Cooper Alloy Tube B111 C68700 O61 Annealed, Aluminium Brass Seamless Tubing For Sea Water Heat Exchanger
Cooper Alloy Tube B111 C68700 O61 Annealed, Aluminium Brass Seamless Tubing For Sea Water Heat Exchanger
Cooper Alloy Tube B111 C68700 O61 Annealed, Aluminium Brass Seamless Tubing For Sea Water Heat Exchanger
Cooper Alloy Tube B111 C68700 O61 Annealed, Aluminium Brass Seamless Tubing For Sea Water Heat Exchanger
Cooper Alloy Tube B111 C68700 O61 Annealed, Aluminium Brass Seamless Tubing For Sea Water Heat Exchanger
Cooper Alloy Tube B111 C68700 O61 Annealed, Aluminium Brass Seamless Tubing For Sea Water Heat Exchanger
Cooper Alloy Tube B111 C68700 O61 Annealed, Aluminium Brass Seamless Tubing For Sea Water Heat Exchanger
Cooper Alloy Tube B111 C68700 O61 Annealed, Aluminium Brass Seamless Tubing For Sea Water Heat Exchanger
Specifications
Brand Name :
YUHONG
Model Number :
C68700 Aluminium Brass Seamless Tube
Certification :
ISO, TUV, PED etc.
Place of Origin :
CHINA
MOQ :
300kgs
Price :
NEGOTIABLE
Payment Terms :
T/T, L/C at sight
Supply Ability :
1000 Ton/Month
Delivery Time :
Depends on quantity
Packaging Details :
Ply-wooden Case /Iron Case/ Bundle with plastic Cap
Standard :
ASTM B111 / ASME SB111
Material :
C68700 / CuZn20Al2As / CuZn20Al2 (Aluminium Brass)
Non-destructive tests :
ET / UT / HT
Applications :
Marine condensers / Heat exchangers / Desalination plants
Description

Cooper Alloy Tube B111 C68700 O61 Annealed, Aluminium Brass Seamless Tubing For Sea Water Heat Exchanger

Short Introduction: C68700 Copper Alloy Seamless Tube

C68700 Copper Alloy Seamless Tube, also known as Aluminium Brass Tube, is a high-performance, non-ferrous tubing material made primarily of copper, zinc, and aluminium. It offers excellent corrosion resistance, particularly in seawater and marine environments, and is commonly used in heat exchangers, condensers, and power plant cooling systems.

The seamless design ensures leak-free operation under pressure and thermal stress. Its high thermal conductivity, good mechanical strength, and resistance to biofouling make it ideal for demanding industrial and marine applications.


Key Characteristics of C68700 Copper Alloy Tube

FeatureDescription
TypeSeamless (SMLS) copper alloy tube
StandardASME SB111 / ASTM B111
Corrosion ResistanceExcellent in seawater, brackish water
Thermal Conductivity~121 W/m·K
Mechanical StrengthTensile ≥ 345 MPa, Yield ≥ 125 MPa (annealed)
WorkabilityGood for expansion, bending, welding
Biofouling ResistanceHigh due to aluminium content


ASME SB111 C68700 Copper Alloy Tube Chemical Composition

Element

Percentage (%)

Copper (Cu)

76.0 – 79.0

Zinc (Zn)

Balance

Aluminium (Al)

1.8 – 2.5

Iron (Fe)

0.02 – 0.06

Manganese (Mn)

0.2 – 0.6

Arsenic (As)

Trace (for corrosion resistance)



ASME SB111 C68700 Copper Alloy Tube Mechanical Properties

Copper or Copper Alloy UNS NO.Temper DesignationTensile StrengthYield StrengthElongation
in 2 in.,
CodeFormermin ksi(min MPa)min ksi(min MPa)min %
C68700O61annealed50(345)18(125)---



ASME SB111 C68700 Equivelant

STANDARDUNSWERKSTOFF NR.
Aluminium BrassC687002.0460 / 1785



Application of C68700 Copper Alloy Seamless Tube:

  • Marine engine seawater coolers

  • Hydraulic oil coolers for construction machinery

  • Power plant small condenser tubes

  • Industrial air compressor aftercoolers

  • Water-cooled chiller evaporators & condensers

  • Shipboard auxiliary machinery cooling systems

  • Lubricating oil coolers for generator sets

  • Small shell-and-tube heat exchangers

  • Seawater desalination preheater tubes

  • HVAC module unit heat exchange tubes


Cooper Alloy Tube B111 C68700 O61 Annealed, Aluminium Brass Seamless Tubing For Sea Water Heat Exchanger
