Specifications
Brand Name :
YUHONG
Model Number :
Inconel 625, UNS N06625, DIN 2.4856
Certification :
ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2015
Place of Origin :
China
MOQ :
1 Pieces
Price :
Negotiable
Payment Terms :
T/T, L/C
Supply Ability :
According To Customers' Request
Delivery Time :
5 - 60 work days
Packaging Details :
Ply-wooden Case / Pallet
Standard :
ASTM B564, ASME SB564
Material Grade :
Inconel 625, UNS N06625, DIN 2.4856
Type :
Threaded flange,Slip on Flange,socket weld flange,weld neck flange,LAP Joint Flange
Size :
1/2"-48"
Pressure :
Class150-2500(PN6-PN100)
Technics :
Forged
Surface treatment :
Heat treatment,Galvanized,pickeling
Applications :
Petroleum,chemical,fittings and connection,etc.
Description

ASTM B564 Inconel 625, UNS N06625, DIN 2.4856 Nickel Alloy Steel RTJ Flange

Inconel Flanges have resistant to oxidation, and this nickel-base alloy functions well at elevated temperatures. In fact, its properties remain unchanged over an extensive temperature range. And like most Inconel alloys, this material has resistant to stress related corrosion cracking to chloride ions. The main applicances of Inconel 625 Forging Flanges include industries like marine and petroleum industries. Other advantages of using the Inconel 625 Flanges are high fracture toughness as well as fabricability. We're manufacturer of ASTM B564 UNS N06625 nickel alloy RTJ flanges with high quality for more than 30 years.

Equivalent Grades:

STANDARD GOST AFNOR EN WERKSTOFF NR. UNS JIS BS
Inconel 625 ХН75МБТЮ NC22DNB4M NC22DNB4M 2.4856 N06625 NCF 625 NA 21

ASTM B564 Inconel 625, UNS N06625, DIN 2.4856 Nickel Alloy Steel RTJ Flange

Specification: Inconel 625 Flanges
Pressure Rating 2500 LBS, Class 150 LBS, 900 LBS, 1500 LBS, 300 LBS, 600 LBS
common types Forged / Threaded / Screwed / Plate
Connect Type/ Flange Face Type Raised Face (RF) Flanges, Large Tongue & Groove Flanges, Flat Face (FF) Flanges, Large Male-Female (LMF) Flanges, Groove Flanges, Lap-Joint Face (LJF) Flanges, Small Male-Female (SMF) Flanges, Small Tongue Flanges, Ring Type Joint (RTJ) Flanges
Coating Oil Black Paint, Anti-rust Paint, Zinc Plated, Cold and Hot Dip Galvanized, Yellow Transparent,
Production technique Forged, Heat treated and machined
Size Chart 1/2" to 48"

Chemical Composition:

Ni C Fe Si Mn S Al Ti Nb + Ta P Mo Cr2
58 min 0.1 max 5 max 0.5 max 0.5 max 0.015 max 0.4 max 0.4 max 3.15–4.15 0.015 max 8-10 20-23

Mechanical Strength:

Tensile Strength Yield Strength (0.2%Offset) Elongation Density Melting Point
Psi – 1,35,000 , MPa – 930 Psi – 75,000 , MPa – 517 42.5 % 8.4 g/cm3 1350 °C (2460 °F)

Applications:

Pipeline

High Temperature Application

Water Pipe Line

Nuclear Power Plants

Food Processing and Dairy Industries

Boiler & Heat Exchangers

ASTM B564 Inconel 625, UNS N06625, DIN 2.4856 Nickel Alloy Steel RTJ Flange
