Q235 Road Highway Guardrail Roll Forming Machine
Q235 Road Highway Guardrail Roll Forming Machine
Q235 Road Highway Guardrail Roll Forming Machine
Q235 Road Highway Guardrail Roll Forming Machine
Specifications
Brand Name :
BEST
Certification :
CE
Place of Origin :
CHINA
MOQ :
1 set
Price :
USD$80000---100000
Payment Terms :
L/C, T/T
Supply Ability :
20 sets/month
Delivery Time :
30 work days
After-sales service provided :
Engineers available to service machinery overseas
Warranty :
2 Years
Weight :
15 T
Voltage :
380V.50HZ.3Phase
Condition :
New
Color :
as your request
Description

Main technical parameters

Finished products: 2 waves and 3 waves guardrail forming machine with 2.5-4mm with holes punching
1.Raw material request:Q235Mpa hot rolled steel ,black steel or galvanized steel 2.Material thickness:2.5mm-4mm 3.Whole line working speed:max15m/min( 3 pcs x4320mm per min 4.Total power:about 100kw 5.Input direction: left to right direction Finished Product information: 6.Product width: 350mm/460mm 7.Product height: 69mm 8.Product length: 4330mm9.Product tolerance:4320mm±1.5mm 10.Space requirement: Length 45mxWidth 5m xHeight 3m
Q235 Road Highway Guardrail Roll Forming MachineQ235 Road Highway Guardrail Roll Forming MachineQ235 Road Highway Guardrail Roll Forming Machine
Q235 Road Highway Guardrail Roll Forming MachineQ235 Road Highway Guardrail Roll Forming MachineQ235 Road Highway Guardrail Roll Forming Machine
