Hydraulic Cutting Tr4 Roofing Sheet Roll Forming Machine for Sales Peru Design

SALIENT FEATURES

Technological Process of IBR Roof Sheet Roll Forming Machine

Decoiler — feeding — guide --- roll forming ---- cut to length — run out table

Description of IBR Roof Sheet Roll Forming Machine

  • We have professional engineering team and can use the Copra Software skillfully to design the forming diagram according to the profile drawing.
  • We adopt the heavy stands to make the machine robust and strong.
  • We adopt pneumatic saw flying cut to shear all profiles
  • The step beams is popularly used in the project of supermarket construction in North America and
  • South America e.g Mexico, Argentina, Chile and so on
  • We exported the step beam machine to Mexico and all of the profiles produced can meet the customer's requirements
  • We also can supply accessories parts machine together with rack machine, crossbar machine, base machine etc

Composition of IBR Roof Sheet Roll Forming Machine

Manual Un coiler 1 unit
Control panel 1 unit
Roll forming main machine 1 unit
Cutting Device 1 unit
Manual out table 2 unit

Equipment List :

  • De-coiler (Manual)
  • Main roll forming machine (20 stand)
  • Hydraulic post cutoff unit
  • Hydraulic power pack
  • Back cutter
  • Lamination unit
  • Electrical control system

1. DECOILER
(1) Max. Width: 1250 mm
(2) Inner Diameter: Φ450 – Φ550 mm
(3) Out Diameter: 1500 mm
(4) Max. Loading Capacity: 5000 kgs


2. ROLL FORMING MACHINE
(1) Material Thickness: 0.3-0.8 mm PPGI and GI

(2) NO. of roller Stations:22groups
(3) Material for Rollers: high grade 45# steel polished and coated with chrome HRC55-60°
(4) Material for shaft: high grade 45# steel

(5) Diameter of shaft: 70mm

(6) Frame panel thickness:14mm

(7) Bottom frame: 35# H-section steel
(8) Motor Power: 5.5kw

(9)Driven type:1.0＂Chain

(10)Speed:8-12m/min

(11)Pre slide cutter

Hydraulic Cutting Tr4 Roofing Sheet Roll Forming Machine for Sales with Crimping Together

3. CUT-OFF DEVICE

(1)Material for Cut-Off Modular:Cr12 steel after treatment
(2)Hardness for Heat Treatment:HRC55 – 60°
(3)Cut-Off Type: Hydraulic, Automatic Cut-Off
(4) Motor for Hydraulic Stand: 3kW

Hydraulic Cutting Tr4 Roofing Sheet Roll Forming Machine for Sales with Crimping Together

4.PLC CONTROL BOX
(1) Type: PLC Frequency Control System with touch screen
(2) PLC Brand:Delta

(3)Length Error: ±2mm

(4)Language: English and Chinese

(5)Voltage: 380v/50HZ, 3Phase

(it depends on customer requirement)

5. HYDRAULIC PUMP STATION

(1) Motor power: 3 kw
(2)Oil type: 46# hydraulic oil
(3) Pump brand: China brand

(4)Cooling fan

6. PRODUCTION SUPPORT TABLE

(1) No power type
(2)Length: 2m


Production Line Sketch
Hydraulic Cutting Tr4 Roofing Sheet Roll Forming Machine for Sales with Crimping Together

Applications
IBR Roofing Sheet; IBR Sheet; IBR Roofing Sheet; Metal roof; Steel roof; Metal roof wall panel; Steel roof wall panel; Metal roofing sheet; Steel roofing sheet; Metal roof panel; Steel roof panel; Beams; C beams;
Step beams in the supermarket

Competitive Advantage
One roll forming machine only can produce one profile.
We can manufacture as per customer provided drawings with the specification or real objects of sectional materials,
custom roll forming machine is welcome.

More information about steel roof panel profiles, Pls contact with us!
