Q235 2 Inch BS138 Galvanized ERW ASTM Thread/Grooved/Painted Pre Galvanized Steel Pipe
Q235 2 Inch BS138 Galvanized ERW ASTM Thread/Grooved/Painted Pre Galvanized Steel Pipe
Q235 2 Inch BS138 Galvanized ERW ASTM Thread/Grooved/Painted Pre Galvanized Steel Pipe
Q235 2 Inch BS138 Galvanized ERW ASTM Thread/Grooved/Painted Pre Galvanized Steel Pipe
Q235 2 Inch BS138 Galvanized ERW ASTM Thread/Grooved/Painted Pre Galvanized Steel Pipe
Q235 2 Inch BS138 Galvanized ERW ASTM Thread/Grooved/Painted Pre Galvanized Steel Pipe
Specifications
Brand Name :
HTFD
Model Number :
A53
Certification :
CE ISO CNAS CQC
Place of Origin :
China
MOQ :
1Ton
Price :
$600-1000
Payment Terms :
T/T,L/C
Supply Ability :
50000Tons/Month
Delivery Time :
7-15 working days
Packaging Details :
Standard Export Package
Material :
Galvanized Iron Pipes
Standard :
ASTM, GB, DIN, JIS
Cross-Section Shape :
Round
Terms :
FOB EXW CIF
Description
Nominal Size
(Inch)
Outer Diameter
(mm)
SCH40
Thickness (mm)
SCH80
Thickness (mm)
SCH160
Thickness (mm)
1/4"
13.7
2.24
3.02
3/8"
17.1
2.31
3.2
1/2"
21.3
2.77
3.73
4.78
3/4"
26.7
2.87
3.91
5.56
1"
33.4
3.38
4.55
6.35
1-1/4"
42.2
3.56
4.85
6.35
1-1/2"
48.3
3.68
5.08
7.14
2"
60.3
3.91
5.54
8.74
2-1/2"
73
5.16
7.01
9.53
3"
88.9
5.49
7.62
11.13
3-1/2"
101.6
5.74
8.08
4"
114.3
6.02
8.56
13.49
5"
141.3
6.55
9.53
15.88
6"
168.3
7.11
10.97
18.26
8"
219.1
8.18
12.7
23.01
10"
273
9.27
15.09
28.58
12"
323.8
10.31
17.48
33.32
Nominal Size
(Inch)
Outer Diameter
(mm)
STD
Thickness (mm)
SCH40
Thickness (mm)
SCH80
Thickness (mm)
14"
355.6
9.53
11.13
19.05
16"
406.4
9.53
12.7
21.44
18"
457
9.53
14.27
23.83
20"
508
9.53
15.09
26.19
24"
610
9.53
17.48
30.96
Product Item ASTM A106 Seamless steel pipe
Size OD 1/8" -24" (5.0mm-716mm)
Wall Thickness

0.3mm-26mm

SCH20,SCH40,STD,XS,SCH80,SCH160,XXS
Length Less than 12m
Steel material

ASTM 106 Gr.B

API 5L Gr.B

ASTM A 53 Gr.B
Standard ASTM A53, BS1387-1985
Zinc Weight

120g,270g,400g,500g,550g

20μm ,40μm ,60μm,70μm,80μm
Usage

1)low pressure liquid, water, gas, oil, line pipe

2)construction

3)fence, door pipe
Ends

1) Plain

2) Beveled

3) Thread with Coupling or cap

4) Chamfer

5) Groove

6) Screw
End protector

1) Plastic pipe cap

2) Iron protector
Surface Treatment

1) Bared

2) Black Painted (varnish coating)

3) Galvanized

4) Oiled

5) PE,3PE, FBE, corrosion resistant coating, Anti corrosion coating.
Technique

Electronic Resistance Welded (ERW )

Electronic Fusion Welded (EFW)

Double Submerged Arc Welded (DSAW)
Welded Line Type Longitudinal
Section Shape Round
Inspection With Hydraulic Testing, Eddy Current , Infrared Test
Package

1) Bundle,

2) Bags
Delivery

1) Container

2) Bulk carrier
Port of Shipment Xingang Port, Tianjin, China
Date of Delivery According To The Quantity And Specification Of Each Order
Payment L/C T/T
Others Fitting as screws and flange also can be supplied.
