EN10305-1 E235 Seamless Cold Drawn Tubes Low Carbon Steel for Vessel Construction
EN10305-1 E235 Seamless Cold Drawn Tubes Low Carbon Steel for Vessel Construction
EN10305-1 E235 Seamless Cold Drawn Tubes Low Carbon Steel for Vessel Construction
EN10305-1 E235 Seamless Cold Drawn Tubes Low Carbon Steel for Vessel Construction
EN10305-1 E235 Seamless Cold Drawn Tubes Low Carbon Steel for Vessel Construction
EN10305-1 E235 Seamless Cold Drawn Tubes Low Carbon Steel for Vessel Construction
EN10305-1 E235 Seamless Cold Drawn Tubes Low Carbon Steel for Vessel Construction
EN10305-1 E235 Seamless Cold Drawn Tubes Low Carbon Steel for Vessel Construction
EN10305-1 E235 Seamless Cold Drawn Tubes Low Carbon Steel for Vessel Construction
EN10305-1 E235 Seamless Cold Drawn Tubes Low Carbon Steel for Vessel Construction
EN10305-1 E235 Seamless Cold Drawn Tubes Low Carbon Steel for Vessel Construction
EN10305-1 E235 Seamless Cold Drawn Tubes Low Carbon Steel for Vessel Construction
Specifications
Brand Name :
YUHONG
Model Number :
EN10305-1 E235N
Certification :
ISO/CE/SGS
Place of Origin :
CHINA
MOQ :
100KG
Price :
Negotiable
Payment Terms :
L/C, T/T
Delivery Time :
5-80 Days
Packaging Details :
Ply-wooden Case /Iron Case/ Bundle with plastic Cap
Standard :
ASTM,GB,DIN
Specification :
EN10305-1 E235N Seamless Cold Drawn Tubes
Technique :
Cold Drawn/Cold Rolling or Both of them
Package :
Standard Seaworthy Package
Application :
hydraulic pipe/motorcycle, car parts/ shock absorber/machine work/
Shape :
Round.
Description

EN10305-1 E235 Seamless Cold Drawn Tubes Low Carbon Steel for Vessel Construction

We are YUHONG GROUP , one of the biggest manufactures of stainless steel & duplex steel & alloy steel tubes and pipes in China. With development more than 33 years, we have accumulated a great many clients all around the world and Yuhong products also won the great praise among the customers.

Description

Grade E235 or as referred to as EN 1.0308 steel is a non-alloy carbon steel grade. Essentially, E235 is the chemical designation for the English standard. The EN 10294-1 Grade E235 is an unalloyed steel that is well suited for machining without the use of a heat treatment.

EN 10305-1 grade covers steel to produce precision piping grades. The EN 10305-1 Tube is designed with a chemical composition of carbon, silicon, manganese, phosphorus, and sulfur. This gives the EN 10305-1 Steel Tubes good strength and excellent tolerance to high temperatures and corrosive media in stress-induced environments. The EN 10305-1 Material is designed with a tensile strength between 340mpa up to 550mpa. They can be elongated by 22% in the system. Steel Tube EN 10305-1 grade can be precisely shaped in different sizes and dimensions to meet different project requirements. The versatile EN 10305-1 Pipe is widely used in transmission shafts, fuel injection pipes, power steering systems, boiler equipment, heat exchanger tubes, and so on.

Chemical Properties

Pipe types CHEMICAL COMPOSITION (LADLE ANALYSIS)
C% Si% Mn% P% S% Cr% Mo% V% Inne% Cr+ Mo+ Ni Max% Al.%
E235 <=0,17 <=0,35 <=1,20 <=0,025 <=0,025 - - - - - 0,020- 0,060
E255 <=0,21 <=0,35 0,40-1,10 <=0,025 <=0,025 - - - - - 0,020- 0,060
E355 <=0,22 <=0,55 <=1,60 <=0,025 <=0,025 - - - - - 0,020- 0,060

Mechanical Properties

Mechanical properties at room temperature
Steel Grade Minimum values for the delivery condition
Steel Name Steel Number +C +LC +SR +A +N
Rm A Rm A Rm ReH A Rm A Rm ReH A
Mpa % Mpa % Mpa Mpa % Mpa % Mpa Mpa %
E215 1.0212 430 8 380 12 380 280 16 280 30 290 to 430 25 30
E235 1.0308 480 6 420 10 420 350 16 315 25 340 to 480 235 25
E355 1.058 640 4 580 7 580 450 10 450 22 490 to 630 355 22

Resistance Properties

Pipe types Steel grades Resistance properties
+C +LC +SR +A +N
Rm [MPa] A% Rm [MPa] A% Rm [MPa] Re [MPa] A% Rm [MPa] A% Rm [MPa] Re [MPa] A%
Precision E235 480 6 420 10 420 350 16 315 25 340- 480 235 25
E235, E255 580 5 520 8 520 375 12 390 21 440- 570 255 21
E255, E355 640 4 580 7 580 450 10 450 22 490- 630 355 22
E355 C34E 590 5 540 7 - - - 440 22 >= 460 280 21
According to PN-EN 10305-1 C45E 720 4 670 6 - - - 510 20 >= 540 340 18

Application

  • Apparatus engineering
  • Vessel construction
  • Pipelines
  • Mechanical engineering
  • Tool-building

EN10305-1 E235 Seamless Cold Drawn Tubes Low Carbon Steel for Vessel Construction
