Specifications
Brand Name :
Sussman
Model Number :
PU - SP
Certification :
CE, ISO9001, SGS
Place of Origin :
Hebei China
MOQ :
1 set
Price :
negotiable
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
5 Sets / Month
Delivery Time :
80 days
Packaging Details :
Film and Steel
Products :
EPS Sandwich Roof Wall Panel Production Line
Thickness :
50mm-250mm
Raw Material :
Metal Steel & EPS
Effective Width :
950mm/970mm
Glue :
A&B
Speed :
5-6 meters/min
Description

950mm 970mm Width EPS Sandwich Roof Wall Panel Production Line

NO.
Name
Components
Quantity
Remark

1

Roof panel roll forming machine
Manual Decoiler
1 set
5 tons
Steel cutting device
1 set
Electric
Single layer roll forming machine
1 set


2
Feeding Machine
Steel uncoiler
2 Sets
Upper/Lower each 1 set
Ribs forming set
2 Sets
Upper/Lower each 1 set
Electrical cutting sheet set
2 Sets
Core material conveying device
1 Set



3


Main sandwich panel part
Glue pump
1 Set
4 glue pumps, 2 motors, 2 inverters
Pneumatic glue device
3 Sets
Upper/Middle/Lower each 1 set
Sandwich main part and transmission
1 Set
Infrared heating device
6 Sets
Electrical edge joint forming set
1 Set
4
PLC computer control
1 Set
5
Cutting set
1 Set
Automatic cutting
6
Receive stacking
1 Set
6 meters

Working Flow:

250mm Thickness EPS PU Sandwich Roof Wall Panel Production Line


Composite Decoiler—Roll Forming—laminating system (ribbon, gelatinizing, heating up, compounding, crimping, notching , edge trimmer)—Cutting system—Runout Table

Profile Drawing:

1, Socket type wall panel

250mm Thickness EPS PU Sandwich Roof Wall Panel Production Line

2, Lapped type roof panel

250mm Thickness EPS PU Sandwich Roof Wall Panel Production Line

3, Self-locking roof panel

250mm Thickness EPS PU Sandwich Roof Wall Panel Production Line

Finished Products:

250mm Thickness EPS PU Sandwich Roof Wall Panel Production Line

250mm Thickness EPS PU Sandwich Roof Wall Panel Production Line
