ASTM B111 UNS C70600 O61, Copper Nickel 90/10, Integral Low Fin Tube For Condensers
ASTM B111 UNS C70600 O61, Copper Nickel 90/10, Integral Low Fin Tube For Condensers
ASTM B111 UNS C70600 O61, Copper Nickel 90/10, Integral Low Fin Tube For Condensers
ASTM B111 UNS C70600 O61, Copper Nickel 90/10, Integral Low Fin Tube For Condensers
ASTM B111 UNS C70600 O61, Copper Nickel 90/10, Integral Low Fin Tube For Condensers
ASTM B111 UNS C70600 O61, Copper Nickel 90/10, Integral Low Fin Tube For Condensers
ASTM B111 UNS C70600 O61, Copper Nickel 90/10, Integral Low Fin Tube For Condensers
ASTM B111 UNS C70600 O61, Copper Nickel 90/10, Integral Low Fin Tube For Condensers
Specifications
Brand Name :
YUHONG
Model Number :
UNS C70600 O61 (Copper-Nickel 90/10)
Certification :
ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2015
Place of Origin :
China
MOQ :
200 KGS
Price :
Negotiable
Payment Terms :
T/T, L/C
Supply Ability :
According To Clients' Request
Delivery Time :
5 - 90 Work Days
Packaging Details :
Plywood Case / Iron Case / Bundle with Plastic Cap
Standard :
ASTM B111, ASME SB111
Material Grade :
UNS C70600 O61 (Copper-Nickel 90/10)
Product Name :
Integral Low Fin Tube
Fin Height :
0mm - 1.6mm
Fin Pitch :
0.6mm - 2.0mm
Tube Outer Diameter :
10 - 38mm
Fin Thicness :
0 - 0.3mm
Tube Length :
18 meters max
Tube material :
Carbon Steel,Stainless Steel,Copper,Alloy Steel
Application :
Heater Parts,Refrigeration Parts,heat exchanger,Cooler,Fluid Cooling
Description

ASTM B111 UNS C70600 O61, Copper Nickel 90/10, Integral Low Fin Tube For Condensers

ASME SB111 UNS 70600, Copper Nickel 90/10, Low Fin Tubes have excellent overall strength corrosion resistance, high ductility, good toughness, excellent resistance to stress corrosion, good erosion, excellent fabrication and welding properties. Copper Nickel 90/10 Low FinTubes are used in various applications like marine systems, oil and gas, chemical and petrochemical industries, and shipbuilding equipments. They are also widely used for handling seawater in all types of heat exchanger and cooling plant.

ASTM B111 UNS C70600 O61 Copper Nickel Alloy Low Fin Tubes are made to form fins with a certain height, distance and thickness on the outer surface of the base tube. Copper nickel low fin tubes are mostly used as heat exchanger elements and evaporators. Using integral low fin tube is developed as a method of increasing heat transfer performance of fluids while minimizing the size also cost of the heat exchanger. The low fin tubes improve the thermal performance of a heat exchanger without changing shell’s size, flow arrangement or re-positioning of tubes. The external surface of the tube is increased by the formation of "low fins".

Material Grade:

Material ASTM B111 BS2871 JIS H3300 DIN1785 GB/T 8890
Copper Nickel C70600 CN102 C7060 CuNi10Fe1Mn BFe10-1-1
C71500 CN107 C7150 CuNi30Mn1Fe BFe30-1-1
C71640 CN108 C7164 CuNi30Fe2Mn2 BFe30-2-2
C70400 — — — BFe5-1.5-0.5
Aluminium Brass C68700 CZ110 C6870 CuZn20AL2 HAL77-2
Admiralty Brass C44300 CZ111 C4430 CuZn28Sn1 HSn70-1

Chemical Composition:

Elements Content (%)
Ni 9.0-11.0
Fe 1.0-1.8
Zn 1.0
Mn 1.0
Pb 0.05
Cu Rem.

Mechanical Properties:

Density Melting Point Tensile Strength Yield Strength (0.2%Offset) Elongation
8.1 g/cm3 1443 °C (2430 °F) 80000Psi, 551Psi 35000Psi, 241Psi 30 %

Applications:

  • Evaporators
  • Heat Exchangers
  • HVAC Industry
  • Electrical Industry
  • Constructions Industry
  • Automobiles Industry
  • Oil and Gas Coolers
  • Electrical Engineering Industry
  • Marine Engineering Industry
  • Pharmaceutical Equipment
  • Chemical Equipment

ASTM B111 UNS C70600 O61, Copper Nickel 90/10, Integral Low Fin Tube For Condensers
