ASTM A270 TP316L Seamless Or Welded Stainless Steel Sanitary Tube, Designed For Sanitary And Hygienic Application
ASTM A270 TP316L Seamless Or Welded Stainless Steel Sanitary Tube, Designed For Sanitary And Hygienic Application
ASTM A270 TP316L Seamless Or Welded Stainless Steel Sanitary Tube, Designed For Sanitary And Hygienic Application
ASTM A270 TP316L Seamless Or Welded Stainless Steel Sanitary Tube, Designed For Sanitary And Hygienic Application
ASTM A270 TP316L Seamless Or Welded Stainless Steel Sanitary Tube, Designed For Sanitary And Hygienic Application
ASTM A270 TP316L Seamless Or Welded Stainless Steel Sanitary Tube, Designed For Sanitary And Hygienic Application
ASTM A270 TP316L Seamless Or Welded Stainless Steel Sanitary Tube, Designed For Sanitary And Hygienic Application
ASTM A270 TP316L Seamless Or Welded Stainless Steel Sanitary Tube, Designed For Sanitary And Hygienic Application
Specifications
Place of Origin :
China, India, USA, Korea, UE
Brand Name :
YUHONG
Certification :
ABS, LR, GL, DNV, NK, TS, PED, AD2000, GOST9941-81, CCS, ISO 9001-2008
MOQ :
100KGS
Price :
negotiable
Packaging Details :
Ply-wooden Case /Iron Case/ Bundle with plastic Cap
Delivery Time :
Depends on quantity
Payment Terms :
T/T, L/C
Supply Ability :
1500 tons per month
Model Number :
TP316L
Standard :
TP316L
Specification :
ASTM A270
Size :
1” NB to 12” NB
W.T. :
SCH5-SCH120
Length :
Single Random, Double Random & Cut Length
NDT :
ET/HT/UT/PT
Description

ASTM A270 TP316L Seamless Or Welded Stainless Steel Sanitary Tube, Designed For Sanitary And Hygienic Application

ASTM A270 TP316L Tube

ASTM A270 TP316L is a low-carbon austenitic stainless steel sanitary tube, designed for hygienic applications in the food, beverage, dairy, pharmaceutical, and biotechnology industries. Manufactured to strict sanitary standards, it offers excellent corrosion resistance, especially in chloride-rich and acidic environments. TP316L tubes are available in seamless or welded form with polished or electropolished finishes, making them ideal for systems requiring high cleanliness, durability, and corrosion resistance.

Chemical Composition of A270 TP316L Tube:

Grade C Mn Si P S Cr Mo Ni N
316L Min – – – – – 16.0 2.00 10.0 –
Max 0.03 2.0 0.75 0.045 0.03 18.0 3.00 14.0 0.10

Mechanical Properties of A270 TP316L Tube

Grade C Mn Si P S Cr Mo Ni N
316L Min – – – – – 16.0 2.00 10.0 –
Max 0.03 2.0 0.75 0.045 0.03 18.0 3.00 14.0 0.10

Physical Properties of A270 TP316L Tube

Material Heat Temperure Tensile Strength Yield Strength Elongation %, Min
Treatment Min. Ksi (MPa), Min. Ksi (MPa), Min.
º F(º C)
TP304 Solution 1900 (1040) 75(515) 30(205) 35
TP304L Solution 1900 (1040) 70(485) 25(170) 35
TP316 Solution 1900(1040) 75(515) 30(205) 35
TP316L Solution 1900(1040) 70(485) 25(170) 35

Application of Stainless Steel Sanitary Tube

  • Food & beverage processing (e.g., milk, beer, juice lines)

  • Pharmaceutical and biotech equipment

  • Dairy pipelines and fittings

  • Cleanroom installations

  • Water purification systems

  • ASTM A270 TP316L Seamless Or Welded Stainless Steel Sanitary Tube, Designed For Sanitary And Hygienic Application
