Specifications
Certification :
CE
Price :
USD6000--40000
Packaging Details :
a.need one 40ft container b.Fit for ocean shipping c.Main body of roll forming machine fixed to container by 8mm diameter steel wire; Rollers and shaft is covered with anti-rust oil; Spare parts in carton box
Roller material :
45# steel
Payment Terms :
L/C,T/T
Use :
Roof
Roller materialRoller material :
45# steel
Tile type :
Colored Glaze Steel
Supply Ability :
20 sets/month
Condition :
New
Usage :
Used As Roof Panel In Steel Construction
Delivery Time :
30 work days
Voltage :
380V 50Hz 3phases
Place of Origin :
CHINA
MOQ :
1 set
Brand Name :
BEST
Description
Galavnized Steel Profile Africa Popular Three Layer Roofing Sheet Roll Forming Machine
Galavnized Steel Profile Africa Popular Three Layer Roofing Sheet Roll Forming Machine
High Efficiency Production System
This advanced standing seam roll forming machine features 13 rows of roller stations for efficient production of aluminum roofing sheets with precision and reliability.
Three Layer Roofing Sheet Roll Forming Machine Components & Specifications
Uncoiler System
Loading capacity: 5 T
Uncoiling width: 1250 mm
Inner diameter: 450-550 mm
Shearing Mechanism
Automatic PLC-controlled cutting
Blade material: Cr12 quenched
Power supply: Hydraulic system
Hydraulic Station
Hydraulic motor power: 3kw
Hydraulic oil: 46# hydraulic oil
Control System
Languages: English and Chinese
Length tolerance: 3m ±1.5mm
Touch screen with button interface
Three Layer Roofing Sheet Roll Forming Production Line Components
No. Component Unit Quantity
1 Decoiler set 1
2 Main roll forming machine set 1
3 Control system set 1
4 Hydraulic system set 1
5 Automatic cutting set 1
6 Output table set 1
Three Layer Roofing Sheet Roll Forming Technical Parameters
Parameter Specification
Suitable materials Color steel plate, galvanized sheet, aluminum coils
Feeding material width 1000mm
Roller stations 13 rows
Material thickness 0.3-0.8mm
Production speed 8-12m/min
Roller material 45# steel
Shaft diameter 75mm
Voltage 380V 50Hz 3 phases
Main machine wall thickness 14mm steel plate
Machine body 300mm H steel
Servo motor power 5.5kw
Dimensions 7500*1500*1400mm
Weight Approximately 4.8 tons
Galavnized Steel Profile Africa Popular Three Layer Roofing Sheet Roll Forming Machine
Warranty & Support
  • One year warranty with lifetime technical support
  • Installation training via video or factory visit
  • Overseas service available (customer covers travel expenses)
Packaging & Delivery
Delivery time: 40-60 days after advance payment
Packaging: PE film or custom packaging as requested
Suitable for ocean shipping in 1*40GP container
