ASTM A210 GR.A1 Carbon Steel Boiler Tube for Sewage Treatment and Petrochemical
ASTM A210 GR.A1 Carbon Steel Boiler Tube for Sewage Treatment and Petrochemical
ASTM A210 GR.A1 Carbon Steel Boiler Tube for Sewage Treatment and Petrochemical
ASTM A210 GR.A1 Carbon Steel Boiler Tube for Sewage Treatment and Petrochemical
ASTM A210 GR.A1 Carbon Steel Boiler Tube for Sewage Treatment and Petrochemical
ASTM A210 GR.A1 Carbon Steel Boiler Tube for Sewage Treatment and Petrochemical
ASTM A210 GR.A1 Carbon Steel Boiler Tube for Sewage Treatment and Petrochemical
ASTM A210 GR.A1 Carbon Steel Boiler Tube for Sewage Treatment and Petrochemical
ASTM A210 GR.A1 Carbon Steel Boiler Tube for Sewage Treatment and Petrochemical
ASTM A210 GR.A1 Carbon Steel Boiler Tube for Sewage Treatment and Petrochemical
Specifications
Brand Name :
YUHONG
Model Number :
ASTM A210 Gr A1
Certification :
ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2008.
Place of Origin :
CHINA
MOQ :
10PC
Price :
Negotiable
Payment Terms :
L/C, T/T
Supply Ability :
1000tons/month
Delivery Time :
15-35 DAYS
Packaging Details :
Ply-wooden Case /Iron Case/ Bundle With Plastic Cap
Standard :
ASTM A210
Material Grade :
GR.A1
Type :
Seamless
Outside Diameter :
2mm~914mm
Wall Thickness :
0.2mm~120mm
Shape :
Round
High Light :
ASTM A210 Carbon Steel Tube, Carbon Steel Seamless Tube, Carbon Steel Tube ASME SB210 GR.A1
Description

ASME SA210 GR.A1 Carbon Steel Tube for Sewage Treatment and Petrochemical

ASME SA 210 is a ferritic grade used in high-pressure and temperature systems. The ASME SA 210 Grade A1 Boiler Tube is made up of a chemical composition consisting of 0.27% of carbon, 0.93% manganese, 0.10% silicon, 0.035% phosphorous, and sulfur. These tubes possess good resistance against corrosion and have good mechanical properties. The ASME SA210 A1 Boiler Tube has a tensile strength of minimum 415Mpa and a yield strength of minimum 215Mpa. These tubes can be easily elongated by 30% and possess 79HRB maximum hardness. In the ASME SA 210 Seamless Boiler Tube, no welds or joints are used in its production.

These tubes are extremely strong and can withstand high pressures up to 160 bar. The ASME SA210 Grade A1 Superheater Tube can resist and work well in extreme temperatures up to 550 degrees C. These tubes don’t deform or dissociate easily and have a long life. The ASME SA210 Tube is highly versatile and widely used in oil and gas refineries, water supply systems, sewage treatment, agricultural equipment, petrochemical, paper industries, etc.

Chemical Composition:

Grade C Mn Si S P
Gr.A1 Min 0.10
Max 0.27 0.93 0.035

0.035

Mechanical Properties:

Grade Tensile Str(Mpa) Yield Str(Mpa) Elongation(%) Hardness
Gr.A1 ≥415 ≥255 ≥30 ≤79

Wall Thickness Tolearance:

Seamless, Cold-Finished Tubes Type Wall Thickness Tolerance
OD Range Under(-) Over(+)
0~38.1mm (Incl.) SMLS 0 20%
38.1mm~127mm (Incl.) SMLS 0 22%

Length Tolearance:

Seamless, Cold-Finished Tubes Type Permissible Variations In mm
OD Range Under(-) Over(+)
0~25.4mm (Incl.) SMLS 0.1mm 0.1mm
25.4~38.1mm (Incl.) SMLS 0.15mm 0.15mm
38.1~50.8mm (Incl.) SMLS 0.2mm 0.2mm
50.8~63.5mm (Incl.) SMLS 0.25mm 0.25mm
63.5~76.2mm (Incl.) SMLS 0.3mm 0.3mm
76.2~101.6mm (Incl.) SMLS 0.38mm 0.38mm
101.6~127mm (Incl.) SMLS

0.64mm

 0..38mm

Application:

Petrochemical Industry
Chemical Industry
Oil and Gas Industry
Pulp & Paper Indusry
Power Plant Industry
Food Processing Industry
Pharmaceuticals Industry
Energy Industry
Aerospace Industry
