SS201 309S 316L Seamless Welded Stainless Steel Tubes Mirror Polished
SS201 309S 316L Seamless Welded Stainless Steel Tubes Mirror Polished
SS201 309S 316L Seamless Welded Stainless Steel Tubes Mirror Polished
SS201 309S 316L Seamless Welded Stainless Steel Tubes Mirror Polished
SS201 309S 316L Seamless Welded Stainless Steel Tubes Mirror Polished
SS201 309S 316L Seamless Welded Stainless Steel Tubes Mirror Polished
SS201 309S 316L Seamless Welded Stainless Steel Tubes Mirror Polished
SS201 309S 316L Seamless Welded Stainless Steel Tubes Mirror Polished
Specifications
Brand Name :
Weiao
Model Number :
stainless steel pipe
Certification :
ISO,CE,TUV,BSI,BV,IQI
Place of Origin :
Wuxi, China
MOQ :
1 Ton
Price :
Negotiation
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
100 Tons per Week
Delivery Time :
10-20 Days
Packaging Details :
Export standard package, or as customers request
Type :
Welded
Application :
Food And Pharmaceuticals Industry , etc.
Tolerance :
±10%
Welding Line Type :
Efw
Processing Service :
Bending, Welding, Decoiling, Punching, Cutting, Moulding
Section Shape :
Round, Square, Rectangular
Technology :
Online Bright Annealing, Pickling
Surface Treatment :
Mill Finish ;Bright or Mirror ;Satin Brushed ; Sand Blast ;Pickling
Description

201 304 304L 309S 316 316L Mirror Polished Tube Seamless Welded Stainless Steel

Products Description:

AiSi ASTM A554 A312 A270 SS 201 304 304L 309S 316 316L Mirror Polished Tube Square Round Seamless Welded Stainless Steel Pipe

Features:
1. Our stainless steel tubes pipes are treated by bright annealing, inside weld bead removing, precise polishing. The roughness of
tubes could be under 0.3μm.
2. We have the non destructive testing ( NDT ), eg. online eddy current inspection and hydraulic or airtightness testing.
3. Thick welding, good appearance.The mechanical properties of tube could be tested.
4. The raw material is from Taigang, Baogang, Zhangpu and so on.
5. And Our tubes are certificated by AD 2000-W0, PED 2014/68/EU, ISO 9001 : 2015.
6. Full material traceability is guaranteed during the manufacturing process.
7. Polished tube is supplied in individual plastic sleeves with capped ends ensuring optimum cleanliness.
8. Internal Bore: Tubes have a smooth, clean and crevice free bore.
9. Market leading quality products.
Stainless Steel Pipe
Product Standards
Food Grade Sanitary Tube: JIS G3447, KS D 3585, ASTM A270, EN 10357(DIN 11850), AS 1528.1, ISO 2037(NF A49-249)
Heat exchanger tube: ASTM A249 / ASME SA249, GB / T 24593-2009, HG 20537.2
Industrial pipe: ASTM A312, EN 10217-7, GB / T 12771-2008, HG 20537.3
Drinking water tube: GB / T 19228
Mechanical tube: ASTM A554, EN 10296-2
Production Size
Outer Diameter Range: 9.5~2000mm
Thickness Range: 0.5~20mm (Size can be customized.)
Length: Up to 18.3 meters per piece.
Shape sections of tube
Round, square, rectangular
Usage of tube
Sanitary tubing: for food processing industry, beverage industry, sugar mill and so on;

Heat exchanger tube: condenser, boiler, super heater, evaporator and so on;

Industiral pipe: for petroleum delivery, gas delivery, petrochemical industry, wastewater treatment, drainage system, and so on;

Mechanical tube: handrail, railings, balustrade, hence and so on.
Chemical Composition
Tensile Strength
Yield Strength
Elongation
Hardness
HRB
Grade 304 Stainless Steel (100% & MPA)
C≤0.08, Mn≤2, P≤0.045, S≤0.03, Si≤0.75, 8≤Ni≤10.5, 18≤Cr≤20
≥515
≥205
≥40
≤92
Grade 304L Stainless Steel (100% & MPA)
C≤0.03, Mn≤2, P≤0.045, S≤0.03, Si≤0.75, 8≤Ni≤12, 18≤Cr≤20
≥485
≥170
≥40
≤92
Grade 316L Stainless Steel (100% & MPA)
C≤0.03, Mn≤2, P≤0.045, S≤0.03, Si≤0.75, 10≤Ni≤14, 16≤Cr≤18
≥485
≥170
≥40
≤95
