ASTM B111 C70600 Copper Nickel Low Finned Tube O61 For Oil Cooler
ASTM B111 C70600 Copper Nickel Low Finned Tube O61 For Oil Cooler
ASTM B111 C70600 Copper Nickel Low Finned Tube O61 For Oil Cooler
ASTM B111 C70600 Copper Nickel Low Finned Tube O61 For Oil Cooler
ASTM B111 C70600 Copper Nickel Low Finned Tube O61 For Oil Cooler
ASTM B111 C70600 Copper Nickel Low Finned Tube O61 For Oil Cooler
ASTM B111 C70600 Copper Nickel Low Finned Tube O61 For Oil Cooler
ASTM B111 C70600 Copper Nickel Low Finned Tube O61 For Oil Cooler
Specifications
Brand Name :
Yuhong Finned Tube
Model Number :
L Type Fin Tube,Tension Wound L Type Fin Tube
Certification :
ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2008
Place of Origin :
China
MOQ :
500 Kgs
Price :
Negotiable
Payment Terms :
T/T, L/C
Supply Ability :
1500 tons per month
Delivery Time :
10 - 20 days
Packaging Details :
Ply-wooden Case /Iron Case/ Bundle with plastic Cap etc.
Standard :
ASTM B111
Copper-Nickel :
C70600, C71500,C71640, C70400
Tube OD :
12.7 mm~25.4mm
Fin Thickness :
Appr. 0.3mm
Fin Height :
1.2 mm ~2.77mm
Tube Length :
18 meters max.
Fin pitch :
30 FPI /28 FPI/ 26 FPI/ 36 FPI /43 FPI
Condition :
Annealed
Application :
Heating systems Ventilation systems Refrigeration and climate control systems Mechanical engineering Automotive manufacturing Chemicals and pertrochemical and power plant technology
High light :
Low finned tube
Description

ASTM B111 C70600 Copper Nickel Low Finned Tube O61 For Oil Cooler

Yuhong supply customised finned tubes to meet specific requirements. We are manufacturer, own complete line of finned tubes includes Extruded Fin Tubes, Spiral Welded Fin Tubes, Embedded Fin Tubes (G-Fin Tubes), L Fin Tubes, LL Fin Tubes, KL Fin Tubes, Square Fin Tubes (H Fin Tubes), Rectangular Fin Tubes (Double H-Fin Tubes), Longitudinal Fins High-frequency welded serrated finned tubes and high-frequency welded solid finned tubes.

Specifications

Items General Materials Popular ASTM Materials
Core Tube Material Carbon steel, low-alloy steel, stainless steel, brass, copper, cooper-nickel alloys, aluminum bronze, nickel alloys.

1. Carbon Steel: A179, A192,SA210 Gr A1/C,A106 Gr B

2. Stainless Steel: TP304/304L,TP316/TP316L

3. Copper:UNS12200/UNS14200/UNS70600,

CuNi70/30,CuNi 90/10

4. Titanium: B338 Gr 2
Fins Material Aluminum & Copper.

1. Aluminum(Alu.1100,Alu.1060)

2. Copper.

Advantages of low-finned tubes

  • 2.5-3 times the external surface area of bare tubes
  • Increased heat exchanger efficiency means fewer tubes are needed to accomplish the same heat transfer as bare tubes
  • Low finned tubes can improve the performance of existing exchangers without the difficult and expensive task of building new housings
  • Reduced space and weight are valuable for offshore production or high altitude distillation towers. Low fin technology can transform large shell and tube heat exchangers into compact heat exchangers

Delivery Condition

O10 Cast and annealed (homogenized)
O11 As-cast and precipitation heat treated
O20 Hot forged and annealed
O25 Hot rolled and annealed
O30 Hot extruded and annealed
O31 Extruded and precipitation heat treated
O40 Hot pierced and annealed
O50 Light annealed
O60 Soft annealed
O61 Annealed
O65 Drawing annealed
O68 Deep-drawing annealed
O70 Dead-soft annealed
O80 Annealed to temper,1/8 hard
O81 Annealed to temper,1/4 hard
O82 Annealed to temper,1/2 hard

Applications

  1. Heat exchangers units for power plant(electric, nuclear, thermal and geothermal power plants);
  2. High corrosive systems (condensers, evaporators, sea water desalinations, fertilizing, urea systems, ammonia, gas, corrosive acids);
  3. The petroleum, chemical and petrochemical industries;
  4. The food processing and refrigeration industries;
  5. Natural gas treatment;

ASTM B111 C70600 Copper Nickel Low Finned Tube O61 For Oil Cooler
