADIANT TUBE
CARBNO STEEL HFW U TYPE FIN TUBE A106 GR.B FOR FIRE FURNACE ,FIRED HEATER ,CONVENCTION TUBE ,RADIANT TUBE
CARBNO STEEL HFW U TYPE FIN TUBE A106 GR.B FOR FIRE FURNACE ,FIRED HEATER ,CONVENCTION TUBE ,RADIANT TUBE
CARBNO STEEL HFW U TYPE FIN TUBE A106 GR.B FOR FIRE FURNACE ,FIRED HEATER ,CONVENCTION TUBE ,RADIANT TUBE
CARBNO STEEL HFW U TYPE FIN TUBE A106 GR.B FOR FIRE FURNACE ,FIRED HEATER ,CONVENCTION TUBE ,RADIANT TUBE
Specifications
Brand Name :
YUHONG
Model Number :
A106 GR.B+AL1010
Certification :
ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2008
Place of Origin :
CHINA
MOQ :
1PC
Price :
Negotiable
Payment Terms :
L/C, T/T
Supply Ability :
5000 tons / month
Delivery Time :
10-15 DAYS
Packaging Details :
ron/Ply Wooden Case
Standard :
ASME A106
Material Grade :
Gr.B
Type :
Seamless Tube , Coil Tube , Fin Tube
Application :
Fire Furnace, Fired Heater, Raffinate Heaters, Extract Heater, Refinery Furnace, Radiant Tube，Convection Coil， Convection Tube
NDT :
MT, ET, UT, HT, PT, PMI
Description

CARBNO STEEL HFW U TYPE FIN TUBE A106 GR.B FOR FIRE FURNACE ,FIRED HEATER ,CONVENCTION TUBE ,RADIANT TUBE

Yuhong Group supply a lot of Stainless Steel Seamless Pipe ( ASME SA213 / ASTM A213 , ASME A312/ ASTM A312,ASME SA376/ ASTM A376: TP304, TP304H, TP310H, TP310S, TP316L , TP316H , TP317L , TP321, TP321H, TP347, TP347H ) , Alloy Steel Seamless Pipe ( ASME SA213/ASTM A213, ASME SA335/ASTM A335: P1, P11, P12, P22, P23, P5, P9, P91, P92 , T1, T11, T12, T22, T23, T5, T9, T91, T92) , Carbon Steel Seamless Pipe to Fired Furance in oil refinary project .

Finned Tube

The high frequency fin tube produced by our company can be applied to boiler economizer, air preheater, chemical crystallizer, etc.The main products: high-frequency spiral resistance welding fin tube, stainless steel fin tube, double metal steel aluminum compound pipe, copper aluminum compound tube, cold and hot coil heat exchanger.

Description:

Standard ASTM A106 & Its equivalent ASME, DIN & EN standard
Base Tube Material Gr.A/B/C
Fin Material Carbon Steel
Base Tube O.D. 16-219mm
Fin Height 6-50mm
Fin Thickness 0.3-3.0mm
Fin Pitch As customer's request
Tube End Plain Ends, Beveled Ends
Bare End As customer's request
Weld Process GMAW
Production Capacity More than 5000 meters per day

Chemical Composition:

Grade C Mn P S Si Cr Cu Mo Ni V
A 0.25 max 0.27-0.93 0.035 max 0.035 max 0.10 min 0.40 max 0.40 max 0.15 max 0.40 max 0.08 max
B 0.30 max 0.29-1.06 0.035 max 0.035 max 0.10 min 0.40 max 0.40 max 0.15 max 0.40 max 0.08 max
C 0.35 max 0.29-1.06 0.035 max 0.035 max 0.10 min 0.40 max 0.40 max 0.15 max 0.40 max 0.08 max

Mechanical Properties:

Grade Tensile Strength, min, psi (MPa) Yield Strength,
min, psi (MPa)		 Elongation in 2 in.
or 50mm, min (%)		 Heat Treatment Temperature,
min, °F(°C)
Longitudinal Transverse
A 48000(330) 30000(205) 35 25 1200(650)
B 60000(415) 35000(240) 30 16.5 1200(650)
C 70000(485) 40000(275) 30 16.5 1200(650)

Application :

Products are widely used in petrochemical, electric power, metallurgy, building materials, coating, boiler, heat carrier air conditioning, refrigeration, heat conduction oil furnace, pressure vessel, dryer, intelligent greenhouse, livestock farming, fin tube economizer and air preheater, etc.

CARBNO STEEL HFW U TYPE FIN TUBE A106 GR.B FOR FIRE FURNACE ,FIRED HEATER ,CONVENCTION TUBE ,RADIANT TUBE
