ASTM A179 ASME SA179 32*3mm Seamless Heat Exchanger Tube
ASTM A179 ASME SA179 32*3mm Seamless Heat Exchanger Tube
ASTM A179 ASME SA179 32*3mm Seamless Heat Exchanger Tube
ASTM A179 ASME SA179 32*3mm Seamless Heat Exchanger Tube
ASTM A179 ASME SA179 32*3mm Seamless Heat Exchanger Tube
ASTM A179 ASME SA179 32*3mm Seamless Heat Exchanger Tube
ASTM A179 ASME SA179 32*3mm Seamless Heat Exchanger Tube
ASTM A179 ASME SA179 32*3mm Seamless Heat Exchanger Tube
Specifications
Brand Name :
Joyruns
Model Number :
32*3mm
Certification :
ISO9001
Place of Origin :
Changzhou
MOQ :
2Tons
Payment Terms :
L/C, T/T
Supply Ability :
2000Tons/Month
Delivery Time :
20days
Packaging Details :
plastic packing, end caps
Standard :
ASTM A179 / ASME SA179
OD :
6mm to 168.3mm
WT :
1mm to 20mm
Length :
24M max
Surface :
Black or Oiling
Packing :
Plastic packing, End caps, or Wooden-box
Material :
ST35, ST52, ST37.2
HS Code :
730419
Description

ASTM A179 / ASME SA179 32*3mm Seamless Cold Drawn Low Carbon Heat Exchanger/Condenser Tube

Seamless steel tubes are widely used in high (low and medium) pressure boilers and petrochemical industry, high-pressure chemical fertilizer processing equipment, cracking of petroleum, the transmission of fluids, shipbuilding, etc

Joyruns Supplies low/Higher temperature seamless carbon steel tube of ASTM A179 specification in product types: Cold Drawn in cut lengths or U tube(bent for heat exchanger application), manufactured for application of critical engineering applications as refineries, power plant, Newclear Power, Fossil Fuel Power Plant.

This tube product is available in custom-made size, diameter, and thickness. We have provided a wide range of tubes that have features like durability, sturdiness, high strength, longer service life and more and are offered in various forms like ferrous and non –ferrous metals. These a179 tubes are delivered with surface coatings like black, oiled, phosphate and bright polishing.

ASTM A179 Chemical Composition

Chemical Composition((%) Max.

C

Mn

P≤

S≤

Si≤

0.06-0.18

0.27-0.63

0.035

0.035

0.25

ASTM A179 Seamless Tube Mechanical Property:

Steel Grade

Yield Strength (Mpa)

Tensile Strength (Mpa)

Elongation (%)

ASTM A179

≥180

≥325

≥35

Tolerance SA-450/SA-450M:

OD In (mm) + - WT In (mm) + -
<1(25.4) 0.10 0.10 ≤1.1/2(38.1) 20% 0
1∼1.1/2(25.4∼38.1) 0.15 0.15 >1.1/2(38.1) 22% 0
>1.1/2∼<2(38.1∼50.8) 0.20 0.20
2∼<2.1/2(50.8∼63.5) 0.25 0.25
2.1/2∼<3(63.5∼76.2) 0.30 0.30
3∼4(76.2∼101.6) 0.38 0.38
>4∼7.1/2(101.6∼190.5) 0.38 0.64
>7.1/2∼9(190.5∼228.6) 0.38 1.14
