Nickel 200 (Pure Nickel - Ni 99.6) Seamless Tube, ASTM B163 N02200, In Marine And Offshore Systems
Nickel 200 (Pure Nickel - Ni 99.6) Seamless Tube, ASTM B163 N02200, In Marine And Offshore Systems
Nickel 200 (Pure Nickel - Ni 99.6) Seamless Tube, ASTM B163 N02200, In Marine And Offshore Systems
Nickel 200 (Pure Nickel - Ni 99.6) Seamless Tube, ASTM B163 N02200, In Marine And Offshore Systems
Nickel 200 (Pure Nickel - Ni 99.6) Seamless Tube, ASTM B163 N02200, In Marine And Offshore Systems
Nickel 200 (Pure Nickel - Ni 99.6) Seamless Tube, ASTM B163 N02200, In Marine And Offshore Systems
Nickel 200 (Pure Nickel - Ni 99.6) Seamless Tube, ASTM B163 N02200, In Marine And Offshore Systems
Nickel 200 (Pure Nickel - Ni 99.6) Seamless Tube, ASTM B163 N02200, In Marine And Offshore Systems
Specifications
Brand Name :
YUHONG
Model Number :
Nickel Alloy 200 Seamless Tube
Certification :
ABS, LR, GL, DNV, NK, TS, PED, ISO 9001
Place of Origin :
CHINA
MOQ :
500KGS
Price :
Negotiable
Payment Terms :
T/T, L/C AT SIGHT
Supply Ability :
30 tons per month
Delivery Time :
Depends on quantity
Packaging Details :
Ply-wooden Case /Iron Case/ Bundle with plastic Cap
Product Name :
Nickel 200(UNS N02200) Seamless Tube
Nickel Content :
≥ 99.6%
Standard :
ASTM B163 / ASME SB163
Material :
UNS N02200 / Nickel Alloy 200 / DIN 2.4066
Heat treatment :
Bright Annealed
NDT :
ET, HT, UT
Description

Nickel 200 (Pure Nickel - Ni 99.6) Seamless Tube, ASTM B163 N02200, In Marine And Offshore Systems

Abstract of Nickel 200 Seamless Tube

Nickel 200 tubes are made of 99% nickel alloy, known as commercial pure nickel. The material has a minimum yield strength of 148MPa and a minimum tensile strength of 462MPa, but the material has very high corrosion resistance. The material consists of carbon, manganese, silicon, sulfur, copper, iron and 99% nickel.

Applications where these ASTM B163 nickel 200 tubes can be used include chemical storage and processing, synthetic fiber production, and methods using fluorine and sodium hydroxide. However, beyond food processing, other applications include defence and aerospace. At the same time, these ASTM B163 tubes have excellent alkali resistance at different concentrations and temperatures.

Key Features of Nickel 200 (Pure Nickel - Ni 99.6) Seamless Tube

  • Material: Nickel Alloy 200 (UNS N02200)

  • Form: Seamless tube (no welds, uniform wall thickness)

  • Nickel Content: ≥ 99.6%

  • Standards: ASTM B161 (general service), ASTM B163 (condenser/heat exchanger applications

ASTM B163 N02200 Tube Chemical Composition

Cu Ni Fe Mn C S Si
0.25 max 99.0 min 0.4 max 0.35 max 0.15 max 0.01 max 0.1 max

ASTM B163 N02200 Tube Mechanical Properties

Density Melting Point Tensile Strength Yield Strength (0.2%Offset) Elongation
8.89 g/cm3 1370 °C (2550 °F) Psi – 1,15,000 , MPa –790 Psi – 52,000 , MPa – 355 40 %

Nickel 200 / UNS N02200 Equivalent Grades

STANDARD WERKSTOFF NR. UNS JIS EN BS GOST AFNOR
Nickel 200 2.4066 N02200 NW 2200 Ni 99.2 NA 11 НП-2 N-100M

ASTM B163 N02200 Tube Physical Properties

Grade ASTM B163 Nickel 200
Density 8.9 g/cm3
Melting Point 1446 °C (2635 °F)

Application of Nickel 200 Tube

  • Caustic soda production

  • Food processing (especially with caustics)

  • Chemical processing

  • Heat exchangers and condensers

  • Aerospace components

  • Marine and offshore systems

  • Electronics (battery and electrode connections)

Nickel 200 (Pure Nickel - Ni 99.6) Seamless Tube, ASTM B163 N02200, In Marine And Offshore Systems
