PU400×125 PU500×170 PU600×210 Metal Sheet Piling PZ22 PZ27 Steel Sheet Pile

Specifications

Brand Name :

HTFD

Model Number :

PU400×125 PU500×170 PU600×210 PU 8 PU 12 PU 32 FSP-Ⅲ FSP-Ⅳ PZ22 PZ27

Certification :

CE ISO CNAS CQC

Place of Origin :

China

MOQ :

1Ton

Price :

USD 1800-2300 per ton

Payment Terms :

T/T,L/C

Supply Ability :

50000Tons/Month

Delivery Time :

7-15 working days

Packaging Details :

Standard Export Package

Model NO. :

Steel Sheet Piles

Application :

Structural Steel Bar

Price Term :

FOB EXW CIF

Shape :

Transport Package :

Standard Sea Freight Packing or Customized

Special Use :

Cutting Tools, Measuring Tools

Description

PU400×125 PU500×170 PU600×210 PU 8 PU 12 PU 32 FSP-Ⅲ FSP-Ⅳ PZ22 PZ27 Steel Sheet Pile

Sheet piles are vertical walls formed by locking connections to
simultaneously maintainearth pressure, water pressure, or both at the same time.

Zhuosheng Steel has supplied more than 10,000 tons of various types of steel sheet piles to overseas customers,
of which about 8,000 tons are used for permanent buildings (such as shipyards, wharves, retaining walls, ship locks,
slipways, pump locks, etc.) Temporary works for engineering projects (such as temporary construction cofferdams, tunnels
and foundation supports, etc.).

advantage:
- Very easy to lift, transport and install.

- Wide entry depth, thick flange and good static performance.

- Symmetrical structure, very easy to reuse.

- Can be pre-assembled into "pile groups" in the factory, greatly improving the efficiency of pile driving.

- Very easy to install ties and accessories, even underwater.

- The thickest part is in the outermost layer of the wall (hot rolled) for good corrosion resistance

U type steel sheet piles

Size				Per piece
Specification	Width (mm)	High (mm)	Thick (mm)	Section area (cm2)	Weight (kg/m)
400 x 85	400	85	8.0	45.21	35.5
400 x 100	400	100	10.5	61.18	48.0
400 x 125	400	125	13.0	76.42	60.0
400 x 150	400	150	13.1	74.40	58.4
400 x 170	400	170	15.5	96.99	76.1
600 x 130	600	130	10.3	78.7	61.8
600 x 180	600	180	13.4	103.9	81.6
600 x 210	600	210	18.0	135.3	106.2
750 x 205	750	204	10.0	99.2	77.9
	750	205.5	11.5	109.9	86.3
	750	206	12.0	113.4	89.0

Z type steel sheet piles:

Specification	Width (mm)	High (mm)	Thick t (mm)	Thick s (mm)	Weight (kg/m)
SPZ12	700	314	8.5	8.5	67.7
SPZ13	700	315	9.5	9.5	74
SPZ14	700	316	10.5	10.5	80.3
SPZ17	700	420	8.5	8.5	73.1
SPZ18	700	418	9.10	9.10	76.9
SPZ19	700	421	9.5	9.5	80.0
SPZ20	700	421	10.0	10.0	83.5
SPZ24	700	459	11.2	11.2	95.7
SPZ26	700	459	12.3	12.3	103.3
SPZ28	700	461	13.2	13.2	110.0
SPZ36	700	499	15.0	11.2	118.6
SPZ38	700	500	16.0	12.2	126.4
SPZ25	630	426	12.0	11.2	91.5
SPZ48	580	481	19.1	15.1	140.2
