Specifications
Brand Name :
YUHONG
Model Number :
ASTM A105/A105N
Certification :
ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2008
Place of Origin :
CHINA
MOQ :
10 PC
Price :
1-100000 USD
Payment Terms :
T/T, L/C
Supply Ability :
1000 tons/month
Delivery Time :
5-45 days
Packaging Details :
Ply-wooden Case /Iron Case/ Bundle with plastic Cap
Product :
Flanges
Material :
Carbon Steel
Standard :
ASTM A105/A105N
Grade :
A105/A105N
Type :
Blind/ Threaded /Slip On /Socket Welded/ Welding Neck/ Lap Joint Flange
Process :
Forged, Drilling/Bending/Stamping, Casting, Heating Treament
Description

ASTM A105 A105N Carbon Steel Flanges Bridas

YUHONG Group can do many projects: heat exchanger / boiler projects, marine projects, oil & gas projects etc. And we supply flanges/ pipe fittings made by many materials, such as of carbon steel, stainless steel, copper steel and alloy steel!

This page is about ASTM A105/A105N carbon steel flanges for pipeline,oil and gas,and many other projects.

Specification Of ASTM A105/A105N

Types of Flange WN Flange;Threaded Flange;SO Flange;Lap Joint Flange;SW Flange;Blind Flange
Dimensions ANSI/ASME B16.5, B 16.47 Series A & B, B16.48, BS4504, BS 10, EN-1092, DIN, etc.
Standard ANSI Flanges, ASME Flanges, BS Flanges, DIN Flanges, EN Flanges, etc.
Size 1/2″ to 48″
Class / Pressure 150#, 300#, 600#, 900#, 1500#, 2500#, PN6, PN10, PN16, PN25, PN40, PN64 etc.
Flange Face Type Flate Face (FF), Raised Face (RF), Ring Type Joint (RTJ)

Chemical Composition Of ASTM A105/A105N

ELEMENT COMPOSITION (%)
Carbon 0.35 max
Manganese 0.60-1.05
Phosphorus 0.035 max
Sulfur 0.040 max
Silicon 0.10-0.35
Copper 0.40 max (1)
Nickel 0.40 max (1)
Chromium 0.30 max (1-2)
Molybdenum 0.12 max (1-2)
Vanadium 0.08 max

The sum of copper, nickel, chromium, molybdenum and vanadium shall not exceed 1.00% while the sum of

chromium and molybdenum shall not exceed 0.32%.

The carbon equivalent CE = C + Mn/6 + (Cr + Mo + V)/5 + (Ni + Cu)/15.

Shall be no larger than 0.47 based on heat analysis.

Mechanical Properties Of ASTM A105/A105N

Mechanical Properties Requirements
Tensile strength,min,psi [MPa] 70000 [485]
Yield strength,min,psi [MPa] 36000 [250]
Elongation, min, % 30
Reductionofarea,min,% 30
Hardness,HB,max 187

Key Markets And Industries

Nuclear power (mostly seamless)

Petrochemicals and acids.

Bitumen upgraders.

Heavy oil refineries

Ship building Construction

Pipeline

Oil and gas industry
