C Channel GI Steel 1.0mm Metal Stud Machine
C Channel GI Steel 1.0mm Metal Stud Machine
C Channel GI Steel 1.0mm Metal Stud Machine
C Channel GI Steel 1.0mm Metal Stud Machine
C Channel GI Steel 1.0mm Metal Stud Machine
C Channel GI Steel 1.0mm Metal Stud Machine
C Channel GI Steel 1.0mm Metal Stud Machine
C Channel GI Steel 1.0mm Metal Stud Machine
Specifications
Brand Name :
BEST
Certification :
CE
Place of Origin :
CHINA
MOQ :
1 set
Price :
USD8000---15000
Payment Terms :
L/C, T/T
Supply Ability :
20 sets/month
Delivery Time :
30 work days
Thickness Range :
0.3-0.7mm
Material Stress :
235MPa 345MPa And 550MPa.
Roller Material :
No.45steel
System :
PLC Control Automatic System
Description

C Channel Stud And Track Roll Forming Machine For GI steel 0.4-1.0mm Thickness

Technical data of metal roof tile roll forming machine

Suitable material color steel sheet;0.3-07mm,
Working speed about10-25m/min
stress 235MPa,345MPa,550MPa.
Power Main motor power: 5.5 Kw(Depend on final design)
Hydraulic station power: 4Kw(Depend on final design)
Material of forming rollers No.45 steel, plated with chrome on surface.
Material of cutter,pressing die Cr12 mould steel with quench treatment, HRC58-60
Material of shaft High quality 45# steel, Roller grinder milling.
Shaft diameter 72mm
Controlling system Mitsubishi PLC & converter
Total weight of machine About 9500KGS
Machine’s size about 18m×1.8m× 1.5m (Depend on final design)

Layout drawing of machine

C Channel GI Steel 1.0mm Metal Stud Machine

C Channel GI Steel 1.0mm Metal Stud MachineC Channel GI Steel 1.0mm Metal Stud Machine
